VideoJet X40 SN
Network Video Server
en
Installation and Operating Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch VideoJet X40 SN

Summary of Contents for Bosch VideoJet X40 SN

  • Page 1 VideoJet X40 SN Network Video Server Installation and Operating Manual...
  • Page 2 VideoJet X40 SN...

  • Page 3: Table Of Contents

    VideoJet X40 SN Table of Contents | en Table of Contents Preface About this Manual Conventions in this Manual Intended Use EU Directives Rating Plate Safety Information Electric Shock Hazard Installation and Operation Maintenance and Repair Product Description Scope of Delivery...
  • Page 4 | Table of Contents VideoJet X40 SN 5.19 Advanced Mode: Encoder Profile 5.20 Advanced Mode: Audio 5.21 Advanced Mode: Storage Management 5.22 Advanced Mode: Remote Video Device 5.23 Advanced Mode: Recording Profiles 5.24 Advanced Mode: Retention Time 5.25 Advanced Mode: Recording Scheduler 5.26...
  • Page 5 VideoJet X40 SN Table of Contents | en Malfunctions with iSCSI Connections LEDs Processor Load Network Connection Serial Interface Terminal Block Communication with Terminal Program 8.10 Copyrights Specifications Unit Protocols/Standards Image Refresh Rate Glossary Index Bosch Security Systems Installation and Operating Manual...
  • Page 6 | Table of Contents VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 7: Preface

    Intended Use The VideoJet X40 SN network video server transfers video, audio and control signals over data networks (Ethernet LAN, Internet). There are various memory options for recording the images captured by the connected camera. The unit is intended for use with CCTV systems.

  • Page 8: Eu Directives

    | Preface VideoJet X40 SN EU Directives The VideoJet X40 SN network video server complies with the requirements of EU Directives 89/336 (Electromagnetic Compatibility) and 73/23, amended by 93/68 (Low Voltage Directive). Rating Plate For exact identification, the model name and serial number are inscribed on the bottom of the housing.

  • Page 9: Safety Information

    Maintenance and Repair – Never open the housing of the VideoJet X40 SN. The unit does not contain any user- serviceable parts. – Never open the housing of the power supply unit. The power supply unit does not contain any user-serviceable parts.
  • Page 10 | Safety Information VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 11: Product Description

    Adobe Acrobat Reader NOTICE! Check that the delivery is complete and in perfect condition. Arrange for the unit to be checked by Bosch Security Systems if you find any damage. Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06...

  • Page 12: System Requirements

    Additional Operational Requirements – Microsoft Internet Explorer (version 6.0 or higher) – Receiver software, for example VIDOS (version 3.11 or higher) or Bosch Video Management System (version 2.02 or higher) – MPEG-4 compatible hardware decoder from Bosch Security Systems (for example VIP XD) as a receiver and connected video monitor –...

  • Page 13: Overview Of Functions

    Two units, for example a VideoJet X40 SN as a sender and a VIP XD as a receiver, can create a standalone system for data transfer without a PC. Video images from a single sender can be received simultaneously on multiple receivers.
  • Page 14 Recordings Various local memory options enable the VideoJet X40 SN to be used as a digital VCR. The VideoJet X40 SN supports ANR technology, which guarantees seamless recording without gaps via VIDOS-NVR, even during network failures.
  • Page 15 VideoJet X40 SN Product Description | en Summary The VideoJet X40 SN provides the following main functions: – Video and data transmission over IP data networks – Dual Streaming function for the encoder for simultaneous encoding with two individually definable profiles –...

  • Page 16: Connections On The Front Panel

    | Product Description VideoJet X40 SN Connections on the Front Panel USB interface for future expansion of functions Video In 1 to Video In 4 video inputs BNC sockets for connecting video sources Audio In audio line input 3.5 mm stereo socket for connecting an audio line input signal Audio Out audio line output 3.5 mm stereo socket for connecting an audio line output signal...

  • Page 17: Connections On The Rear Panel

    VideoJet X40 SN Product Description | en Connections on the Rear Panel ETH RJ45 socket for connecting to an Ethernet LAN (local network), 10/100 MBit Base-T ETH LED lights up yellow when the unit is connected to the network via ETH...
  • Page 18 | Product Description VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 19: Installation

    The ambient temperature must be between 0 and +50 °C (+32 and +122 °F). The relative humidity must not exceed 95%. The VideoJet X40 SN generates heat during operation, so you should ensure that there is adequate ventilation and enough clearance between the unit and heat-sensitive objects or equipment.

  • Page 20: Connections

    Ground Ground Connect two audio sources with line level to the Audio In socket of the VideoJet X40 SN with a 3.5 mm stereo plug. Connect a unit with line-in connection to the Audio Out socket of the VideoJet X40 SN with a 3.5 mm stereo plug.
  • Page 21 To remove the CF card, simply pull it out. Data Interface The bidirectional data interface is used to control units connected to the VideoJet X40 SN, such as a dome camera with a motorized lens. The connection supports the RS-232, RS-422 and RS-485 transmission standards.
  • Page 22 Remote Indication of the Connection Status When the VideoJet X40 SN is connected to a video, the Connect LED on the front panel of the unit flashes. The LED also provides information on the operational state of the unit and signals a unit defect (see Section 8.4 LEDs, page 113).
  • Page 23 Installation | en Backup Power Supply If the VideoJet X40 SN does not have a permanent power supply, it may be necessary to supply the internal clock separately. To do this, you can connect the VideoJet X40 SN directly to a battery via the BP and GND contacts. The correct time is crucial for evaluating local recordings.

  • Page 24: Power On/Power Off

    The VideoJet X40 SN does not have a power switch. Power is supplied via a separate unit. Connect the VideoJet X40 SN to the power supply unit and plug this into the mains. The unit is now ready for use. The VideoJet X40 SN does not come supplied with a power supply unit.
  • Page 25 You can start the configuration if a VideoJet X40 SN is shown in the list in the left section of the window. To do this, right-click the entry for the unit.
  • Page 26 | Installation VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 27: Configuration Using A Web Browser

    Configuration Using a Web Browser Connecting The integrated HTTP server in the VideoJet X40 SN provides you with the option to configure the unit over the network with a Web browser. This option is an alternative to configuration using the Configuration Manager program and is considerably richer in function and more convenient than configuration using the terminal program.
  • Page 28 VideoJet X40 SN Establishing the Connection Before you can operate the VideoJet X40 SN within your network, it must have a valid IP address for your network and a compatible subnet mask. The following default address is preset at the factory: 192.168.0.1 Start the Web browser.

  • Page 29: Configuration Menu

    The settings in the advanced mode should only be processed or modified by expert users or system support personnel. All settings are backed up in the VideoJet X40 SN memory so they are not lost even if the power fails.
  • Page 30 | Configuration Using a Web Browser VideoJet X40 SN Starting Configuration Click the SETTINGS link in the upper section of the window. The Web browser opens a new page with the configuration menu. Navigation Click one of the menu items in the left window margin. The corresponding submenu is displayed.

  • Page 31: Basic Mode: Unit Access

    Basic Mode: Unit Access Device name You can give the VideoJet X40 SN a name to make it easier to identify. The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the VIDOS or Bosch Video Management System programs.

  • Page 32: Basic Mode: Date/Time

    VideoJet X40 SN Password A VideoJet X40 SN is generally protected by a password to prevent unauthorized access to the unit. You can use different authorization levels to limit access. The VideoJet X40 SN operates with three authorization levels: service, user and live.

  • Page 33: Basic Mode: Network

    MAC address, and must be appropriately set up so that, once an IP address is assigned, it is retained each time the system is rebooted. IP address Enter the desired IP address for the VideoJet X40 SN in this field. The IP address must be valid for the network. Subnet mask Enter the appropriate subnet mask for the selected IP address here.

  • Page 34: Basic Mode: Encoder Profile

    | Configuration Using a Web Browser VideoJet X40 SN Gateway address If you want the unit to establish a connection to a remote location in a different subnet, enter the IP address of the gateway here. Otherwise leave the box blank (0.0.0.0).

  • Page 35: Basic Mode: Audio

    VideoJet X40 SN Configuration Using a Web Browser | en Basic Mode: Audio You can set the gain of the audio signals to suit your specific requirements. The current video image is shown in the small window next to the slide controls to help you check the selected audio source and improve assignments.

  • Page 36: Basic Mode: Recording

    CF cards (see Section CF Slot, page 20) are the ideal solution for shorter storage times. if the VideoJet X40 SN has a USB hard drive, this is suitable for longer, local recordings. For long-term, authoritative images, it is essential that you use an appropriately sized iSCSI system.

  • Page 37: Advanced Mode: Identification

    Device name You can give the VideoJet X40 SN a name to make it easier to identify. The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the VIDOS or Bosch Video Management System programs.

  • Page 38: Advanced Mode: Password

    Camera 1 parameters. The window will close. Initiator extension You can attach your own text to the initiator name of the VideoJet X40 SN to make the unit easier to identify in large iSCSI systems. This text is added to the initiator name, separated from it by a full stop.

  • Page 39: Advanced Mode: Date/Time

    – it is added automatically. Enter the current time or click the Sync to PC button to copy your computer's system time to the VideoJet X40 SN. Unit time zone Select the time zone in which your system is located.

  • Page 40: Advanced Mode: Display Stamping

    Now click the OK button to save and activate the table. Time server IP address The VideoJet X40 SN can receive the time signal from a time server using various time server protocols, and then use it to set the internal clock. The unit polls the time signal automatically once every minute.
  • Page 41 VideoJet X40 SN Configuration Using a Web Browser | en Camera name stamping This field sets the position of the camera name overlay. It can be displayed at the Top, at the Bottom or at a position of your choice that you can then specify using the Custom option. Or it can be set to Off for no overlay information.

  • Page 42: Advanced Mode: Appearance

    Internet/Intranet). When accessing via the Internet/Intranet, ensure that a connection is always available to display the image. The image file is not stored in the VideoJet X40 SN. Website language Select the language for the user interface here.

  • Page 43: Advanced Mode: Livepage Functions

    Bilinx control Next to the field for view control at the top left of the LIVEPAGE, an additional field is displayed for the special Bosch Security Systems Bilinx control. Lease time (s) The lease time in seconds determines the time beyond which a different user is authorized to control the cameras after no further control signals are received from the current user.
  • Page 44 | Configuration Using a Web Browser VideoJet X40 SN Show alarm inputs Alarm inputs are shown next to the video image as icons, along with their assigned names. If an alarm is active, the corresponding icon changes color. Show relay outputs Relay outputs are shown next to the video image as icons, along with their assigned names.

  • Page 45: Advanced Mode: Logging

    VideoJet X40 SN Configuration Using a Web Browser | en 5.16 Advanced Mode: Logging Save event log Check this option to save event messages in a text file on your local computer. You can then view, edit and print this file with any text editor or the standard Office software.

  • Page 46: Advanced Mode: Video Input

    You can activate the 75 Ohm terminating resistance for each video input of the VideoJet X40 SN. The terminating resistance must be deactivated for the video signal to be looped through. Every video input is closed at the time of delivery.

  • Page 47: Advanced Mode: Picture Settings

    VideoJet X40 SN Configuration Using a Web Browser | en 5.18 Advanced Mode: Picture Settings You can set the video image of each camera to suit your requirements. The current video image is displayed in the small window next to the slide controls as confirmation. Your changes are effective immediately.

  • Page 48: Advanced Mode: Encoder Profile

    You can adapt the video data transmission to the operating environment (for example network structure, bandwidth, data load). To this end, the VideoJet X40 SN simultaneously generates two data streams (Dual Streaming) for each video input, which compression settings you can select individually, for example one setting for transmissions to the Internet and one for LAN connections.
  • Page 49 VideoJet X40 SN Configuration Using a Web Browser | en Pre-programmed profiles are available, each giving priority to different perspectives. – Low bandwidth (CIF) High quality for low bandwidth connections, resolution 352 × 288/240 pixels – Low delay (2/3 D1) High quality with low delay, resolution 464 ×...
  • Page 50 VideoJet X40 SN Target data rate You can limit the data rate for the VideoJet X40 SN to optimize utilization of the bandwidth in your network. The target data rate should be set according to the desired picture quality for typical scenes with no excessive motion.
  • Page 51 VideoJet X40 SN Configuration Using a Web Browser | en Video quality This setting allows you to adjust the image quality. The Auto option automatically adjusts to the optimum combination of movement and image definition (focus). Alternatively, you can use the slide control to select a value between 1 and 100. A value of 100 results in a very high refresh rate and lower image quality.

  • Page 52: Advanced Mode: Audio

    | Configuration Using a Web Browser VideoJet X40 SN 5.20 Advanced Mode: Audio You can set the gain of the audio signals to suit your specific requirements. The current video image is shown in the small window next to the slide controls to help you check the selected audio source and improve assignments.

  • Page 53: Advanced Mode: Storage Management

    VideoJet X40 SN has a USB hard drive, this is suitable for longer, local recordings. For long-term, authoritative images, it is essential that you use an appropriately sized iSCSI system.
  • Page 54 Each storage medium can only be associated with one user. If a storage medium is already being used by another user, you can decouple the user and connect the drive with the VideoJet X40 SN. Before decoupling, make absolutely sure that the previous user no longer needs the storage medium.
  • Page 55 VideoJet X40 SN Configuration Using a Web Browser | en Check the boxes for the Overwrite older recordings option to specify which older recordings can be overwritten once the available memory capacity has been used. Recording 1 corresponds to Stream 1, Recording 2 corresponds to Stream 2.

  • Page 56: Advanced Mode: Remote Video Device

    5.22 Advanced Mode: Remote Video Device You can allow a remote video device to use the VideoJet X40 SN storage media. This means you can record video images from a camera that does not have its own storage media, for example.

  • Page 57: Advanced Mode: Recording Profiles

    VideoJet X40 SN Configuration Using a Web Browser | en 5.23 Advanced Mode: Recording Profiles You can define up to ten different recording profiles. You will then use these recording profiles in the recording scheduler, where they are linked with the individual days and times (see Section 5.25 Advanced Mode: Recording Scheduler, page 60).
  • Page 58 Section 5.35 Advanced Mode: Alarm Inputs, page 78). The numbering of the checkboxes for the alarm inputs corresponds to the labeling of the alarm inputs on the VideoJet X40 SN. The motion and video loss alarm corresponds to the labeling on the video inputs.

  • Page 59: Advanced Mode: Retention Time

    VideoJet X40 SN Configuration Using a Web Browser | en Recording includes You can specify whether, in addition to video data, audio data and metadata (for example alarms, VCA data and serial data) should also be recorded. Including metadata could make subsequent searches of recordings easier but it requires additional memory capacity.

  • Page 60: Advanced Mode: Recording Scheduler

    | Configuration Using a Web Browser VideoJet X40 SN 5.25 Advanced Mode: Recording Scheduler The recording scheduler allows you to link the created recording profiles with the days and times at which the images of selected cameras are to be recorded in the event of an alarm.
  • Page 61 Click the Stop button to deactivate the recording scheduler. Running recordings are interrupted and the configuration can be changed. Recording status The graphic indicates the recording activity of the VideoJet X40 SN. You will see an animated graphic while recording is taking place. Bosch Security Systems Installation and Operating Manual DOC | V4.0 | 2009.06...

  • Page 62: Advanced Mode: Recording Status

    | Configuration Using a Web Browser VideoJet X40 SN 5.26 Advanced Mode: Recording Status Certain details on the recording status are displayed here for information purposes. You cannot change any of these settings. DOC | V4.0 | 2009.06 Installation and Operating Manual...

  • Page 63: Advanced Mode: Alarm Connections

    5.27 Advanced Mode: Alarm Connections You can select how the VideoJet X40 SN responds to an alarm. In the event of an alarm, the unit can automatically connect to a pre-defined IP address. You can enter up to ten IP addresses to which the VideoJet X40 SN will connect in sequence in the event of an alarm, until a connection is made.
  • Page 64 VIDOS or Bosch Video Management System, you can store a general password here. The VideoJet X40 SN can use this general password to connect to all remote stations protected with the same password. In this case, proceed as follows: Select 10 from the Number of destination IP address list field.
  • Page 65 Please note that the SSL encryption must be activated and configured at both ends of a connection. This requires the appropriate certificates to be uploaded onto the VideoJet X40 SN (see Section Maintenance log, page 90). You can activate and configure encryption of the media data (video, audio and metadata) on the Encryption page (see Section 5.42 Advanced Mode: Encryption, page 88).

  • Page 66: Advanced Mode: Vca

    5.28 Advanced Mode: VCA The VideoJet X40 SN contains an integrated video content analysis (VCA), which can detect and analyze changes in the signal on the basis of image processing. Such changes can be due to movements in the camera's field of view.

  • Page 67: Advanced Mode: Vca Profiles

    VideoJet X40 SN Configuration Using a Web Browser | en 5.29 Advanced Mode: VCA Profiles You can configure two profiles with different VCA configurations. You can save profiles on your computer's hard drive and load saved profiles from there. This can be useful if you want to test a number of different configurations.
  • Page 68 NOTICE! Additional analysis algorithms with comprehensive functions such as IVMD and IVA are available from Bosch Security Systems. If you select one of these algorithms, you can set the corresponding parameters here directly. You can find information on this in the relevant documents on the product CD supplied.
  • Page 69 VideoJet X40 SN Configuration Using a Web Browser | en Sensitivity (MOTION+ only) The basic sensitivity of the motion detector can be adjusted for the environmental conditions to which the camera is subject. The sensor reacts to variations in the brightness of the video image. The darker the observation area, the higher the value that must be selected.
  • Page 70 | Configuration Using a Web Browser VideoJet X40 SN Global change You can set how large the global change in the video image must be for an alarm to be triggered. This setting is independent of the sensor fields selected under Select Area. Set a high value if fewer sensor fields need to change to trigger an alarm.

  • Page 71: Advanced Mode: Vca Scheduled

    VideoJet X40 SN Configuration Using a Web Browser | en Left-click the fields to be activated. Activated fields are marked yellow. If necessary, click Select All to select the entire video frame for monitoring. Right-click any fields you wish to deactivate.
  • Page 72 | Configuration Using a Web Browser VideoJet X40 SN Click the profile you want to link in the Time periods field. Click in a field in the table, hold down the mouse button and drag the cursor over all the periods to be assigned to the selected profile.

  • Page 73: Advanced Mode: Vca Event Triggered

    VideoJet X40 SN Configuration Using a Web Browser | en 5.31 Advanced Mode: VCA Event Triggered This configuration allows you stipulate that the video content analysis is only to be activated when triggered by an event. As long as no trigger is activated, the Silent MOTION+ configuration in which metadata is created is active;...

  • Page 74: Advanced Mode: Audio Alarm

    5.32 Advanced Mode: Audio Alarm The VideoJet X40 SN can create alarms on the basis of audio signals. You can configure signal strengths and frequency ranges in such a way that false alarms, for example due to machine noise or background noise, are avoided.

  • Page 75: Advanced Mode: Alarm E-Mail

    Configuration Using a Web Browser | en Name The name makes it easier to identify the alarm in extensive video monitoring systems, for example with the VIDOS and Bosch Video Management System programs. Enter a unique and clear name here. CAUTION! Do not use any special characters, for example &, in the name.
  • Page 76 | Configuration Using a Web Browser VideoJet X40 SN Mail server IP address Enter the IP address of a mail server that operates on the SMTP standard (Simple Mail Transfer Protocol). Outgoing e-mails are sent to the mail server via the address you entered.

  • Page 77: Advanced Mode: Alarm Task Editor

    VideoJet X40 SN Configuration Using a Web Browser | en 5.34 Advanced Mode: Alarm Task Editor CAUTION! Editing scripts on this page overwrites all settings and entries on the other alarm pages. This procedure cannot be reversed. In order to edit this page, you must have programming knowledge and be familiar with the information in the Alarm Task Script Language document.

  • Page 78: Advanced Mode: Alarm Inputs

    VideoJet X40 SN 5.35 Advanced Mode: Alarm Inputs You can configure the alarm inputs of the VideoJet X40 SN. Alarm input Select Active high if the alarm is to be triggered when the contact closes. Select Active low if the alarm is to be triggered when the contact opens.
  • Page 79 VideoJet X40 SN Configuration Using a Web Browser | en Operating mode Select an operating mode for the relay. For example, if you want an alarm-activated lamp to stay on after the alarm ends, select Bistable. If you wish an alarm-activated siren to sound for ten seconds, for example, select 10 s.

  • Page 80: Advanced Mode: Com1

    NOTICE! If the VideoJet X40 SN is working in multicast mode (see Section 5.40 Advanced Mode: Multicasting, page 86), the first remote location to establish a video connection to the unit is also assigned the transparent data connection. However, after about 15 seconds of inactivity the data connection is automatically terminated and another remote location can exchange transparent data with the unit.

  • Page 81: Advanced Mode: Network

    5.38 Advanced Mode: Network The settings on this page are used to integrate the VideoJet X40 SN into an existing network. Some changes only take effect after the unit is rebooted. In this case, the Set button changes to Set and Reboot.
  • Page 82 MAC address, and must be appropriately set up so that, once an IP address is assigned, it is retained each time the system is rebooted. IP address Enter the desired IP address for the VideoJet X40 SN in this field. The IP address must be valid for the network. Subnet mask Enter the appropriate subnet mask for the selected IP address here.
  • Page 83 You can specify a higher MSS value for a connection to the iSCSI system than for the other data traffic via the network. The potential value depends on the network structure. A higher value is only useful if the iSCSI system is located in the same subnet as the VideoJet X40 SN. Enable DynDNS DynDNS.org is a DNS hosting service that stores IP addresses in a database ready for use.

  • Page 84: Advanced Mode: Advanced

    Only use this function when necessary and no more than once a day, to avoid the possibility of being blocked by the service provider. To transfer the IP address of the VideoJet X40 SN, click the Register button. Status The status of the DynDNS function is displayed here for information purposes.
  • Page 85 The RADIUS server must also contain the corresponding data. To configure the unit, you must connect the VideoJet X40 SN directly to a computer using a network cable. This is because communication via the network is not enabled until the Identity and Password parameters have been set and successfully authenticated.

  • Page 86: Advanced Mode: Multicasting

    In addition to a 1:1 connection between an encoder and a single receiver (unicast), the VideoJet X40 SN can enable multiple receivers to receive the video signal from an encoder simultaneously. The device either duplicates the data stream itself and then distributes it to multiple receivers (Multi-unicast) or it sends a single data stream to the network, where the data stream is simultaneously distributed to multiple receivers in a defined group (Multicast).

  • Page 87: Advanced Mode: Jpeg Posting

    (duplication of the data streams in the network). With the setting 0.0.0.0 the encoder for the relevant stream operates in multi-unicast mode (copying of data streams in the unit). The VideoJet X40 SN supports multi-unicast connections for up to five simultaneously connected receivers.

  • Page 88: Advanced Mode: Encryption

    | Configuration Using a Web Browser VideoJet X40 SN – Large 704 × 576/480 pixels (4CIF) File name You can select how file names will be created for the individual images that are transmitted. – Overwrite The same file name is always used and any existing file will be overwritten with the current file.

  • Page 89: Advanced Mode: Maintenance

    Advanced Mode: Maintenance Firmware The VideoJet X40 SN is designed in such a way that its functions and parameters can be updated with firmware. To do this, transfer the current firmware package to the unit via the selected network. It will then be automatically installed there.
  • Page 90 | Configuration Using a Web Browser VideoJet X40 SN Configuration You can save configuration data for the VideoJet X40 SN on a computer and then load saved configuration data from a computer to the unit. Upload Enter the full path of the file to upload or click Browse to select the required file.

  • Page 91: Advanced Mode: Licenses

    VideoJet X40 SN Configuration Using a Web Browser | en 5.44 Advanced Mode: Licenses You can enter the activation key to release additional functions or software modules. NOTICE! The activation key cannot be deactivated again and is not transferable to other units.

  • Page 92: Function Test

    The VideoJet X40 SN offers a variety of configuration options. You should therefore check that it is functioning correctly after installation and configuration. The function test is the only way to ensure that the VideoJet X40 SN operates as expected in the event of an alarm.

  • Page 93: Operation

    Operation | en Operation Operation with Microsoft Internet Explorer A computer with Microsoft Internet Explorer (version 6.0 or higher) can receive live images from the VideoJet X40 SN, control cameras or other peripherals and replay stored video sequences. System Requirements –...
  • Page 94 VideoJet X40 SN Establishing the Connection Before you can operate the VideoJet X40 SN within your network, it must have a valid IP address for your network and a compatible subnet mask. The following default address is preset at the factory: 192.168.0.1 Start the Web browser.

  • Page 95: The Livepage

    If you do not connect, the unit may have reached its maximum number of connections. Depending on the unit and network configuration, each VideoJet X40 SN can have up to 25 Web browser connections or up to 50 connections via VIDOS or Bosch Video Management System.
  • Page 96 Control options for peripherals (for example a pan/tilt head or dome camera) depend on the type of unit installed and on the configuration of the VideoJet X40 SN. If a controllable unit is configured and connected to the VideoJet X40 SN, the controls for the peripheral are displayed next to the video image.
  • Page 97 Depending on the configuration, the VideoJet X40 SN can send and receive audio signals. All users who are connected by browsers receive the audio signals sent by the VideoJet X40 SN. Audio signals can only be sent to the VideoJet X40 SN by the user who connects to the unit first.

  • Page 98: Saving Snapshots

    Click the icon to start recording. The storage location depends on the configuration of the VideoJet X40 SN (see Section Path for JPEG and MPEG files, page 44). A red dot in the icon indicates that recording is in progress.

  • Page 99: Running Recording Program

    VideoJet X40 SN Operation | en Running Recording Program The hard drive icon below the camera images on the LIVEPAGE changes during an automatic recording. A moving graphic will appear to indicate a running recording. If no recording is taking place, a static icon is displayed.

  • Page 100: The Recordings Page

    100 en | Operation VideoJet X40 SN The RECORDINGS Page The RECORDINGS page for playing back recorded video sequences can be accessed from the LIVEPAGE and from the SETTINGS menu. The RECORDINGS link is only visible if a storage medium has been selected (see Section 5.21 Advanced Mode: Storage Management, page 53).
  • Page 101 VideoJet X40 SN Operation | en 101 The time bar offers various options for navigation. Red bars indicate the points in time where alarms were triggered. Drag the green arrow to navigate to these points quickly. You can change the time interval by clicking the zoom keys (magnifying glass icons). The display can span a range from two months to a few seconds.

  • Page 102: Installing The Player

    Configuration Manager program. Installing the Player You can play back saved video sequences using the Player from Bosch Security Systems, which can be installed from the product CD supplied (see Section 3.1 Scope of Delivery, page 11).

  • Page 103: Hardware Connections Between Video Servers

    Operation | en 103 Hardware Connections Between Video Servers A VideoJet X40 SN with connected cameras to it can be used as a sender and a compatible MPEG-4 hardware decoder (such as the VIP XD) with a connected monitor as a receiver using an Ethernet network connection.
  • Page 104 104 en | Operation VideoJet X40 SN Connecting with a Terminal Program Various requirements must be met in order to operate with a terminal program (see Section 8.9 Communication with Terminal Program, page 116). Start the terminal program and enter the command 1 in the main menu to switch to the IP menu.

  • Page 105: Operation Using Software Decoders

    The VideoJet X40 SN video server is also designed for use with the DiBos 8 digital recorder. DiBos 8 records up to 32 video and audio streams and is available as IP software or hybrid DVR with additional analog camera and audio inputs.
  • Page 106 106 en | Operation VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...

  • Page 107: Maintenance And Upgrades

    Connect LED flashes red (see Section 3.4 Connections on the Front Panel, page 16). All settings will revert to their defaults. Change the IP address of the VideoJet X40 SN if necessary. Configure the unit to meet your requirements.

  • Page 108: Repairs

    (electrical engineers or network technology specialists). In case of doubt, contact your dealer's technical service center. Transfer and Disposal The VideoJet X40 SN should only be passed on together with this installation and operating manual. Your Bosch product is designed and manufactured with high-quality materials and components which can be recycled and reused.

  • Page 109: Appendix

    If you are unable to resolve a malfunction, please contact your supplier or systems integrator, or go directly to Bosch Security Systems Customer Service. You can view a range of information about your unit version on the System Overview page (see Section 5.45 Advanced Mode: System Overview, page 91).

  • Page 110: General Malfunctions

    110 en | Appendix VideoJet X40 SN General Malfunctions Malfunction Possible causes Recommended solution No connection between Incorrect cable connections. Check all cables, plugs, the unit and terminal contacts, terminals and program. connections. The computer's serial interface Check the other serial interface.
  • Page 111 VideoJet X40 SN Appendix | en 111 Malfunction Possible causes Recommended solution The unit does not report Alarm source is not selected. Select possible alarm sources on an alarm. the Alarm Inputs configuration page. No alarm response specified. Specify the desired alarm...

  • Page 112: Malfunctions With Iscsi Connections

    112 en | Appendix VideoJet X40 SN Malfunctions with iSCSI Connections Malfunction Possible causes Recommended solution After connecting to the Incorrect LUN mapping during Check the iSCSI system iSCSI destination, no iSCSI system configuration. configuration and reconnect. LUNs are displayed.

  • Page 113: Leds

    VideoJet X40 SN Appendix | en 113 LEDs The VideoJet X40 SN network video server has a number of LEDs on its front and rear panels that show the operating status and can give indications of possible malfunctions: ETH LED Does not light up: No network connection.

  • Page 114: Processor Load

    VideoJet X40 SN Processor Load If the VideoJet X40 SN is accessed via the Web browser, you will see the processor load indicators in the top right of the window next to the manufacturer's logo. You can obtain additional information to help you when troubleshooting or fine tuning the unit.

  • Page 115: Terminal Block

    VideoJet X40 SN Appendix | en 115 Terminal Block The terminal block has several contacts for: – 4 alarm inputs – 4 relay outputs – Serial data transmission Pin Assignment The pin assignment of the serial interface depends on the interface mode used (see Section 5.37 Advanced Mode: COM1, page 80).

  • Page 116: Communication With Terminal Program

    Communication with Terminal Program Data Terminal If a VideoJet X40 SN cannot be found in the network or the connection to the network is interrupted, you can connect a data terminal to the VideoJet X40 SN for initial setup and setting of important parameters.
  • Page 117 Appendix | en 117 Assigning an IP Address Before you can operate a VideoJet X40 SN in your network you must first assign it an IP address that is valid for your network. The following default address is preset at the factory: 192.168.0.1 Start a terminal program such as HyperTerminal.

  • Page 118: Copyrights

    118 en | Appendix VideoJet X40 SN 8.10 Copyrights The firmware 4.0 uses the fonts "Adobe-Helvetica-Bold-R-Normal--24-240-75-75-P-138- ISO10646-1" and "Adobe-Helvetica-Bold-R-Normal--12-120-75-75-P-70-ISO10646-1" under the following copyright: Copyright 1984-1989, 1994 Adobe Systems Incorporated. Copyright 1988, 1994 Digital Equipment Corporation. Permission to use, copy, modify, distribute and sell this software and its documentation for...

  • Page 119: Specifications

    VideoJet X40 SN Specifications | en 119 Specifications Unit Operating voltage 10 to 30 V DC, power supply via external unit Power consumption Approx. 19 W with full equipment LAN interface 1 × Ethernet 10/100 Base-T, automatic adjustment, half/full duplex, RJ45 Data interfaces 1 ×...

  • Page 120: Protocols/Standards

    120 en | Specifications VideoJet X40 SN Protocols/Standards Video standards PAL, NTSC Video coding protocols H.264 Baseline Profile, MPEG-4, M-JPEG, JPEG Video data rate 9.6 kbps to 6 Mbps Image resolutions (PAL/NTSC) 704 × 576/480 pixels (4CIF/D1) 704 × 288/240 pixels (2CIF) 464 ×...

  • Page 121: Glossary

    Unit of measurement for the speed of data transmission Bits per second, the actual data rate BVIP Bosch Video over IP unit CompactFlash; interface standard, for digital storage media amongst other things. Used in computers in the form of CF cards, digital cameras and Personal Digital Assistants (PDA).
  • Page 122 122 en | Glossary VideoJet X40 SN HTTP Hypertext Transfer Protocol: protocol for transmitting data over a network HTTPS Hypertext Transfer Protocol Secure: encrypts and authenticates communication between Web server and browser ICMP Internet Control Message Protocol Identification: a machine readable character string...
  • Page 123 VideoJet X40 SN Glossary | en 123 MPEG-4 A further development of MPEG-2 designed for transmitting audiovisual data at very low transfer rates (for example over the Internet) Maximum Segment Size; maximum byte figure for the user data in a data packet...
  • Page 124 124 en | Glossary VideoJet X40 SN SNTP Simple Network Time Protocol; a simplified version of NTP (see NTP) Secure Sockets Layer; an encryption protocol for data transmission in IP-based networks Subnet mask See Net mask Transmission Control Protocol Telnet Login protocol with which users can access a remote computer (Host) on the Internet Transport Layer Security;...

  • Page 125: Index

    VideoJet X40 SN Index | en 125 Index Display stamping 40 Dome camera 21 Activating the recording 61 Dual Streaming 13 Activation key 91 DynDNS 83 Alarm 17 Alarm e-mail 75 Alarm input 21 Echo 116 Alarm inputs 78 Electromagnetic compatibility 8...
  • Page 126 126 en | Index VideoJet X40 SN Recording video sequences 98 Reflections of light 68 Main functions 15 Regulations 7 Maintenance 9 Relay 17 Manufacturer logo 42 Relay output 78 Media-replay 100 Relay outputs 22 Milliseconds 41 Remote control 14...
  • Page 127 VideoJet X40 SN Index | en 127 Transmission parameters 116 Transmission protocol 64 Transmission rate 80 Transmission standards 21 Transparent 80 Traps 85 Trick mode 102 Trigger 21 Trigger relay 79 TTL 87 UDP 64 Unicast 86 Unit date 39...
  • Page 128 128 en | Index VideoJet X40 SN DOC | V4.0 | 2009.06 Installation and Operating Manual Bosch Security Systems...
  • Page 130 Bosch Sicherheitssysteme GmbH Robert-Koch-Straße 100 85521 Ottobrunn Germany Telefon 089 6290-0 089 6290-1020 www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2009...

This manual is also suitable for:

Videojet x20 sn

Table of Contents
