- Page 1 DSB-122L/122LH(영어) 01.8.17 5:29 PM 페이지20 OWNER'S MANUAL SPLIT AIRCONDITIONING SYSTEM MODEL #: DSB-122L/DSB-122LH...
-
Page 2: Safety Instructions
The installation instructions are for a experienced in- staller. If you are not an experienced installer, contact a local installer for help. If you require help with service, contact your certified dealer or Daewoo Electronics for additional instructions. If Unit is Installed Improperly:... -
Page 3: Table Of Contents
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지2 It is recommended that you read the Installation and Operating instructions fully before installing and/or operating this unit. Safety Instructions ...1 Contents...2 Basic Accessories ...3 Optional Accessories...4 Location of Controls...5 Indoor Unit ...5 Outdoor Unit ...5 Remote Controller ...7... -
Page 4: Basic Accessories
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지3 This Installation section explains how and where to connect this new air conditioner. Please read make sure all acces- sories are included as shown below and read manual thoroughly. This Installation section is provided to assist the per- son knowledgeable in air conditioner installation and should not be installed by anybody who is not thoroughly familiar with this type of installation. -
Page 5: Optional Accessories
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지4 ACCESSORIES NOT SUPPLIED WITH THE UNIT: Description Drain Hose Extension Tape Copper Tubing Extension Insulator Plate Putty Connection Cord Signal line Cord Cap Wall Complete Optional Accessories (1, 2, 3, 4, 5, 6, 7, 8) -
Page 6: Location Of Controls
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지5 LOCATION OF CONTROLS INDOOR UNIT Indoor Cover Electrostatic Filter Removes dust particles from the air. Air Cleaning Filters Removes dust and prohibits germs. Fan Direction OUTDOOR UNIT AIR OUT Air In Deodorizing Filter Removes bad smells from the air. - Page 7 DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지6 INDOOR UNIT Indoor Unit Display Remote Control Signal Receiver This place is the part to receive the signal if it receive the signal, you can hear the signal “beep”. QUICK CLEAN ON (Red) Lights-on during the operation...
-
Page 8: Remote Controller
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지7 DSB-122L REMOTE CONTROLLER FAN SPEED Button Press to select the fan speed (High " ", Middle " ", Low " ", Natural). MODE Button Press to cycle through the modes (Auto/Quick/Cool/Fan/Dehumidifier) SLEEP Button Press to set the unit for the sleep mode. - Page 9 DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지8 DSB-122LH REMOTE CONTROLLER FAN SPEED Button Press to select the fan speed (High " ", Middle " ", Low " ", Natural) MODE Button Press to cycle through the modes (Auto/Quick/Cool/Fan/Dehumidifier /Heat) SLEEP Button Press to set the unit for the sleep mode.
-
Page 10: Operation
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지9 CONNECTING THE AC CORD The outdoor unit is connected to the indoor unit through the AC connecting wire or connection cord. To connect the in- door unit to AC, follow the procedures below: 1. Insert the at-... -
Page 11: How To Install Batteries
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지10 HOW TO INSTALL BATTERIES To install the batteries, follow the procedures below: 1. Slide down the cover to access most of the remote buttons. Slide down further to access the bat- tery compartment. The precautions below should be followed when using batteries in this device: 1. -
Page 12: To Set Auto Mode
DSB-122L/122LH(영어) 01.8.17 5:27 PM 페이지11 TO SET AUTO MODE This unit will automatically operate the unit according to its surroundings while in the Auto mode. All you have to set is the desired temperature and it will control the fan, coolness and dehumidifier. Follow procedures below: 1. -
Page 13: To Set Fan Only Mode
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지12 TO SET FAN ONLY MODE To operate only the fan so the unit will circulate the air, proceed as follows: 1. Press the ON/OFF button on the remote control to turn the unit on; the On LED will light on the indoor unit and “ON”... -
Page 14: To Set Heat Mode(Dsb-122Lh Only)
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지13 TO SET HEAT MODE (DSB-122LH ONLY) To set the unit to heat the room to a desired temperature, follow the procedures below: 1. Press the ON/OFF button on the remote control to turn the unit on; the On LED will light on the indoor unit and “ON”... -
Page 15: To Set On Timer Mode
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지14 TO SET ON TIMER MODE This unit can be set to automatically turn on after a predetermined amount of hours (up to 24) in the order of 0.5, 1, 1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 8, 10, 12, 16, 20, 24. -
Page 16: To Set Unit To Sleep Mode
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지15 TO SET UNIT TO SLEEP MODE When you are going to sleep, select this feature and the unit will cool off the room to the desired temperature and then increase that temperature throughout the night. -
Page 17: Changing/Cleaning The Air Filters
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지16 CHANGING/CLEANING THE AIR FILTERS To change or clean the two black air filters, follow the procedures below: 1. Open the indoor unit’s cover and remove both black air filters by bending them slightly backward and the lifting out. -
Page 18: Care And Maintenanc
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지17 CARE AND MAINTENANCE warning • Make sure the AC cord is unplugged and the unit is off before cleaning. • Do not use water on the unit to clean it. This is a shock hazard and the unit can be damaged. -
Page 19: Troubleshooting Guide
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지18 TROUBLESHOOTING GUIDE Before requesting service, please refer to the chart below for possible solutions: SYMPTOMS No power The compressor does not turn on. (no cool air) Strange sounds occur. Strange smells occur. No remote operation. -
Page 20: Specifications
DSB-122L/122LH(영어) 01.8.17 5:28 PM 페이지19 MODEL Function Power Supply Cooling Capacity (Heating Mode) Operating Current (Heating Mode) Power Consumption (Heating Mode) Indoor Unit Dimensions Outdoor Unit Dimensions Indoor Net Weight Outdoor Type Connection the piping Liquid Air Cleaning Operating Indoor side (Heating Mode)
