Order information
Vertical Zoneline
units
®
Number
Description
RAK3152
208/230V Universal power supply kit (15 Amp)
RAK3202
208/230V Universal power supply kit (20 Amp)
RAK3302
208/230V Universal power supply kit (30 Amp)
RAK4157
208/230V Universal power supply kit (15 Amp)
RAK4207
208/230V Universal power supply kit (20 Amp)
RAK4307
208/230V Universal power supply kit (30 Amp)
RAK5157
265/277V Universal power supply kit (15 Amp)
RAK5207
265/277V Universal power supply kit (20 Amp)
RAK5307
265/277V Universal power supply kit (30 Amp)
RAVAL1
Aluminum outdoor grille
RAVRG1
Access panel with return air grille for closet wall
RAVRG2
Return air grille for common closet wall
RAVRMS
Wall-mounted room air sensor
RAVWP6
Wall plenum for up to 6" walls
RAVWP8
Wall plenum for up to 8" walls
RAVWP12
Wall plenum for up to 12" walls
RAVWP15
Wall plenum for up to 15" walls
Zoneline units
Number
Description
RAA62
Replacement filters for AZ models (20 pairs per box) for 2200, 3200 & 5200 only
RAA62A
Replacement filters (20 pairs per box) for 2500, 3500 & 5500 only
RAA63
Replacement filters (10 pairs per box) for 2800, 3800, 4100, 5800 & 6100 only
RAB71A
Standard wall case
RAB77A4
SMC wall case
RAD10
Internal/external drain kit
RAF452
Replacement standard room cabinet (2-position louvers) for 2200, 3200 & 5200 only
RAF452A
Replacement standard room cabinet (2-position louvers) for 2500, 3500 & 5500 only
RAF453
Replacement standard room cabinet (2-position louvers) for 2800, 2900, 3800, 3900, 4100, 5800 & 6100 only
RAG60
Stamped aluminum exterior rear grille
RAG61
Architectural rear grille, beige
RAG62
Architectural rear grille, maple
RAG63
Architectural rear grille, dark brown
RAG67
Aluminum architectural outdoor grille
RAKOIM
Optional interface module for central desk control or remote thermostat control for 2200, 3200 & 5200 only
RAK40
Air deflector kit
RAK4002
Direct-connect junction box, 230/208 and 265/277V for 2200, 3200 & 5200 only
RAK4002A
230/208V direct-connect junction box for 2500, 3500, 2800, 2900, 3800, 3900, 4100 & 6100 only
RAK4002B
230/208V direct-connect junction box for 5500, 5800 only
RAK4002CW
230/208V and 265/277 direct-connect junction box wiring
RAK201
Access plate cover
RAK3152
208/230V Universal power supply kit (15 amp) for AZ7500/8500 only
RAK3153
Universal power supply, 15 Amp for 5200, 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
RAK3202
208/230V Universal power supply kit (20 amp) for AZ7500/8500 only
RAK3203
Universal power supply, 20 Amp for 5200 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
RAK3302
208/230V Universal power supply kit (30 amp) for AZ7500/8500 only
RAK3303
Universal power supply, 30 Amp for 5200 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
RAK4157
208/230V Universal power supply, 15 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK4207
208/230V Universal power supply, 20 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK4307
208/230V Universal power supply, 30 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK5157
265/275V Universal power supply, 15 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK5207
265/275V Universal power supply, 20 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK5307
265/275V Universal power supply, 30 Amp for 2800, 2900, 3800, 3900, 4100, 5500, 5800, 6100, 7500 & 8500 only
RAK5172
Universal power supply, 15 Amp, 265V for 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
RAK5202
Universal power supply, 20 Amp, 265V for 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
RAK5302
Universal power supply, 30 Amp, 265V for 2800, 2900, 3800, 3900, 4100, 5500, 5800 & 6100 only
All sales kits are stocked in Appliance Distribution Centers
* A-B Series: Zoneline units built before 1987 – Zoneline I, II, III, and IV; AZC Series: Zoneline units built from 1987 to 1992 – includes AZR Series – Zoneline 1000, 2000, 2500, 2700, 3000,
4000, 5000; AZ Series: Zoneline units built after 1992 – Zoneline 2100, 3100, 2600, 5100 / Zoneline 2200, 3200, 5200 / Zoneline 2500, 3500, 5500 / Zoneline 2800, 2900, 3800, 3900, 4100,
5800, 6100, 7500, 8500.
