3. Look for Option 66.
If Option 66 is not already defined, select Add.
Name
Data Type
Code
Description
If Option 66 is already defined:
4. Select OK.
5. Right-click the Scope Options for the domain and select Configure Options.
6. Select the check box next to Option 66.
7. For the String field, enter the IP address of the UC server (for example, 123.45.67.89).
8. Select OK.
NOTE: For DHCP servers other than Windows Server 2003/2008 and Windows SBS, consult the
appropriate documentation and fill in the options as indicated in Step 3.
Preparation
This section provides instructions on how to apply firmware upgrades (if necessary) and how to set up the
phone for automatic detection and provisioning.
Setting the Protocol
Mitel supports two protocols: MiNET and SIP. MiNET is a proprietary communication protocol
developed by Mitel exclusively for their private branch exchange (PBX) systems. Mitel phones by default
ship with the MiNET protocol enabled. Because the UC server uses SIP for communication, you must
change the phone to SIP mode.
To set the phone to SIP mode:
Hold down the * and 7 keys while the phone is booting. After about 5 seconds, a message will
appear on the screen that says CHANGE CONFIRMED. This means that the phone is now in
SIP mode.
UC Server Provisioning Server
String
66
UC Server Provisioning Server IP Address
If it is defined as a String type and the value is the IP address for the UC server,
no action is required.
If it is not defined as a String type and/or the value is not the IP address for the
UC server, automatic detection of the Mitel phones is not possible unless this
option can be changed as per the instructions above.
4
