FD8136 World Smallest Network Fixed Dome Camera
Commercial Series, H.264, 1-Megapixel, Stylish Design, Easy & Quick
Installation
Architectural and Engineering Specification
2.01
Manufacturer
A. VIVOTEK Inc.
6F, No.192, Lien-Cheng Rd.
Chung-Ho, New Taipei City, Taiwan 23553
Phone
+886 8245-5282
Fax
+886 8245-5532
Email
sales@vivotek.com
B. Manufacturer shall warrant the camera to be free from defects in
material and workmanship for two years from the purchase date.
2.02
General Network Camera Descriptions
A. The product represents the next-generation in video quality in network
cameras. With its 1-Megapixel resolution users will be able to
experience the utmost in picture clarity. The camera supports the
industry-standard H.264 compression technology, drastically reducing
file sizes and conserving valuable network bandwidth. With MPEG-4 and
MJPEG compatibility also included, video streams can be transmitted
in any of these formats for versatile applications.
B. The camera has a built-in web server for users to configure the camera
to meet different purposes. It is IEEE 802.3af compliant
Power-over-Ethernet ready, and with such feature the installation can
be very convenient.
C. The camera shall have on-board storage supporting Micro SD/SDHC cards.
2.03
General Camera Requirements
A. The H.264 camera specified shall incorporate a progressive scan CMOS
imager with a 1/4-inch optical format, not less than 1280(H) x 800(V)
pixels.
B. The image resolution shall be no less than 1280(H) x 800(V) pixels.
Users can specify many resolutions smaller than default for a specific
purpose.
C. The camera shall produce a frame rate of 30 frames per second (fps)
at resolution of 1280(H) x 800(V) 16:10 aspect ratio in H.264 and MJPEG
codec.
D. The camera shall produce a frame rate of 25 frames per second (fps)
at resolution of 1280(H) x 800(V) 16:10 aspect ratio in MPEG-4 codec.
E. Minimum light requirement to produce an image shall be approximately
0.45 lux with an F1.8 lens 50 IRE.
FD8136 – 2012/04
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivotek FD8136
Summary of Contents for Vivotek FD8136
- Page 1 FD8136 World Smallest Network Fixed Dome Camera Commercial Series, H.264, 1-Megapixel, Stylish Design, Easy & Quick Installation Architectural and Engineering Specification 2.01 Manufacturer A. VIVOTEK Inc. 6F, No.192, Lien-Cheng Rd. Chung-Ho, New Taipei City, Taiwan 23553 Phone +886 8245-5282 +886 8245-5532 Email sales@vivotek.com...
- Page 2 Internet Explorer or Mozilla released after January 1, 2010. C. The camera shall provide integrated support for IPv4, IPv6, TCP/IP, IGMP, DHCP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, DDNS, DNS, NTP, SNMP, , SMTP, FTP, PPPoE, CoS, QoS, and 802.1X. D. The camera shall be ONVIF compliant. FD8136 – 2012/04...
- Page 3 J. The camera shall provide the possibility to sync the frequency with the power line frequency to eliminate a flickering image. K. The camera shall be able to provide the possibility to flip and/or mirror the video image for increase the flexibility of the installation. FD8136 – 2012/04...
- Page 4 FCC, Class B ii. CE iii. LVD iv. VCCI v. C-Tick B. RoHS a. All material and/or components used in the manufacture of the product shall be in compliance with the EU Directive 2002/95/EC Restriction of Hazardous Substance (RoHS). FD8136 – 2012/04...
