PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M6 Washer
M10 Split Washer 16mm Wave
M8 x 22mm M10 x 25mm
(90)––8
(105)––20 Washer (54)––2
Washer (97)––10 Washer (134)––2
M4 x 16mm M8 x 16mm
M6 x 16mm
M4 x 12mm
M8 Jam Nut
Screw (101)––10
Screw (103)––8 Screw (82)––10
Screw (148)––4
(102)––6
M8 x 43mm M10 x 20mm
Bolt (96)––6 Screw (91)––22
