ProForm 18.0 Re Elliptical Manual page 14

13. IMPORTANT: If you purchase the optional
chest heart rate monitor (see page 27), see
step 18 on page 16 to install the receiver
included with the heart rate monitor.
Orient the Rear Console Cover (80) as shown.
Attach the Rear Console Cover (80) to the
Upright (4) with four M4 x 16mm Screws (101).
14. While a second person holds the Console (7)
near the Upright (4), connect the wires on the
Console to the Upper Wire (152), to the Right
and Left Sensor Wires (108, 110), and to the
Extension Wire (162).
Insert the excess wire into the Upright (4).
Tip: Avoid pinching the wires. Attach the
Console (7) to the Upright (4) with four M4 x
12mm Screws (148).
13
80
14
7
152
14
101
101
4
Avoid pinching
the wires
108,
110
162
4
148
