PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Locknut
(102)–4
M8 x 13mm
Screw (82)–4
M10 x 25mm
Screw (92)–2
M8 x 22mm
Washer (129)–2
M8 x 20mm
Head Screw (120)–2
Screw (95)–2
Screw (101)–22
M8 x 28mm
Washer (97)–2
M8 x 20mm Flat
M10 x 114mm Screw
(104)–4
7
Tablet Holder
M4 x 16mm
Screw (133)–4
M8 x 45mm Bolt
(96)–4
