Product and Cut-out Dimensions

Built-in Coffee System

CVA4062

Location Codes

E -
5 foot - 120 Volt - 15 Amp 3-wire
molded plug connects left upper rear.
O -
Standard NEMA 5-15 outlet.
Location must be accessible.

Notes

• Width with optional EBA Trim Kits:

EBA5470MC
EBA5476MC
• All installations must be done in
accordance with local codes.
O
26" - 26 1/4"
28 3/8" - 28 1/2"
E
NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 151208
