  • Page 1 WaveAce Oscilloscope Passive Probes Models: PP013 PP014 PP015 PP016 Instruction Manual Revision A – November, 2008...
  • Page 2 Spare parts, replacement parts and repairs are warranted for 90 days. In exercising its warranty, LeCroy, at its option, will either repair or replace any assembly returned within the warranty period to the Customer Service Department of an authorized service center.
  • Page 3 Instructions Introduction The probes (PP013, PP014, PP015, PP016) described in this manual are passive probes to be used with LeCroy WaveAce oscilloscopes Safety Information This symbol appears on the product: It refers you to additional information contained in this manual. The corresponding information in the manual is similarly denoted.
  • Page 4: Specifications

    Use of the probe and/or the test instrument it is connected to in a manner not specified by the manufacturer may impair the protection mechanisms. Accessories The following table lists the standard accessory kit which is included with all WaveAce Passive Probes (PP013, PP014, PP015, PP016). Part Quantity Standard Ground Lead Sprung Hook...
  • Page 5 Instructions Note: The maximum input voltage derates when frequency response is approximately 30 kHz or higher. See voltage derating curve on the next page. EC Declaration of Conformity The PP010 probe meets intent of the European Council Directive 73/23/EEC for product safety per the following standard: EN 61010-031:2002 Safety requirements for hand-held probe assemblies for electrical test and...
  • Page 6 WaveAce Passive Probes LF compensation is performed by connecting the input of the probe to a low frequency square wave, such as the oscilloscope calibrator signal set to 1 kHz. The compensation is adjusted by rotating the trimmer pot accessible through the small hole in the center of the housing near the BNC connector.
