Installation/Operator's Manual
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion or to prevent property damage,
personal injury or death.
Do not store or use gasoline or other flammable
vapor and liquids in the vicinity of this or any
other appliance.
WHAT DO YOU DO IF YOU SMELL GAS
* Do not try to light any appliance.
* Do not touch any electrical switch; do not
use any phone in your building.
* Clear the room, building or area of all
occupants.
* Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
* If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
072999EL/cms
EURO-24
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables dans
le voisinage de cet appareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
* Ne pas tenter d'allumer d'appareil.
* Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment où vous vous trouvez..
* Évacuez la pièce, le bâtiment ou la zone.
* Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions
du fournisseur.
* Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installation et l'entretien doivent être assurés
par un installateur ou un service d'entretien
qualifié ou par le fournisseur de gaz.
For replacement parts, contact the distributor from which the dryer
American Dryer Corporation
Fall River MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
e-mail: techsupport@amdry.com
was purchased or
88 Currant Road
ADC Part No. 113105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EURO-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for American Dryer Corp. EURO-24

Summary of Contents for American Dryer Corp. EURO-24

  • Page 1 Installation and service must be performed by a qualified installer, service agency or the gas supplier. 072999EL/cms EURO-24 AVERTISSEMENT: Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort.

  • Page 2: Pour Votre Sécurité

    Retain This Manual In A Safe Place For Future Reference American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is prop- erly maintained, it will provide many years of safe, efficient, and trouble-free operation. ONLY qualified technicians should service this equipment.

  • Page 3: For Your Safety

    YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, AD- JUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Oc- cupational Safety and Health Administration) STANDARDS.
  • Page 4 The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT. DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE...EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED. PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/ or specified in the installation/operator's manual included with the dryer.

  • Page 5: Table Of Contents

    Table of Contents SECTION I ... 3 IMPORTANT INFORMATION A. Receiving and Handling ... 3 B. Safety Precautions ... 4 SECTION II ... 6 SPECIFICATIONS/COMPONENT IDENTIFICATION A. Specifications ... 6 SECTION III ... 8 INSTALLATION PROCEDURES A. Unpacking/Setting Up ... 8 B.
  • Page 6 SECTION VI ROUTINE MAINTENANCE ... 42 A. Cleaning ... 42 B. Adjustments ... 43 C. Lubrication ... 43 D. Lint Drawer Removal ... 44 SECTION VII TROUBLESHOOTING... 45 Microprocessor (Computer) Models ... 45 Dual Timer Models ... SECTION VIII DATA LABEL LOCATION/INFORMATION ... 55 SECTION IX REVERSING TIMER SPIN/DWELL ADJUSTMENTS ...

  • Page 7: Section I

    IMPORTANT INFORMATION A. RECEIVING and HANDLING The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden skid should be visually inspected for shipping damage.

  • Page 8: Safety Precautions

    B. SAFETY PRECAUTIONS WARNING: For your safety, the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury, or loss of life. WARNING: The dryer must never be operated with any of the back guards, outer tops, or service panels removed.
  • Page 9 WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvent will create a fire hazard. WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubberlike materials. Drying in a heated basket (tumbler) may damage plastics or rubber and also may be a fire hazard.

  • Page 10: Section Ii

    A. SPECIFICATIONS MAXIMUM CAPACITY ( DRY WEIGHT BASKET ( ) DIAMETER TUMBLER BASKET ( ) DEPTH TUMBLER BASKET ( ) MOTOR TUMBLER DOOR OPENING (D IAMETER BASKET ( ) VOLUME TUMBLER DRYERS PER 20'/40' CONTAINER DRYERS PER 45'/48' TRUCK VOLTAGE AVAILABLE APPROX.

  • Page 11: Specifications

    Specifications EURO-24 NOTE: ADC reserves the right to make changes in specifications at any time without notice or obligation.

  • Page 12: Section Iii

    INSTALLATION PROCEDURES Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable AMERICAN NATIONAL STANDARDS: ANSI Z223.1-LATEST EDITION (National Fuel Gas Code) ANSI/NFPA NO.70-LATEST EDITION (National Electrical Code) A.

  • Page 13: Location Requirements

    B. LOCATION REQUIREMENTS Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1-LATEST EDITION. 1. The dryer must be installed on a sound level floor capable of supporting its weight. It is recommended that carpeting be removed from the floor area that the dryer is to rest on.

  • Page 14: Dryer Enclosure Requirements

    C. DRYER ENCLOSURE REQUIREMENTS Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of twelve (12) inches (30.48 cm) above the dryer's outer top; eighteen (18) inches (45.72 cm) for steam dryers, except along the front of the dryer which may be closed if desired. NOTE: Allowances must be made for opening the control door.

  • Page 15: Fresh Air Supply Requirements

    D. FRESH AIR SUPPLY The EURO-24 air supply (makeup air) must be given careful consideration to assure proper performance of each dryer. An unrestricted source of air is necessary for each dryer. As a general rule, an unrestricted air entrance from the outdoors (atmosphere) of a minimum of 1-1/2 square feet (0.14 square meters) is required for each dryer.

  • Page 16: Exhaust Requirements

    E. EXHAUST REQUIREMENTS Exhaust duct work should be designed and installed by a qualified professional. Improperly sized duct work will create excessive back pressure which results in slow drying, increased use of energy, and shutdown of the burner by the airflow (sail) switch, burner hi-limit, or lint chamber hi-heat protector thermostat. Where possible, it is suggested to provide a separate (single) exhaust duct for each dryer.

  • Page 17: Single Dryer Venting

    SINGLE DRYER VENTING IMPORTANT: For exhaust duct runs over 20 feet (6 meters) a minimum size of 10-inches (25 cm) must be used. ORIZONTAL ENTING When a single 8-inch (20 cm) horizontal vent is used, the duct work to the outlet cannot exceed 20 feet (6 m) (refer to Illus.

  • Page 18: Vertical Venting

    ERTICAL ENTING When vertical single 10-inch (25 cm) venting is used (refer to Illus. B below), the duct work from the dryer to the outside outlet cannot exceed 40 feet (12 meters) (refer to Illus. B below). This calculation compensates for the use of a maximum of three (3) elbows including the two (2) elbows creating the 180°...
  • Page 19 MULTIPLE DRYER (Common) VENTING If it is not feasible to provide separate exhaust ducts for each dryer, ducts for individual dryers may be channeled into a common main duct. Each dryer is provided with a back draft damper. The individual ducts should enter the bottom or side of the main duct at an angle not more than 45°...
  • Page 20 ORIZONTAL ENTING Illus. C ERTICAL ENTING . D. LLUS...
  • Page 21 IMPORTANT VENTING REMINDERS 1. Duct work size and installation should be done by a qualified professional. 2. The dryer must be exhausted to the outdoors. 3. Duct work should be routed as short as possible to the outdoors with as few elbows as possible. 4.

  • Page 22: Electrical Information

    F. ELECTRICAL INFORMATION 1. Electrical Requirements It is your responsibility to have ALL electrical connections made by a properly licensed and competent electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL electrical connections, material, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO.70-LATEST EDITION.
  • Page 23 2) Electric Models ONLY ALL electrically heated dryers must be connected to the electric service shown on the dryer's data label which is affixed to the back side of the control (service) door. The connecting wires must be properly sized to handle the rated current. NOTE: Electrically heated service (amperage) specifications/requirements not available at the time of printing.
  • Page 24 INGLE HASE Ø Black White If local codes permit, power to the dryer can be made by the use of a flexible U.L. listed power cord or pigtail (wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker panel.
  • Page 25 5. 3-Phase (3ø) Wiring Connections/Hookup The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, L3, and some- times Neutral) and ground. Single-phase (1ø) power for the control circuit is done internally to the dryer. No single-phase (1ø) input connection is required on a 3-phase (3ø) dryer.
  • Page 26 CAUTION: The dryer must be grounded. A ground lug has been provided for this purpose. IMPORTANT: A CIRCUIT SERVING EACH DRYER MUST BE PROVIDED. The only electrical connections to the dryer are the 3-phase (3ø) leads (L1, L2, L3, and sometimes Neutral) and ground.

  • Page 27: Electrical Service Specifications

    EURO-24 (G EURO-24 (S LECTRICAL IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify NOTES: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY. B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used.

  • Page 28: Gas Information

    G. GAS INFORMATION It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION or the CAN/CGA-B149, installation codes.
  • Page 29 Per Hour MODEL Rating NUMBER EURO-24 150,000 Shaded area is stated in metric equivalent * D.M.S. (Drill Material Size) equivalents are as follows: Natural Gas ... #29 = .1360" (3.4544 mm) Liquid Propane Gas ..
  • Page 30 3. Piping Connections ALL components/materials must conform to National Gas Code specifications. It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of ALL the appliance BTU's being supplied. The dryer is provided with a 1/2"...
  • Page 31 Consistent gas pressure is essential at ALL gas connections. It is recommended that a 3/4-inch pipe gas loop be installed in the supply line serving a bank of dryers. An in-line pressure regulator must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 12.0 inches of water column (30 mbar) pressure.

  • Page 32: Steam Information

    IMPORTANT: Failure to comply with the requirements stipulated in this manual can result in component failure which will VOID THE WARRANTY. NOTE: The EURO-24 is manufactured with a pneumatic (piston) damper system which requires an external supply of air (80 PSI +/- 10 PSI or 5.5 bar +/- 0.7 bar).
  • Page 33 a. The pressure of the condensate in the steam supply will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made with a minimum 10-inch (25 cm) riser. This will prevent any condensate from draining towards the dryer.
  • Page 34 4. Steam Damper Air System Connections The EURO-24 is manufactured with a pneumatic (piston) damper system which requires an external supply of compressed air. The air connection is made to the steam damper solenoid valve which is located at the rear inner top area of the dryer just in front of the electric service relay box.
  • Page 35 4. Steam Damper System Operation The steam damper, as shown in the illustration below, allows the coil to stay constantly charged eliminating repeated expansion and contraction. When the damper is opened, the air immediately passes through the already hot coil, providing instant heat to start the drying process. When the damper is closed, ambient air is drawn directly into the basket (tumbler), allowing a rapid cool down.
  • Page 36 a. Steam Damper Air Piston (Flow Control) Operation Adjustment Damper operation was tested and adjusted prior to shipping at 80 psi (552 KPa). If damper air adjustment is necessary, locate the flow control valve and make the necessary adjustments as noted below.

  • Page 37: Preparation For Operation/Start-Up

    I. PREPARATION FOR OPERATION/START-UP The following items should be checked before attempting to operate the dryer: 1. Read ALL "CAUTION," "WARNING," and "DIRECTION" labels attached to the dryer. 2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label affixed to the back side of the top front control/service door.

  • Page 38: Preoperational Tests

    J. PREOPERATIONAL TESTS ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions. 1.

  • Page 39: Preoperational Instructions

    5. Make a complete operational check of ALL operating controls. NOTE: If computer program changes are required, refer to the computer programming section of the manual supplied with the dryer. 6. The dryer should be operated through one (1) complete cycle to assure that no further adjustments are necessary and that ALL components are functioning properly.
  • Page 40 NOTES: 1. If the Anti-Wrinkle program is active, the L.E.D. (light emitting diode) display will continue to read "donE", and the microprocessor controller (computer) will proceed through the Anti-Wrinkle program until the maximum "Active Guard Time" has expired or until the door is opened, whichever comes first.
  • Page 41 b. Select Temperature... The dryer will start, the L.E.D. (light emitting diode) display will read the temperature cycle selected, and the drying time portion of the L.E.D. (light emitting diode) display will read "00" and count upward as time elapses, or the vended time will count downward, depending on the program parameter setting. IMPORTANT: If the door is opened during a cycle, both the heat and motor will stop.

  • Page 42: Shut Down Instructions

    1) Display will read "READY" (meaning no cycle in progress). 2) Press the letter on the keyboard (touch pad) corresponding to the cycle desired (i.e., Key "E"). Dryer will start to rotate. 3) L.E.D. display will now toggle "Drying" "manual" "Cycle" "30 Min" "Remain" meaning the dryer is in the drying cycle and count down in minutes.

  • Page 43: Service/Parts Information

    SERVICE/PARTS INFORMATION A. SERVICE 1. Only properly licensed or trained technicians should service the dryer. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Service Department for a distributor in your area. NOTE: When contacting the ADC Service Department, be sure to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.

  • Page 44: Warranty Information

    WARRANTY INFORMATION A. RETURNING WARRANTY CARD(S) 1. Before any dryer leaves the ADC factory test area, a warranty card (ADC Part No. 112254) is placed on the back side of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you, if you file a warranty claim.
  • Page 45 e. Specify whether the part(s) being returned is for a replacement, a credit, or a refund. NOTE: If a part is marked for a credit or a refund, the invoice number covering the purchase of the replacement part must be provided. NOTE: Warranty tags (ADC Part No.

  • Page 46: Routine Maintenance

    ROUTINE MAINTENANCE A. CLEANING A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location.

  • Page 47: Adjustments

    90 DAYS Inspect and remove lint accumulation in customer-furnished exhaust duct work system and from dryer's internal exhaust ducting. WARNING: THE ACCUMULATION OF LINT IN THE EXHAUST DUCT WORK CAN CREATE A POTENTIAL FIRE HAZARD. WARNING: DO NOT OBSTRUCT THE FLOW OF COMBUSTION and VENTILATION AIR. WARNING: INSPECT and REMOVE ANY LINT ACCUMULATION WHICH CAN CAUSE THE BACK DRAFT DAMPER TO BIND OR STICK.

  • Page 48: Lint Drawer Removal

    D. Lint Drawer Removal To remove the lint drawer from the dryer pull drawer out approximately halfway. Rotate/move lint drawer stop hinge (refer to the illustration below) downward and pull drawer out. IMPORTANT: After replacing the lint drawer back into the dryer, be sure to rotate/move hinge back to the upward stop position.

  • Page 49: Troubleshooting

    IMPORTANT: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY or THE STEAM SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.
  • Page 50 4. Failed microprocessor controller (computer). . Drive motor (reversing) operates in one direction only...stops and restarts in same direction... 1. Failed drive motor contactor (relay). 2. Failed arc suppressor (A.S.) board (for Reversing Models ONLY). 3. Failed microprocessor controller (computer). D.
  • Page 51 3. Failed arc suppressor (A.S.) board (for Reversing Models ONLY). 4. Failed microprocessor controller (computer). 5. Failed 24 VAC transformer. H. Both drive motor and blower motor run a few minutes and then stop...microprocessor controller (computer) display continues to read time or percent of extraction and all indicator dots are off... 1.
  • Page 52 K. Microprocessor controller (computer) will not accept any keyboard entries, i.e., L.E.D. (light emitting diode) display reads "FILL" and when keyboard entries are selected, the L.E.D. display continues to read "FILL"... 1. Failed keyboard label (touchpad) assembly. 2. Failed microprocessor controller (computer). L.

  • Page 53: Gas Models Only

    P. Heating unit is not operating (no heat) and heat indicator dot is on... ODELS 1. Fault in sail switch circuit ... a. Sail switch is out of adjustment or has failed. b. Sail switch damper is not closing or is fluttering ... 1) Lint drawer/screen is dirty.
  • Page 54 3. No (external) compressed air to steam damper (80 psi (552 KPa) required). 4. Failed steam damper 24 VAC pneumatic solenoid switch. 5. Failed piston. 6. Steam damper stuck closed. Q. Dryer operates but is taking too long to dry... 1.
  • Page 55 2. Back draft damper is sticking in partially closed position. S. Scraping noise from basket (tumbler) area... 1. Check for object caught in basket (tumbler)/wrapper area. 2. Basket (tumbler) is out of proper alignment ... a. Check both vertical and lateral alignment. b.

  • Page 56: Dual Timer Models

    A. Dryer will not start...both drive and blower motors not operating (indicator light is off)... 1. Dryer control circuit fuse is blown. 2. Open at location...service main fuse or circuit breaker. 3. Failed push to start relay. 4. Failed door switch and/or circuit. 5.
  • Page 57 b. Sail switch not closing or fluttering ... 1) Check blower (impellor/fan) motor and rotation direction. 2) Restriction in location exhaust system. 2. Tripped burner manual reset hi-limit circuit. 3. Tripped lint compartment (225 4. Failed heat selector switch. LECTRIC ODELS 1.
  • Page 58 2. Steam damper binding in partially open position (for STEAM MODELS ONLY). 3. Lint and/or dust accumulation on steam coil fins (for STEAM MODELS ONLY). 4. Housekeeping ... a. Lint drawer and lint compartment not being cleaned on a regular basis. b.

  • Page 59: Technical Information

    SECTION VIII TECHNICAL INFORMATION A. DATA LABEL Contact American Dryer Corporation When contacting American Dryer Corporation certain information is required to insure proper service/parts information from American Dryer. This information is on the data label located on the inside of the control door. When contacting ADC please have the model number and serial number available.
  • Page 60 THE DATA LABEL 1. MODEL DRYER The model number is an ADC number which describes the size of the dryer and the type of heat (gas, electric, or steam). 2. SERIAL NUMBER The serial number allows ADC to gather information on your particular dryer. 3.

  • Page 61: Reversing Timer Spin/Dwell Adjustments

    REVERSING TIMER SPIN/DWELL Dual timer models with "reversing option" have an electric reversing timer in the electric service box which is located in the upper rear area of the dryer. Both the dwell (stop) time and basket (tumbler) spin time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below).

  • Page 62: Procedure For Functional Check Of Replacement Components

    SECTION X PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT COMPONENTS 1. Microprocessor (computer) Board a. Upon completing installation of the replacement microprocessor (computer) board, reestablish power to the dryer. b. Start the drying cycle by pressing any of the preset cycles in letters "A" thru "F." c.
  • Page 63 d. Verify that motor(s) heat, and door indicator lights on the back side of the microprocessor (computer board are lit. (Refer to illustration below.) e. Open the main door. The dryer must stop and ALL indicator lights on the back side of the microprocessor (computer) board must go out.
  • Page 64 ADC 113105 1- 08/03/99-25 2* 01/18/00-25 3- 07/14/00-20...
