HB50 / ES50 / M50ES
Installation/Operator Manual
WARNING: For your safety the information
in this manual must be followed to
minimize the risk of fire or explosion and
to prevent property damage, personal
injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
●
Do not try to light any appliance.
●
Do not touch any electrical switch;
do not use any phone in your
building.
●
Clear the room, building or area of
all occupants.
●
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
●
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette
notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou
la mort.
—Ne pas entreposer ni utiliser d'essence
ni d'autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
●
Ne pas tenter d'allumer d'appareils.
●
Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
●
Évacuez la pièce, le bâtiment ou la
zone.
●
Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
●
Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L'installation et l'entretien doivent être
assurés par un installateur ou un
service d'entretien qualifié ou par le
fournisseur de gaz.
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.adclaundry.com
ADC Part No. 113014 - 19
Advertisement
Table of Contents
Related Manuals for American Dryer Corp. HB50
Summary of Contents for American Dryer Corp. HB50
- Page 1 HB50 / ES50 / M50ES Installation/Operator Manual AVERTISSEMENT: Assurez-vous de bien WARNING: For your safety the information suivre les instructions données dans cette in this manual must be followed to notice pour réduire au minimum le risque minimize the risk of fire or explosion and d’incendie ou d’explosion ou pour éviter...
- Page 2 Retain This Manual in a Safe Place for Future Reference This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. Only qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.
-
Page 3: Table Of Contents
WARNING WARNING Children should not be allowed to play on or near the dryer(s). Children should be supervised if Proposition 65 near dryer(s) in operation. Use of this product could expose you to substances Under no circumstances should the dryer door from fuel combustion that contain chemicals switch(es), lint door/drawer switch(es), or heat known to the State of California to cause cancer,... -
Page 4: Safety Precautions
Safety Precautions ___________________ WARNING WARNING Do not use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubber For your safety, the information in this manual must materials. Drying in a heated tumbler may damage be followed to minimize the risk of fire or explosion plastics or rubber and also may be a fire hazard. - Page 5 IMPORTANT: The dryer must be installed in a location/ environment, which the ambient temperature remains between 40° F (4.44° C) and 130° F (54.44° C). NOTES _____________________________________________________ The operation of this appliance may affect the operation of other types of gas appliances, which take their air for safe ____________________________________________________________ combustion from the same room.
-
Page 6: Specifications
Specifications _____________________________________________________________________ MAXIMUM CAPACITY (DRY WEIGHT) 50 lb 22.68 kg TUMBLER DIAMETER 37” 93.98 cm TUMBLER DEPTH 25-3/4” 65.41 cm TUMBLER VOLUME 16.02 cu ft 453.64 L TUMBLER / DRIVE MOTOR 3/4 hp 0.56 kW BLOWER / FAN MOTOR 1/2 hp 0.37 kW DOOR OPENING (DIAMETER) 27-3/8”... - Page 7 Specifications _____________________________________________________________________ NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation. 113014 - 19 www.adclaundry.com...
-
Page 8: Installation Procedures
Installation Procedures ______________ Unpacking / Setting Up _______________ Installation should be performed by competent professional Remove protective shipping material (i.e., plastic wrap and in accordance with local, state, and country codes. In the optional shipping box) from the dryer. absence of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1- IMPORTANT: Dryer must be transported and handled in LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA... -
Page 9: Fresh Air Supply Requirements
Fresh Air Supply Requirements ______ Exhaust Requirements _______________ This appliance may only be installed in a room that meets Exhaust ductwork should be designed and installed by a the appropriate ventilation requirements specified in the qualified professional. Improperly sized ductwork will create national installation regulations. - Page 10 Outside Ductwork Protection To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the ductwork travels vertically up through the roof, it should be protected from the weather by using a 180°...
-
Page 11: Electrical Information
IMPORTANT: A separate protected circuit must be A = 8-inch (20.32 cm) B = 20 feet (6 meters) provided to each dryer. The dryer must be connected to the electric supply shown on the data label. In the case of 208 VAC or 240 VAC, the supply voltage must match the electric service specifications of the data label exactly. - Page 12 Electric Models Only For added personal safety, when possible, it is suggested that a separate ground wire (size per local codes) be All electrically heated dryers must be connected to the connected from the ground connection of the dryer to a electric service shown on the dryer’s data label.
-
Page 13: Gas Information
Gas Information ______________________ IMPORTANT: A strain relief must be used where the input wiring enters the oven assembly. It is your responsibility to have all plumbing connections, materials, and workmanship conform to local and state Electrically Heated Models Only regulations or codes of the country of destination. In the The electrical input connections are made at the rear service absence of such codes, all plumbing connections, box located at the right upper section of the dryer. - Page 14 CE and Australian Dryers There is an N.P.T. to B.S.P.T. adaptor included with each dryer, which must be installed to the gas inlet. The adaptor is shipped in the tumbler. IMPORTANT: Pipe joint compounds that resist the action of natural, propane, and butane gases must be used. Heat Input / Gas Consumption / Orifice (Injector) Data Gas Specifications for Dryers Going to CE Countries**...
- Page 15 Piping / Connections IMPORTANT: Pipe joint compounds that resist the action of natural, L.P., and butane gases must be used. Inlet Connection – 1/2” M.N.P.T. Test all connections for leaks by brushing on a soapy CE and Australian dryer connections will be B.S.P.T., all water solution (liquid detergent works well).
- Page 16 Locate the gas train and disconnect the union, three electrical Unregulated Gas Valve plugs, and the gas train mounting screws from the burner. Regulate (govern) gas externally (refer to “Supply Pressure” Carefully slide the gas train out of the gas train enclosure. in chart on page 14) to the correct gas pressure for the gas (The carbon ignitor located at the far end of the gas train is being used.
-
Page 17: Gas Pressure Testing
• Converting from regulated L.P. to regulated natural WARNING (CE Dryers) gas: remove the white plastic regulator adjustment screw (under vent cap). Remove spring under screw This appliance must only be operated with the gas and replace with spring from kit (ADC P/N 140415). type indicated on the dryer’s data plate. -
Page 18: Steam Information
Steam Information ____________________ Steam Requirements – High Pressure It is your responsibility to have all plumbing connections made OPERATING STEAM PRESSURE by a qualified professional to ensure that the steam plumbing Maximum psig* 1.0 MPa installation is adequate and conforms with local, state, and Heat Input (Normal Load) 4 Bhp country regulations or codes. -
Page 19: Water Information
Flexible hoses or couplings must be used. The dryer Water Connections vibrates slightly when it runs and this will cause the steam The water connection is made to the 3/4”-11.5 NH hose coil connections to crack if they are hard piped to the supply adaptor, which is shipped in the tumbler and must be installed and return mains. -
Page 20: Preoperational Test
• Be sure all back panels (guards) and electric box Make a complete operational check of all operating controls. covers are in place. Tumbler Coating • Be sure the service doors are closed and securely in place. The tumbler is treated with a protective coating. We suggest dampening old garments or cloth material with a solution •... -
Page 21: Shutdown Instructions
At the end of the cycle the L.C.D. display will read "Cycle Warranty Done". Opening the main door will put the computer back For a copy of the commercial warranty covering your particular into the “Select Cycle” state. dryer(s), contact the reseller from whom you purchased the equipment and request a dryer warranty form. -
Page 22: Routine Maintenance
IMPORTANT: No replacements, credits, or refunds will be Steam Dryers issued if the claim cannot be processed due to insufficient Clean the steam coil fins. It is suggested that compressed information. The party filing the claim will be notified in air and a vacuum cleaner with brush attachment be used. -
Page 23: Data Label Information
Data Label Information _______________ AGA Label Standard Label When contacting ADC, the information on the data label is required to ensure proper service/parts assistance. The data label is located at the upper left rear of the dryer behind the back guard. CE Label 1. -
Page 24: Programming
Programming _________________________ Event Codes Defined: Top Pocket / Bottom E1 / E4: While attempting to turn on the burner, no burner return Enter Service Mode by Inserting Key and Turning Clockwise signal was received within RADIANT SENSOR COOL DOWN TIME. Main Service Mode window will appear and offer 5 selections: 1: Machine Info 2: Program Setup... - Page 25 NOTES __________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ _________________________________________________________________________________________________________________________________ 113014 - 19 www.adclaundry.com...
- Page 26 ADC Part No. 113014 19 - 05/23/17...
