- Page 1 Operating Guide EPIA EN-Series Mini-ITX Mainboard January 18, 2012 Version 1.21...
-
Page 2: Table Of Contents
EPIA EN-Series Operating Guide Table of Contents Table of Contents ...................................... i VIA EPIA EN-Series Overview................................1 VIA EPIA EN-Series Layout.................................. 2 VIA EPIA EN-Series Specifications ..............................3 VIA EPIA EN Processor SKUs ................................4 VIA CN700 Chipset Overview ................................5 VIA EPIA EN-Series I/O Back Panel Layout............................ -
Page 3: Via Epia En-Series Overview
EPIA EN-Series Operating Guide VIA EPIA EN-Series Overview The VIA EPIA EN-Series Mini-ITX Mainboard is an ultra compact native x86 platform optimized for today's demanding embedded and productivity applications. The mainboard is based on the VIA CN700 chipset featuring an embedded hardware MPEG-2 accelerator and integrated VIA UniChrome™ Pro 2D/3D graphics for rich digital media performance. -
Page 4: Via Epia En-Series Layout
EPIA EN-Series Operating Guide VIA EPIA EN-Series Layout January 18, 2012 - 2 - Version 1.21... -
Page 5: Via Epia En-Series Specifications
EPIA EN-Series Operating Guide VIA EPIA EN-Series Specifications Model Name EPIA EN15000 EPIA EN12000E Processor VIA C7 1.5GHz NanoBGA2 VIA Eden 1.2GHz NanoBGA2 Chipset - VIA CN700 North Bridge - VIA VT8237R-Series South Bridge System Memory - 1 DDR2 400/533 DIMM slot - Up to 1GB memory size - Integrated VIA UniChrome™... -
Page 6: Via Epia En Processor Skus
EPIA EN-Series Operating Guide VIA EPIA EN Processor SKUs The VIA EPIA EN-Series is available in 1.2GHz and 1.5GHz speed grades. The VIA EPIA EN12000E and the VIA EPIA EN15000 utilize the most efficient VIA C7™ / Eden V4 Bus NanoBGA2 processor. Suitable for small, low power, ultra efficient and secure x86 platform. -
Page 7: Via Cn700 Chipset Overview
EPIA EN-Series Operating Guide VIA CN700 Chipset Overview The VIA CN700 Chipset is designed to enable high quality digital video streaming and DVD playback in a new generation of fanless, small form factor PCs and IA devices. The CN700 features the embedded VIA UniChrome™... -
Page 8: Via Epia En-Series I/O Back Panel Layout
EPIA EN-Series Operating Guide VIA EPIA EN-Series I/O Back Panel Layout The EPIA EN’s ultra compact 17cm x 17cm, integrated design supports all the standard legacy x86 connectivity options as well as PS2 Mouse port, PS2 Keyboard port, VGA port, COM port, RJ45 LAN port, USB 2.0 ports, RCA port, S-Video port and AC’97 audio jacks. -
Page 9: Via Epia En-Series Layout Diagram & Mounting Holes
EPIA EN-Series Operating Guide VIA EPIA EN-Series Layout Diagram & Mounting Holes January 18, 2012 - 7 - Version 1.21... -
Page 10: Via Epia En-Series Layout Diagram & Height Distribution
EPIA EN-Series Operating Guide VIA EPIA EN-Series Layout Diagram & Height Distribution January 18, 2012 - 8 - Version 1.21... -
Page 11: Power Consumption
EPIA EN-Series Operating Guide Power Consumption Power consumption tests were carried out comparing the VIA EPIA EN12000E (running with the 1.2GHz VIA Eden V4 Bus NanoBGA2 processor) and the VIA EPIA EN15000 (running with the 1.5GHz VIA C7™ V4 Bus NanoBGA2 processor). The following tables are a comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while running common system applications. -
Page 12: Via Epia En15000
EPIA EN-Series Operating Guide E. Run C.C. Winstone 2001 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.381 1.027 3.472 Main Board +5V 5.071 1.515 7.683 Main Board 5VSB 5.062 0.173 0.876 Main Board +12V 12.198 0.165 2.013 Main Board Power Consumption 14.043 F. - Page 13 EPIA EN-Series Operating Guide D. Idle Measured Voltage Measured Amp. Watts Main Board +3.3V 3.385 1.037 3.510 Main Board +5V 5.074 1.278 6.485 Main Board 5VSB 5.066 0.188 0.952 Main Board +12V 12.216 0.204 2.492 Main Board Power Consumption 13.439 E.
-
Page 14: Power Specifications
EPIA EN-Series Operating Guide Power Specifications The EPIA EN utilizes an industry standard 20-pin ATX main connector to the power supply. Due to the EPIA EN platform’s ultra low power requirements a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -
Page 15: Via Epia En-Series Microsoft And Linux Driver Support
EPIA EN-Series Operating Guide VIA EPIA EN-Series Microsoft and Linux Driver Support Microsoft Driver Support VIA EPIA EN series offers full support for the complete range of Microsoft operating systems. For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the VEPD website at www.viaembedded.com. -
Page 16: Contact
EPIA EN-Series Operating Guide Contact For more information on the VIA EPIA EN-Series Mini ITX Mainboard contact your sales representative or visit our website at www.viaembedded.com Taiwan Headquarters Europe 1F, 531 Zhong-Zheng Road 940 Mission Court In den Dauen 6 Xindian District, New Taipei City Fremont, CA 94539 53117 Bonn...
