Precor Move Beyond 966i Product Specification

966i Treadmill
Low impact treadmill, with wide variety of programming options, designed for heavy commercial use.
Features
Deck and •
Decline to –3% simulates downhill running for training different muscle groups.
Belt •
Ground Effects Impact Control System helps decrease impact on joints and reduces lateral motion.
•
Integrated Footplant Technology makes each step feel more natural, balanced and in-control.
•
Rear deck hinges and front cushioning create a laterally stable platform that reduces shock to the runner and provides a firm surface
for push off.
•
Deck and belt require no external lubrication and are fully warranted for 2 years regardless of usage.
•
Deck is a one-inch Slik-Dek bed composed of 52-lb high-density fiberboard core with phenolic laminate bonded on both sides. Can
be flipped to double life.
•
Seigling E8 special weave multi-ply polyester belt with dry lubricant integrated into the material.
•
Steel tapered rollers keep the belt centered to reduce maintenance and noise.
•
Self-tensioning drive belt protects drive motor from excessive tension.
•
Injection molded trim strips with textured rubber insert are durable and offer secure footing when straddling the treadmill running
belt.
•
Drive
4.0hp continuous-duty DC motor. Continuously operating cooling fan delivers airflow directly through the motor reducing operating
System
temperatures and allowing increased torque output, especially at lower speeds.
•
Lower PCA has integrated power components and continuous fan to handle higher loads and temperatures.
•
Magnetic Hall-effect speed sensor and precision-machined flywheel guarantee exact sensor readings and are unaffected by dust and
dirt build up.
•
Low voltage drive system (PWM) draws less current and minimizes problem with circuit breakers.
•
Removable power cord has a low profile right-angle plug. The cord is attached at a right angle for clearance and is clamped to the
treadmill for reliability.
•
Display
CSAFE ready. Touch sensitive display makes it easy to monitor and alter workouts.
•
Has numeric keypad for easy data entry.
•
Touch sensitive switches are more reliable, resulting in fewer costly repairs than membrane switches.
Frame and •
Two-step powder-coating process applies rust-resistant undercoat and cosmetic topcoat to steel frame.
Lift •
Lift unit generates up to 1000 lbs. of thrust and operates in compression as intended by design.
•
Threads in lift actuator screw are covered at low incline to prevent dust collection
Diagnostics •
Ability to set owner parameters, e.g., limit exercise time and pause time.
•
Ability to check safety breaker and display functioning and to monitor current draw by motor to detect bed and belt wear before
damage occurs.
•
Heart Rate
Heart rate controlled course.
•
Has handheld heart rate and is equipped for heart rate telemetry reading using Polar technology.
•
SmartRate shows actual heart rate in relation to the target zone for weight loss and cardio training.
•
Other
QuickStart for user convenience lets user begin workout with the push of a single button.
Features
•
Accessory holder for water bottle, reading material and portable music.
•
Safety clip attached to emergency stop switch to immediately turn off power bringing treadmill to a gentle stop. Stop switch has no
magnet to lose and has a guard to prevent inadvertent activation.
•
Cord management system includes pre-drilled holes underneath the frame side rails and snap-in cord clips.
•
Warranty
Seven years frame, 5 years touch sensor display housing, 5 years motor fan, 3 years drive motor, 2 years parts and 1 year labor.
Warranties outside the U.S. and Canada may vary.
•
21
Manual, Track, 3 Cross Country, 5K Course, 2 Aerobic, 2 Gluteal, 4 interval, 2 Custom Courses, Random, Heart Rate, Weight Loss,
Programs
Distance Goal, Calorie Goal (Note: A Fitness Test following the firefighter protocol can be enabled in diagnostic mode at the
owner's discretion. If not enabled, a second Custom course is included.)
•
Electronic
Calories, Calories per minute, Distance, Heart Rate, Incline/Decline, METs, Pace, Profile, Segment Time, SmartRate, Speed, Time
Readouts
Measurements
•
Length
•
Width with handrails
•
Height
•
Weight
•
Shipping Weight
•
Regulatory Approvals
•
Maximum workout time
•
Cord length
•
Optional handrail length
Power For equipment:
US & Canada 120 VAC, 50/60 Hz, 16.5A, 1386W
US & Canada 240 VAC, 50/60 Hz, 11.3A, 1900W
International 240 VAC, 50/60 Hz, 11.3A, 1900W
Commercial Sales (425) 486-9292
86 in (218 cm) •
Running Surface
37 in (93 cm) •
Incline
59 in (150 cm) •
Speed
375 lbs. (170 kg) •
Maximum user weight
•
518 lbs. (235 kg) Roller diameter
•
FCC, ETL, CE Step-up
•
240 minutes
Standard handrail length
•
12 ft (3.7m)
Deck height at maximum incline
of 15%
33 in (83.8 cm)
For outlet:
Dedicated 120V/20A circuit with 5-20R NEMA receptacle
Dedicated 240V/20A circuit with 6-20R NEMA receptacle
IEC 320-C19 inlet supporting Schuko and BSI plugs
June 23, 2004
Product Specification
* Polar is a registered trademark of Polar Electro Oy.
60" x 20" (153cm x 51cm)
-3% to 15% in 0.5% increments
0.5-16 mph (1-26 kph)
500 lbs. (227 kg)
4.0 in (10.2cm)
11.6 in (29.5cm)
13 in (33cm)
17.9 in (45.5cm) at farthest forward standing
point
www.precor.com
