Page 1: High Performance
ED/EHD705-004 OP ER ATI ON I N S T RU C T I O N ED705 EHD705 INDOOR DOME OUTDOOR / VANDAL DOME HIGH PERFORMANCE TRUE WDR LOW PROFILE DOME EHD705 ED705... -
Page 2: Operation Instruction
All specifi cations are therefore subject to change without notice. All rights reserved. No part of the contents of this manual may be reproduced or transmitted in any form or by any means without written permission of the EverFocus Electronics Corporation. - Page 3 Precautions Do not install the camera near electric or magnetic fi elds. Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the electromagnetic fi elds generated from these devices may distort the video image or otherwise interfere with camera operation. Never disassemble the camera beyond the recommendations in this manual nor introduce materials other than those recommended herein.
- Page 4 ATTENTION! This is a class A product which may cause radio interference in a domestic environment; in this case, the user may be urged to take adequate measures. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Table Of Contents
Tabl e of C o n te n t s 1. CAUTIONS 2. IMPORTANT SAFETY INSTRUCTION 3. EQUIPMENT AND ACCESSORIES 4. CAMERA COMPONENT DESCRIPTIONS • Indoor Dome / Outdoor-Vandal Dome Type 5. INSTALLATION • Indoor Dome / Outdoor-Vandal Dome Type 6. -
Page 6: Product Overview
To take full advantage of the amazing images produced by this advanced imaging technology, the EverFocus Ultra Series ED705 uses a Sony Double Scan 960H_WD sensor together with a megapixel lens to produce True Wide Dynamic Range (WDR) performance with 720 horizontal TV lines of resolution from this unique Ultra Series 720+ camera. -
Page 7: Equipment And Accessories
3. EQ UIP M EN T A N D A C CESSORI ES Indoor Dome Type Mount Guide (Indoor Dome Type) Outdoor Vandal Dome Type Mount Guide (Outdoor Vandal Dome Type) Manual Screws(3ea) / L-Wrench Service Video Output Test Cable... -
Page 8: Camera Component Descriptions
4. C AM E R A C OM PON EN T DESCRIPTIONS • Indoor Dome Type PART NAME Top Case Lens Cover Camera Module Bracket Camera Module Ass'y Cable Main PCB OSD Controller Base... - Page 9 4. C AM E R A C OM PON EN T DESCRIPTIONS • Vandal Dome Type PART NAME Top Case Lens Cover Case Rubber Camera Module Bracket Camera Module Ass'y Main PCB Safety Wire OSD Controller Base...
-
Page 10: Installation
5. I NS TALLAT IO N (Plastic Dome) 1. Attach the Low Profi le Dome on the ceiling using the screws provided. Considering the camera angle required for the viewing angle. 2. Adjust the Lens Angle to the desired location. TAPPING SCREW (4 x 20L) - 3EA 3. - Page 11 5. I NS TALLAT IO N (Vandal Dome) 1. Attach the Low Profi le Dome on the ceiling using the screws provided. Considering the camera angle required for the viewing angle 2. Adjust the Lens Angle to the desired location. TAPPING SCREW (4 x 20L) - 3EA 3.
-
Page 12: Monitor Connection
5 . INS TA LLATI ON • MONITOR CONNECTION - DC12V/AC24V DC12V/AC24V POWER SUPPLY DC12V/AC24V (TERMINAL BLOCK) VIDEO IN BNC FEMALE CAMERA When you install the camera, please glue up the end of cable to keep it stable in order to protect the camera from the humidity problems. -
Page 13: Dimensions
6. D IME N S I ON S • Indoor Dome Type • Outdoor Vandal Dome Type 5.47" 4.68" Unit(Inches) -
Page 14: Specification
7. SP E CI FI C ATI ON NTSC Image Sensor 1/3” 960H SONY Double Scan Super HAD CCD II Scanning System 2 : 1 Interlace H Resolution. 700TV Lines Scanning Frequency 15.734KHz(H), 59.94Hz(V) 1 5 . 625KHz(H ), 5 0 H z ( V ) Total Pixels No. -
Page 15: Osd Manual
8. O S D M A N U A L • Menu structure Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU FLICKERLESS OFF / ON HIGH LUMINANCE BRIGHTNESS 0 ~ 255 AGC, SLOW, AGC >... - Page 16 8. O S D M A N U A L Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU LEVEL 0 ~ 15 CONTRAST1 0 ~ 7 WDR MODE OFF, ON CONTRAST2 0 ~ 4 RETURN CENTER, TOP, BOTTOM,...
- Page 17 EverFocus USA - California: EverFocus USA - New York: 1801 Highland Avenue, Unit A, Duarte, CA 91010, USA 415 Oser Avenue, Unit S, Hauppauge, NY 11788, USA TEL: +1 626 844 8888 TEL: +1 631 436 5070...
