Billion 5200G Specifications

802.11g 802.11g
Wireless Wireless
WPA-PSK/WPA2-PSK WPA-PSK/WPA2-PSK
Annex M Annex M
Technology Technology
Easy Web Easy Web
Configuration Configuration
BiPAC 5200G R4 Series
802.11g ADSL2+ Firewall Router
Billion's BiPAC 5200G R4 is an economical ADSL2+ Firewall Router with 802.11g Wireless AP ideally designed
for home and SOHO users to enjoy rich firewall security, mobility, and faster speed when using ADSL Internet
connection. With integrated Wireless 802.11g AP, the router enables you to surf the Internet anywhere in your
home. The router lets you share high-speed ADSL Internet connection, even faster with advanced ADSL2+
capability of downstream rate up to 24 Mbps. The powerful SOHO Firewall feature protects against hackers'
attacks when you surf the Internet. VPN pass-through is also built-in for secure access. In addition, the web-based
Graphic User Interface allows you to install and manage your network easily. The BiPAC 5200G R4 makes fast
wireless net surfing affordable and easy - Going online is just 'plug & play'.
Express Internet Access
This router complies with worldwide ADSL standards. It supports downstream rates of up to 12/24 Mbps with
ADSL2/2+, 8 Mbps with ADSL, and upstream rates of up to 1 Mbps. With this technology, users enjoy not only
high-speed ADSL service but also broadband multimedia applications such as interactive gaming, video streaming
and real-time audio much more quickly and easily than ever. In particular, by doubling the upstream data rate,
the Annex M standard included in the BiPAC 5200G R4A model supports the latest ADSL2/2+ for higher upload
speeds.
Wireless Mobility
With an integrated 802.11g Wireless Access Point, the router offers quick and easy access and mobility to the
users of wired networks, wireless networks, and broadband connections (ADSL). In addition to supporting the 54 Mbps
802.11g data rate, it is also backward compatible with existing 802.11b equipment. The Wireless Protected
Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol (WEP) features enhance the level of data
protection and access control via a Wireless LAN.
SOHO Firewall Security
Along with the built-in NAT natural firewall feature, the router's advanced antihacker pattern-filtering protection
feature automatically detects and blocks Denial of Service (DoS) attacks. In addition to the NAT technology, the
BiPAC 5200G R4 supports Packet Filtering for high-level security control.
Easy Network Management
The Web-based User Interface makes the BiPAC 5200G R4 extremely easy for users to install and manage the
network. The router supports DHCP client andserver, enabling system administrators to easily fit this security
router into existing network environment and manage the IP assignment without reconfiguring other stations.
Furthermore, future firmware upgrade can be downloaded via the user-friendly Web-based Interface.
LAN
PWR PWR SYS SYS WLAN WLAN 1 USB 2 3 LAN 4 ADSL PPP ADSL PPP
BiPAC 5200G R4 Front Panel
ADSL 4 3 2 1
PWR
LAN
BiPAC 5200G R4 Rear Panel
• 802.11g Wireless Access Point
with WPA-PSK/WPA2-PSK support
• High speed Internet access with
ADSL2/2+; backward compatible
with ADSL
• Integrated with 4-port
Ethernet Switch
• SOHO Firewall Security with
DoS Prevention and Packet
Filtering
• Universal Plug and Play (UPnP)
Compliant
• Dynamic Domain Name System
(DDNS)
• Supports Virtual Private Network
(VPN) pass-through
• Easy Network Management
• Ideal for Home and SOHO Users
