Installation Guide
For Models:
BW321AG3
BW321SS3
E192641
net weight of fan: 15.63 lb (7.09 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pgs. 5 - 6
Canopy Assembly. pg. 6
Wall Control Operation. pg. 7
Remote Control Operation. pg. 8
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Warranty. pg. 9
Parts Replacement. pg. 9
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Craftmade BW321AG3
Summary of Contents for Craftmade BW321AG3
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Models: BW321AG3 Table of Contents: BW321SS3 Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor assembly and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location of the fan allows the fan cage a inches 10 feet clearance of 10 feet (3.05m) from the floor and that (3.05m) (76cm) the edges of the fan cage will be at least 30in. (76 cm) from any wall or obstruction. -
Page 5: Fan Assembly. Pgs
5. Fan Assembly. If you wish to extend the hanging length of set screw set screw hole your fan, you must remove the hanging ball stop pin from the 4½in. downrod provided to use with an extended downrod (sold separately). [If you wish to use the 4½in. -
Page 6: Wiring. Pgs
5. Fan Assembly. (cont.) safety cable loop wood With the hanging bracket secured to the outlet box ceiling and able to support the fan, you are now ready to joist hang your fan. Grab the fan firmly with two hands. wood screw Slide downrod through opening in hanging bracket and washer... -
Page 7: Canopy Assembly
6. Wiring. (cont.) IN ORDER TO WIRE WALL CONTROL, remove outlet box wall existing wall switch. Wire the WALL CONTROL control with wire connectors provided as shown in plate diagram at right. * Wrap each wire connector separately with green/ green/ green/ bare... -
Page 8: Automated Learning Process/Activating Code
8. Automated Learning Process./ code Activating Code. switches CAUTION: The remote control transmitter can be TRANSMITTER programmed to multiple receivers or fans. If this is (back) not desired, turn wall switch off to any other programmable receiver or fan. Remove battery cover from back side of remote control transmitter. -
Page 9: Remote Control Operation
10. Remote Control Operation. HI button - turns lower fan to HIGH speed main MED button - turns lower fan to MEDIUM speed LOW button - turns lower fan to LOW speed OFF button - turns lower fan OFF button - turns main fan ON/OFF when pressed once (i.e., controls ROTATION of the ENTIRE fan) lower fan... -
Page 10: Troubleshooting
2. Check to be sure code switches in remote to arrange for return of fan. Return fan, shipping prepaid, to control transmitter and wall control are set Craftmade/Ellington. We will repair or ship you a replacement fan, and we will pay the return shipping cost. properly.
