Installation Guide
For Models:
BW248AG6
BW248SS6
E192641
net weight of fan: 27.58 lb (12.51 kg)
READ THESE INSTRUCTIONS AND

Table of Contents:

Wiring. pg. 6
Warranty. pg. 11
SAVE THEM FOR FUTURE USE
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BW248AG6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftmade BW248AG6

Summary of Contents for Craftmade BW248AG6

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Models: Table of Contents: BW248AG6 Safety Tips. pg. 1 BW248SS6 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor assembly and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the blades a inches 10 feet clearance of 10 feet (3.05m) from the floor and (3.05m) (76cm) 30in. (76 cm) from any wall or obstruction. This fan is suitable for room sizes up to 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. If you wish to extend the hanging length of your fan, you must remove the hanging ball set screw hole set screw from the 4½in. downrod provided to use with stop pin an extended downrod (sold separately). [If you wish to use the 4½in.
  • Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet safety cable loop wood box and able to support the fan, you are now ceiling ready to hang your fan. Grab the fan firmly with joist two hands. Slide downrod through opening in wood screw hanging bracket and let hanging ball rest on and washer...

  • Page 7: Wiring

    Las modificaciones no aprobadas por la parte responsable de la conformidad podrían invalidar la autorización del usuario para manejar el equipo. 6. Wiring. *NOTA: Se han hecho pruebas en este equipo y se ha comprobado que cumple con los límites para un aparato digital de clase B, de acuerdo con la Parte 15 de las Reglas de la FCC.

  • Page 8: Canopy Assembly

    antenna 7. Canopy Assembly. hanging bracket Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the hanging screw bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and push up.

  • Page 9: Alternate Final Assembly, Without Light Kit

    8. Light Kit Assembly (Optional). (cont.) motor Remove finial and finial plate from threaded assembly rod at bottom of light kit fitter. Raise glass shade in order to align threaded rod on light kit fitter with hole in middle of glass shade and push up gently, allowing threaded rod to come through hole.

  • Page 10: Automated Learning Process./ Activating Code

    10. Automated Learning Process./ Activating Code. code transmitter CAUTION: The remote control transmitter can be switches (back) programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Remove battery cover on back side of remote control transmitter.

  • Page 11: Remote Control Operation

    12. Remote Control Operation. HI button - turns the 2 smaller fans to HIGH speed MED button - turns the 2 smaller fansto MEDIUM speed LOW button - turns the 2 smaller fans to LOW speed button - turns the 2 smaller fans OFF button - turns light ON/OFF when tapped quickly.

  • Page 12: Troubleshooting

    Return fan, shipping prepaid, to 3. Verify that receiver is wired properly. Craftmade/Ellington. We will repair or ship you a 4. Verify that wall control is wired properly. replacement fan, and we will pay the return shipping cost.
