GCL-GT
HEAVY-DUTY GEAR HEAD TROLLEY OPERATOR
The GCL-GT is designed for standard lift
sectional doors that have up to 60-cycle/hour
duty requirement. Advanced features and
robust mechanical design combine to provide
a heavy-duty operator that sets a new
standard for productivity.
UL325-2010 APPROVED
• Allows for monitored entrapment protection and
momentary operation when used with select photo eyes
and/or edge-sensing devices.
• See back for approved list of monitored devices.
GCL-GT Advantages
• MultiVolt
- Order phase-specific operator for the job and
have the ability to select the right voltage on the job site.
- Single Phase: 115/208/230 VAC
- Three Phase: 208/230/460 VAC
- 575VAC voltage models available separately
• Modular design with optional expansion boards for
advanced timer to close, and auxiliary output functionality.
• LCD display with intuitive setup menu. Provides real-time
status and trouble-shooting assistance.
• Internal receiver with the ability to individually add/delete
up to 50 Intellicode
I transmitters directly from the LCD
®
display.
• EZ Limit
provides for push to set limits that remain
synchronized with door even during long term loss of
power.
• Low-profile height of power head maximizes the clearance
for vehicular traffic.
• Open/close/stop and setup keys included on control board.
Keeps all controls near the LCD display convenient
for set up.
www.GenieCompany.com/commercial
GCL-GT operators are covered by the following U.S. patents: 6737823, 8014966, 8113263
GENIE
®
Standard Features
• EZ Limit
electro-mechanical limits.
• MultiVolt
voltage simplification.
• Max run timer automatically adjusts to up and down run time.
• Heavy-duty worm gearbox for primary reduction.
• Delay on reverse.
• 16-character LCD display.
• UL325-2010 approved.
• Advanced radio receiver displays and stores activation by transmitter
ID number on the LCD screen.
• 3-button control station.
• 2-year/20,000-cycle warranty.
• Programmable mid-stop.
• Drawbar disconnect for emergency manual operation.
• DC disc brake with progressive braking.
|
800.843.4084
CommErCIAL opErATors
