Precision Health Scale
Model UC-321P
Precautions
Please read this booklet before using your scale.
Place your scale on a solid level surface, such as tile, wood, or
laminate flooring.
Do not place your scale on a soft, wet or slippery floor. If the scale
must be used on a carpet, be sure to attach the plastic add-on feet as
shown on page 14.
Your scale contains delicate, high-precision parts. Avoid extremes in
temperature, humidity, direct sunlight, shock, moisture and dust.
Do not step on your scale with your feet wet. Be sure that your feet
are dry to prevent slipping and serious injury.
Step on the center portion of your scale gently.
Do not step on the display window.
Do not open the case of the scale.
Holding the measurement switch for extended periods will shorten battery life.

Indications for Use

The UC-321P is designed for adult use at home.
Compliance with European Directive
The scale complies with the statutory EMC (Electromagnetic Compatibility) directive 2004/
108/EC. Note: The displayed value may be adversely affected under extreme
electromagnetic influences.
1WMPD4002101
Precautions .................................... 1
Scale Components ......................... 2
Display Symbols ............................ 3
Operations
Basic Measurement ....................... 4
Memory Function ........................... 6
Target Function .............................. 8
BMI Indication .............................. 10
References
Specifications ............................... 15
Maintaining the Scale ................... 15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC-321P and is the answer not in the manual?

Questions and answers

Related Manuals for A&D UC-321P

Summary of Contents for A&D UC-321P

  • Page 1: Table Of Contents

    Do not open the case of the scale. Holding the measurement switch for extended periods will shorten battery life. Indications for Use The UC-321P is designed for adult use at home. Compliance with European Directive The scale complies with the statutory EMC (Electromagnetic Compatibility) directive 2004/ 108/EC.

  • Page 2: Scale Components

    Scale Components Display Back Function Indicators OK Mark Low Battery Mark Slide Switch Front Measurement Switch Battery Compartment Function The following four measurements can be selected by the slide switch. Refer to “Basic Measurement” and “Measuring a Baby or an Animal”. WEIGHT The function to measure your weight, the weight of a baby or animal.

  • Page 3: Display Symbols

    Display Symbols OK mark. This mark is displayed when the measurement display is stable. Low battery mark. If this mark is displayed, replace all four batteries with new ones. Function indicators. The current function is indicated. Installing (or Replacing) Batteries Caution Insert each battery with its positive (+) and negative (-) terminals properly aligned with the corresponding marks in the battery compartment.

  • Page 4: Basic Measurement

    Basic Measurement Measuring Your Weight Set the slide switch to “WEIGHT”. Press the measurement switch gently. All display segments are indicated for several seconds. Then, 0.00 kg and the mark are displayed. Step on your scale. Step on your scale gently. When the mark disappears, the measurement is started.
  • Page 5 Measuring a Baby or an Animal Set the slide switch to “WEIGHT”. Press the measurement switch gently and immediately step on your scale. With all of the display segments indicated (sev- eral seconds) and before 0.00 kg appears, step on the scale without any baby or animal in your hands.

  • Page 6: Memory Function

    Memory Function Up to 31 weight data can be stored in memory. The 32nd data is stored by deleting the oldest stored data. The difference from the previous result is displayed automatically. Storing a Current Weight. Set the slide switch to “MEMORY”. Press the measurement switch gently.
  • Page 7 Displaying the Weight Data Stored in the Scale The stored measurement data is displayed in order, beginning with the most recent measurement. Set the slide switch to “MEMORY”. With the scale turned off, press and hold the measurement switch gently. The weight data is displayed in order, from the last result.

  • Page 8: Target Function

    Target Function The difference between the preset target weight and the current weight can be displayed. Presetting a New Target Weight Set the slide switch to “TARGET”. With the scale turned off, press and hold the measurement switch gently. The preset target weight is displayed. Using the measurement switch, set a new target weight.
  • Page 9 Comparing a Current Weight with a Preset Target Weight Set the slide switch to “TARGET”. Press the measurement switch gently. The stored target weight is displayed. Step on the scale. When 0.00 kg and the mark are displayed, step on your scale gently.

  • Page 10: Bmi Indication

    BMI Indication Body Mass Index or BMI (kg/m ), based Underweight Below 18.5 on an individual’s height and weight, is Normal 18.5 to 24.9 a helpful indicator of underweight, over- Overweight 25.0 to 29.9 weight or obesity, in adults. According to the new NHLBI (National Obesity 30.0 and Above Institutes of Health) guidelines, the BMI...
  • Page 11 Displaying the BMI Score Set the slide switch to “BMI”. Press the measurement switch gently. The preset height is displayed. Step on the scale. When 0.00 kg and the mark are displayed, step on your scale gently. The measurement is started when the mark disappears.

  • Page 12: Tracking Your Weight With Your Personal Computer

    Tracking Your Weight with Your Personal Computer The UC-321P can monitor your weight by recording the data to a personal computer and displaying the data on the computer display via the “Weight Diary” Windows software. You can track your weight data and BMI values on the personal computer display by graph or tabular format.
  • Page 13 (9 pin) to the RS-232C port of your computer. Start your computer. Notes Keep the cable straight and keep the feet of the UC-321P off the cable. Gathering the excess length of cable and putting it under the scale is not recommended. This can cause the UC-321P to give an inaccurate reading.

  • Page 14: Measuring Your Weight On A Carpet

    Measuring Your Weight on a Carpet Place the scale on a solid level surface, such as tile, wood, or laminate flooring. If the scale must be used on a carpet, be sure to attach the plastic add-on feet. Steps for Attaching the Add-on Feet Each add-on foot has two pins.

  • Page 15: Specifications

    Specifications Digital display Liquid crystal display, 25 mm character height Maximum capacity 150 kg Minimum display 0.05 kg Power source Four type AA batteries (R6P, 1.5 volt x 4) Battery life Approximately 2000 measurements Accessories Instruction manual, Add-on feet (4), Batteries (4), Connecting cable, CD-ROM “Weight Diary”...
