UC-321PL
Precision Health Scale
Precautions
❒ Please read this booklet before using your scale.
❒ Do not place your scale on a soft, wet or slippery floor. It
is recommended you place your scale on the solid and
level floor.
❒ Place your scale on a solid level flooring surface. Your
scale contains delicate, high-precision parts. Avoid
extremes in temperature, humidity, direct sunlight, shock,
moisture and dust.
❒ Do not step on to your scale with wet feet. Make certain
that feet are dry to prevent slipping or serious injury.
❒ Gently step onto the center portion of your scale.
❒ Do not place feet on the display window.
❒ Holding the measurement switch for extended periods will
shorten battery life.
Indications for Use
❒ This scale is designed for home and clinical use.
Compliance with European Directive
The scale complies with the statutory EMC (Electromagnetic
Compatibility) directive 2004/108/EC. Note: The displayed value may
be adversely affected under extreme electromagnetic influences.
Before Use
Precautions . . . . . . . . . . . . . . . . . . 1
Scale Components . . . . . . . . . . . . 2
Display Symbols . . . . . . . . . . . . . . 3
Installing (or Replacing) Batteries 3
Operations
Normal Measurement . . . . . . . . . . 4
References
Specifications . . . . . . . . . . . . . . . . 6
Maintaining the Scale . . . . . . . . . . 6
Before Requesting Service . . . . . . 6
How to Maintain and Store
your Precision Scale . . . . . . . . . . . 6
Measuring weight on
a shag carpet . . . . . . . . . . . . . . . . . 7
-1-
Advertisement
Table of Contents
Related Manuals for A&D UC-321PL
Summary of Contents for A&D UC-321PL
- Page 1 Scale Components ... . 2 Display Symbols ....3 Installing (or Replacing) Batteries 3 UC-321PL Operations Precision Health Scale Normal Measurement .
-
Page 2: Display Symbols
Scale Components Display Symbols Front Back Ready/Complete symbol. This symbol is displayed when the measurement display is stable. Ready/Complete Symbol Low battery mark. If this mark is displayed, replace the batteries with new ones. WEIGHT A WEIGHT B Installing (or Replacing) Batteries Low Battery Mark Slide Switch Caution... -
Page 3: Normal Measurement
Normal Measurement Measuring Your Weight Measuring a Baby or Small Animal Slide switch Slide switch 1 Set the slide switch to the correct mode. to correct mode to correct mode 1 Set the slide switch to the correct mode. 2 Press the measurement switch gently. 2 Press the measurement switch gently and All display segments are visible for several step on your scale. -
Page 4: Maintaining The Scale
Measuring weight on a shag carpet Specifications UC-321PL Digital display Liquid crystal display, one inch character height Please use the enclosed add-on feet if you wish to use the Precision Health Maximum capacity 450 lb. (200 kg) Scale on shag carpet. - Page 5 A division of A&D Engineering, Inc. 1756 Automation Parkway San Jose, CA 95131 www.andmedical.com I-MAN-321PL 08/2010 ©2010 A&D Medical. All rights reserved. Specifications subject to change without notice.
