- Page 1 Precision Health Scale UC-321PBT-C Instruction Manual 1WMPD4001968B...
-
Page 2: Table Of Contents
Contents Before Use Precautions -------------------------------------------------------------------------------------- 1 Scale Components ------------------------------------------------------------------------------ 2 Display Symbols --------------------------------------------------------------------------------- 3 Installing (or Replacing) Batteries ---------------------------------------------------------- 3 Pairing The PBT-C Series Device With a Continua-Compliant Manager ---------- 4 Operations Basic Measurement ----------------------------------------------------------------------------- 5 Measuring Your Weight-------------------------------------------------------------------------------------- 5 Measuring an Infant or Small Animal--------------------------------------------------------------------- 6 Measuring Your Weight on a Carpet -------------------------------------------------------- 7 References... -
Page 3: Scale Components
Scale Components Display Back Ready/Complete Symbol Low Battery Indicator Slide Switch Front Battery Compartment Measurement Switch The following measurements can be selected by the slide switch and are classified into two categories - WEIGHT A and WEIGHT B. Within WEIGHT A and WEIGHT B, you have a choice to select and have your weight displayed in kg or lb. -
Page 4: Display Symbols
Display Symbols Ready/Complete symbol. This symbol is displayed when the measurement display is stable. Low battery indicator. If this symbol is displayed, replace all four batteries with new ones. Installing (or Replacing) Batteries Caution Insert each battery with its positive (+) and negative (-) terminals properly aligned with the corresponding symbols in the battery compartment. -
Page 5: Pairing The Pbt-C Series Device With A Continua-Compliant Manager
Pairing The PBT-C Series Device With a Continua-Compliant Manager Model UC-321PBT-C is a PBT-C series device. PBT-C series devices are designed to be connected only with Continua Managers. To pair the device with a Manager, please follow these steps: Remove the four AA batteries from the device. Discharge the device completely by trying to take a measurement. -
Page 6: Basic Measurement
Basic Measurement Measuring Your Weight Set the slide switch 1. Set the slide switch to the correct mode. to the correct mode Example: Set the slide switch to [WEIGHT B]. Press the measurement switch 2. Press the measurement switch gently. All display segments are displayed for several seconds. -
Page 7: Measuring An Infant Or Small Animal
Basic Measurement Measuring an Infant or Small Animal Set the slide switch to the correct mode 1. Set the slide switch to the correct mode. Example: Set the slide switch to [WEIGHT B]. Press the measurement switch Step on the scale 2. -
Page 8: Measuring Your Weight On A Carpet
Measuring Your Weight on a Carpet Place the scale on a solid level surface, such as tile, wood, or laminate flooring. If the scale must be used on a carpet, be sure to attach the plastic add-on feet. Steps for Attaching the Add-on Feet 1. -
Page 9: Specifications
Specifications Digital display Liquid crystal display, 25 mm character height Maximum capacity 200 kg / 450 lb Minimum display 0.1 kg / 0.2 lb Wireless communication WML-40AH (Mitsumi Electronics Co. Ltd.) Bluetooth Ver.2.1 Class 1 HDP Continua certified Power source Four type AA batteries (R6P or LR6, 1.5 volt x 4) Battery life... -
Page 10: Transmitting Data To A Continua Manager
Transmitting Data to a Continua Manager Measurement results will be automatically transmitted to the paired Manager at each measurement. In the case of unsuccessful transmission, the device stores the last 25 measurements in memory. The device will send all of the data at the next successful connection and clear memory. - Page 11 MEMO...
- Page 12 A&D Company, Limited 1-243 Asahi, Kitamoto-shi, Saitama 364-8585 JAPAN Telephone: [81] (48) 593-1111 Fax: [81] (48) 593-1119 A&D INSTRUMENTS LTD. Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485 A&D Australasia Pty Ltd.
