Appendix D:

ITI-5232E Four Port 10/100 Ethernet PCI adapter

Bus Interface
Hardware Interrupts
Base I/O Addresses
Data Transfer Rates
Power Requirements
Environmental
Operating Temperature
Humidity
Altitude
Ethernet Standards
Certifications
Electrical Connections
Physical Dimensions
Network Speeds Supported
per Ethernet Network
Segment
Indication LEDs
Adapter Specifications
PCI 32-bit bus master
ITI-5232E-N - supports shared interrupts
ITI-5232E-O/U – does not support shared interrupts
Assigned by BIOS
Up to 800 Mbps in Fast full duplex mode
PCI Universal 3.3 or 5 volts at 17 watts
0 to 55 C
5% to 85% non-condensing
3000m maximum
IEEE 802.3 10 Base-T
IEEE 802.3u 100 Base-T
FCC Class B
CE Class B
(4) RJ-45 female
9.0" X 4.125"
10 Mbps
20 Mbps Full duplex
100 Mbps
200 Mbps Full duplex
Link
Activity
100TX link
36
