Appendix A

Digital's SRM Console Settings

When the ITI-5232E is being used in a Digital Alpha platform running OpenVMS or
Digital UNIX, the SRM console is used to set the port speed, media (cable) type and boot
protocols, and can also be used to test the module.
After powering your system up, and before booting your operating system, the system
will stop at the SRM console prompt. On a uni-processor machine, the SRM prompt is
">>>" and on the primary processor of a multi-processor machine, is "P0>>>".
Digital uses a set of "Environment Variables" to store the settings of certain user
definable parameters, which are passed to the operating system to allow the users
configuration information to stay consistent when the SRM passes control of the system
to the operating system.

Displaying and Setting Ethernet Port Characteristics

The Alpha console recognizes the Ethernet device as an EW port. There are two
commands that are necessary for setting and showing the Ethernet port:
SET and SHOW.
Use SHOW to display characteristics of the Ethernet port.
>>>Show EWn0_MODE
Where 'n' is the Ethernet port letter.
Use SET to set characteristics of the Ethernet port. The available settings for
Ethernet media type are shown in Table 4.
Parameter
EWn0_MODE

Table 4 Digital UNIX and OpenVMS SRM Console Media Selection

Settings
TWISTED-PAIR
FAST
FULL DUPLEX TWISTED PAIR
AUI
BNC
FAST FD
Description
10Mb/sec Twisted Pair
100Mb/sec Twisted Pair
Half Duplex
Full Duplex Twisted Pair
Not Supported
Not Supported
FAST Full Duplex
28
