Windows 95 Installation for PCI systems
The following step should be taken in order to use the IntraServer Technology, Inc. ITI-
5232E Four Port Fast Ethernet 10/100 adapter in a system running Windows 95:
1. Power the machine down, unplug the AC power line, and remove the access cover.
2. Install the ITI5232 into an unused PCI slot. Attach the network cable(s) from the card
to your existing network device.
3. Replace the access cover of your machine.
4. Replace the AC power line, and boot Windows 95.
5. When Windows 95 detects the new hardware, a message:
"New Hardware Found, PCI Ethernet Controller" will be displayed.
6. Put the Software Installation Floppy in your Floppy drive, then select
Next >.
6. Windows '95 will read the installation floppy, and will automatically find the ITI-
5232E Four Port Ethernet controller Select Finish. If you are the "Select Device" dialog
box to select the ITI-5232 Four Port 10/100 Mbps Ethernet Adapter" from the list and
select OK.
18
