  • Page 1 HIGH SPEED BURNISHER MODELS: LB2000I LB2000IA UB2000F LB2000 10090200 10090210 10090620 10090190 Operating Instructions (ENG) 86309600-K 05/30/12...
  • Page 2: Machine Data Log/Overview

    MACHINE DATA LOG/OVERVIEW Model: Date of Purchase: Serial Number: Sales Representative: Address: Phone Number: OVERVIEW The High Speed Burnisher is a mains powered, portable floor burnisher intended for commercial use. The appliance can be fitted with a variety of pads to perform various floor care functions. The appliance employs active dust control, and automatically adjusted pad pressure.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Machine Data Log/Overview........2 Table of Contents..........3 HOW TO USE THIS MANUAL How to use this Manual........1-1 SAFETY Important Safety Instructions .......2-1 Hazard Intensity Level..........2-3 Grounding Instructions.........2-5 OPERATION Technical Specifications........3-1 Handle Installation..........3-2 Operation..............3-3 Pad Driver Installation ..........3-3 MAINTENANCE Machine Troubleshooting........4-1 Wiring Diagram/Service Schedule .......4-2...
  • Page 4: How To Use This Manual

    HOW TO USE THIS MANUAL This manual contains the following sections: The OPERATIONS section is to familiarize the operator with the operation and function of the HOW TO USE THIS MANUAL machine. SAFETY OPERATIONS The MAINTENANCE section contains preventive MAINTENANCE maintenance to keep the machine and its PARTS LIST components in good working condition.
  • Page 5: Safety

    SAFETY IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual.
  • Page 6 IMPORTANTES MESURES DE SÉCURITÉ L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL). Pour réduire les risques d’incendie, de chocs électriques, ou de AVERTISSEMENT blessures : N’utiliser cette machine qu’en intérieur. Ne jamais l’utiliser à l’extérieur ou dans la pluie. N’utiliser cette machine que comme décrit dans le présent manuel.
  • Page 7: Hazard Intensity Level

    SAFETY The following symbols are used throughout this guide as indicated in their descriptions: HAZARD INTENSITY LEVEL There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR SAFETY. The level of hazard intensity is determined by the following definitions: WARNING - Hazards or unsafe practices, which COULD result in severe personal injury or death .
  • Page 8 DEGRÉS DE RISQUES EN CAS DE DANGER Les symboles ci-dessous sont utilisés à travers ce manuel comme illustré dans leurs descriptions : DEGRÉS DE RISQUES EN CAS DE DANGER Il existe trois degrés de risques identifiés par les termes signalétiques –AVERTISSEMENT et ATTENTION et POUR VOTRE SÉCURITÉ.
  • Page 9: Grounding Instructions

    SAFETY Grounding Pin GROUNDING INSTRUCTIONS 120V GROUNDING CONNECTION THIS PRODUCT IS FOR COMMERCIAL USING AN ADAPTOR USE ONLY. Grounded Outlet ELECTRICAL: Metal Screw FIGURE A In the USA this machine operates on a 15 amp nominal 120V, 60 hz, A.C. power circuit. The Adaptor amp, hertz, and voltage are listed on the data Tab for Grounding...
  • Page 10 SAFETY GROUNDING INSTRUCTIONS-230V Improper connection of the equipment- THIS PRODUCT IS FOR COMMERCIAL USE grounding conductor can result in a risk of ONLY. electric shock. Check with a qualified electrician or service person if you are in doubt ELECTRICAL: as to whether the outlet is properly grounded. The amp, hertz, and voltage are listed on the data Do not modify the plug provided with the label found on each machine.
  • Page 11 SAFETY SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the Machine. If, at any time, the labels become illegible contact your authorized representative for prompt replacement. EMPLACEMENT DE L'ÉTIQUETTE DE SÉCURITÉ REMARQUE : Ces dessins indiquent l'emplacement des étiquettes de sécurité sur la machine.
  • Page 12: Technical Specifications

    Motor 1.5 hp Transmission Direct drive from motor shaft. Pad speed 2000 rpm Electrical system: LB2000I, LB2000IA 230 volts, 50Hz LB2000, UB2000F 115 volts, 60Hz 75’ [22.9 m] Cable Switches Dual levers with safety lock. ∅20” [50.8 cm] flexible disc Pad Holder Four ∅5”...
  • Page 13: Handle Installation

    OPERATION HANDLE ASSEMBLY HANDLE MOUNT BRACKET DECK ASSEMBLY HANDLE INSTALLATION The machine is shipped with handle unassembled. 4. Slide Bolt (item 3) through, washers (item 2), Handle Mount Brackets and Handle Assembly as Follow these steps for installation: shown. Tighten bolt (item 3) and nut (item 1) until the handle cannot twist in the mount bracket (45- 1.
  • Page 14: Operation

    OPERATION 5. With the safety lock forward, squeeze one or CONTROLS both of the switch levers, turning the machine on. (These levers can be operated 1. Safety Lock – Prevents unintended operation independently of each other). The safety lock of the machine. will not re-engage until both levers are released.
  • Page 15: Maintenance

    MAINTENANCE MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Tripped circuit breaker Reset Circuit breaker tripped in Check and reset building. Fuse in motor is blown Replace CAUTION: To reduce the risk of electrical shock, unplug the machine before opening fuse holder. Machine will not run Fuse will only open under extreme conditions.
  • Page 16: Wiring Diagram/Service Schedule

    MAINTENANCE SERVICE SCHEDULE MAINTENANCE DAILY MONTHLY Check pad wear to prevent buildup of chemicals Check pad driver system for damage Check handles, switches, and knobs for damage Store with pad off the floor Check all bearings for noise Check skirt/bumpers for damage and replace as necessary Check overall performance of machine 86309600 (2000) BURNISHER 10/08/08...
  • Page 17 NOTES: 86309600 (2000) BURNISHER 10/08/08...
  • Page 18 DECK 6A-B 86309600 (2000) BURNISHER 10/08/08...
  • Page 19 86223430 67463 RETAINER, CORD 86276810 70738 SCR, M5 X .8MM X 10 MM PPHMS BLK LB2000, 86217640 29244BLU DECK, 20 IN BURNISHER, BLUE LB2000I, LB2000IA 86289010 29244GRY DECK, 20 IN BURNISHER, GRY UB2000UF 86216270 140423 BUMPER, EXTRUSION 86137340 87211 WASHER, M6 FLAT BLK...
  • Page 20: Electrical

    ELECTRICAL 14 A-B 13 A-C 86309600 (2000) BURNISHER 03/31/11...
  • Page 21 BOOT, 3/8 CIRCUIT BREAKER LB2000, 86234140 23154 CORD SET, 14/3 ST C 75’ YLW UB2000F CORD SET, EURO 1.5MM X 75 86216950 23212 LB2000I 86216970 23217 CORD SET, SAA/3 1.5MM X 75 LB2000IA LB2000, 86312460 BREAKER, 14A, VDE CIRCUIT UB2000F...
  • Page 22: Handle-Lower

    HANDLE-LOWER 86309600 (2000) BURNISHER 10/08/08...
  • Page 23 HANDLE-LOWER PART SERIAL DESCRIPTION NOTES: 86276810 70738 SCR, M5 X .8MM X 10 MM PPHMS BLK 86198450 20005 CLAMP, 5/16 NYLON 86223490 67468 RING, 10MM EXT SNAP, DIN 471 86222570 66340 PIN, DOWEL 10MM DIA X 124 MM LG 86215480 140421 BRACKET, HANDLE LINK 86223500...
  • Page 24: Handle-Upper

    HANDLE-UPPER 86309600 (2000) BURNISHER 10/08/08...
  • Page 25 HANDLE-UPPER SERIAL PART NO. DESCRIPTION NOTES: 86136670 70686 SCR, M6 X 45 SHCS BLK 86136680 70687 SCR, M6 X 50 SHCS BLK 86224740 73990 SPRING, EXT, .50D X 3.5L 86225370 78437 TUBE, GRIP HANDLE 86004070 36196 GRIP, POLISHER HANDLE 86005160 51327 LEVER, SWITCH 86136350...
  • Page 26: Motor

    MOTOR 1 A-B 86309600 (2000) BURNISHER 05/30/12...
  • Page 27 PART SERIAL NO. DESCRIPTION NOTES: FROM MOTOR, 115V 1.5HP 86312260 LB2000, UB20000F 20000RPM MOTOR, 230V 1.5HP 86312250 LB2000I, LB2000IA 20000RPM 86217490 27884 COVER, MOTOR 1.25HP 86223690 70702 SCR, M5 X .8 X15MM BLK WASHER, 3/8 SPLIT LOCK 86010790 87163 PLTD SCREW 3/8-16 X 1"...
  • Page 28: Pad/Driver

    PAD/DRIVER 5-11 86309600 (2000) BURNISHER 05/30/12...
  • Page 29 PAD/DRIVER PART SERIAL NO. DESCRIPTION NOTES: FROM 86010720 87086 WASHER, M10 X 30 PLTD SCREW 3/8-16 X 1" 86006740 70266 HHCSGR5PLT DL PAD DRIVER, 20 INCH INCLUDES ITEMS 86222470 64108 BURNISHER 6 & 7 86279210 87102 WASHER, 5/16 ID X 1-1/4 OD 86274590 70244 SCR, 5/16-24 X 1/2 HHMS SS...
  • Page 30: Wiring-120V

    WIRING-120V CORD SET -CB1 120V AC 15A -SWITCH -SWITCH -MOTOR SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES: FROM WIRE, 125MM, BLK/14, 86311830 76029X76029 5-13 86309600 (2000) BURNISHER 10/08/08...
  • Page 31: Wiring-230V

    WIRING-230V CORD SET -CB1 120V AC 15A EMC FILTER -SWITCH -SWITCH EMC FILTER2 -MOTOR SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES: FROM WIRE, 125MM, BLK/14, 86311830 76029X76029 5-14 86309600 (2000) BURNISHER 10/08/08...
  • Page 32: Suggested Spare Parts

    SUGGESTED SPARE PARTS SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES: FROM 86224740 73990 SPRING, EXT .5OD X 3.5L 86224750 73993 SPRING, COMP .48OD X .91L 86007110 72123 SWITCH, 25A SPST 125-250V SNAP 86312460 BREAKER, 14A, VDE CIRCUIT 120V 86291460 BREAKER, 11A, VDE CIRCUIT 230V 86223460...
