D
BATTERY PACK
Battery pack
Voltage
2250 mAh (min.)
BP-232WP
7.4 V
2300 mAh (typ.)
*
1
When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
2
Operating period depends on the alkaline cells used.
• BP-240/BP-261
battery case
BP-240:
Battery case for AAA (LR03) × 6 alkaline
BP-261:
Battery case for AA (LR6) × 6 alkaline
BP-240 and BP-261 have IPX4 waterproof protection. When in
use, the transceiver's waterproof rating meets IPX4.
D
CHARGERS
• BC-119N
desktop charger
+ BC-145S
ac adapter
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approximately 3 hours when BP-232WP is at-
tached.
• BC-121N
+ AD-106
-
multi
charger
+ BC-157S
ac adapter
For rapid charging of up to 6 battery packs (six AD-106's
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: approximately 3 hours when BP-232WP is at-
tached.
Capacity
Battery life*
1
17.5 hrs.
+ AD-106
charger adapter
(6 pcs.)
charger adapter
OPTIONS
• BC-160
+ BC-145S
desktop charger
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approximately 3 hours when BP-232WP is at-
tached.
• BC-171
+ BC-147S
desktop charger
An AC adapter is supplied with the charger depending on
versions.
Charging time: approximately 10 hours when BC-232WP is at-
tached.
D
DC CABLES
• CP-23L
cigarette lighter cable
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-160/BC-171/BC-119N)
• OPC-515L/OPC-656
dc power cables
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-160/BC-171/BC-119N
OPC-656 : For BC-121N
D
BELT CLIPS
• MB-93
swivel belt clip
• MB-94
belt clip
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
• MB-96N/96F
leather belt hanger
8
ac adapter
ac adapter
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
26
