Air King Professional Series Specifications

• Dimensions

Overall bottom projection: 18"
Height: 12"
Overall Width: 32"

• Hood

All metal Galvanized Steel with stainless steel fascia.

• Lighting

2 - PAR16 medium screw base, 45 watt maximum
Halogen lamps

• Ducting Options

Vertical or Horizontal ducting through ducting transi-
tion
(not included)

• Cut Out Opening Size

Width: 30.5"
Depth: 17.25"

• Filters

Grease Baffles: Dishwasher safe, Stainless Steel
baffles
(included).

• Available Finishes

Stainless Steel
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice
Professional Series Insert
(not included).
specified for size of motor.
MODEL
PIN300
PIN500
PIN600
PIN900
PIN1200
1 All speed selections of control panel operated at same speed •
Breaker Size is listed at the recommended minimum size. Installation must be in accordance with all applicable codes and standards.
3
CFM = cubic feet per minute • Sones = sound level measurement
IN
RPM WATTS
W.C.

HVI CFM/SONES @ 0.1 WG

HIGH MEDIUM LOW
300/1.5 N/A N/A
1 1
500/4.5 N/A 300/1.5
2 2
600/5.5 500/4.5 300/1.5
900/11.0 600/5.5 400/2.0
1200/15.0 900/11.0 400/2.0
2 Speed selections II and III of control panel operate at same speed
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: West Chester, PA 19380
Phone: (877) 304-3785
Fax: (610) 696-8048
Email: sales@airkinglimited.com

SPECIFICATIONS

PIN
RANGE HOODS
12"
12"
32"
REQUIRED FULL LOAD
DUCT SIZE LIGHTING
6" round 2-45W Halogen
6" round 2-45W Halogen
6" round 2-45W Halogen
8" round 2-45W Halogen
10" round 2-45W Halogen
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: Brampton, Ontario L6T 2J3
Phone: (905) 456-2033
Fax: (905) 456-1015
Email: casales@airkinglimited.com
4"
18"
BREAKER
3
AMPS SIZE
1.7 amps 15 amp
1.9 amps 15 amp
2.1 amps 15 amp
6.5 amps 15 amp
8.0 amps 15 amp
New 2-09
