Air King P1836 Specifications

Professional Series 18" Height
• Hood Dimensions
Overall bottom projection - 24"
Available height
(less Soffit)
Available widths: 36", 42" and 48"
• Hood
Stainless steel. Wall mounted. Install at least 24" above the
cooking surface.
• Lighting
36" widths: 2 - PAR16 medium screw base, 45 watt maximum
Halogen lamps
42", 48" widths: 3 - PAR16 medium screw base, 45 watt maximum
Halogen lamps
• Heat Lamps
(models P1836W, P1842W, P1848W)
2 - 175 watt maximum Type PAR38 heat lamps

• Ducting Options

Vertical or Horizontal ducting through ducting transition
specified for size of motor.
(not included)
• Filters
Grease Baffles: Dishwasher safe, Stainless Steel baffles
Model Description
P1836 Range Hood
P1842 Range Hood
P1848 Range Hood
36"
Full Load Breaker
Motor Size Amps
300 CFM 1.7 amps
500 CFM 1.9 amps
600 CFM 2.1 amps
900 CFM 6.5 amps
1200 CFM 8.0 amps
Breaker Size is listed at the recommended minimum size. Installation must be in accordance with all applicable codes and standards.
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
Wall Mounted Range Hood
-18"
.
(not included)
.
(not included)
(not included)
Width Height
36" 18"
42" 18"
48" 18"
36" w/Heat Lamps
Full Load Breaker Full Load
Size Amps Size
15 amp 5.9 amps 15 amp
15 amp 6.1 amps 15 amp
15 amp 6.3 amps 15 amp
15 amp 10.7 amps 15 amp
15 amp 12.2 amps 20 amp
IN
RPM WATTS
W.C.
.
.
(included)
Model Description
P1836W Range Hood w/Heat Lamps
P1842W Range Hood w/Heat Lamps
P1848W Range Hood w/Heat Lamps
POWER USAGE
42" 42" w/Heat Lamps
Breaker Full Load
Amps Size Amps
2.2 amps 15 amp 6.3 amps
2.4 amps 15 amp 6.5 amps
2.5 amps 15 amp 6.7 amps
7.0 amps 15 amp 11.1 amps
8.5 amps 15 amp 12.6 amps
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
PROFESSIONAL
RANGE HOODS
P18 SERIES
18"
24 "
36", 42", 48"
Width Height
36" 18"
42" 18"
48" 18"
48"
Breaker Full Load Breaker Full Load
Size Amps Size
15 amp 2.2 amps 15 amp
15 amp 2.4 amps 15 amp
15 amp 2.5 amps 15 amp
15 amp 7.0 amps 15 amp 11.1 amps
20 amp 8.5 amps 15 amp 12.6 amps
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
48" w/Heat Lamps
Breaker
Amps Size
6.3 amps 15 amp
6.5 amps 15 amp
6.7 amps 15 amp
15 amp
20 amp
New 3-08
