Page 1: Operating Instructions
Room Air Conditioner OPERATING INSTRUCTIONS HP21WC-Cooling Only HP21WR-Reverse Cycle Thank you for selecting Hotpoint air conditioners. Please read this manual carefully before operation and keep it for further reference. -
Page 3: Table Of Contents
CONTENTS Thank you for choosing a Hotpoint air conditioner. Our design is based on the best efficiency and the lowest noise operation and it can keep the room comfortable. Please read this operating manual carefully before operating the unit and keep it for consultation. -
Page 4: Function
Function Introduction Autumn Window type room air conditioners of Hotpoint can regulate the room Spring Summer Winter Room temperature and dry the room. It is convenient for your work,study temp. and life. It can be widely used in residence, shop, hotel, office, library and laboratory, and so on. -
Page 5: Operating Condition
Operating Condition Please operate air conditioner in the correct conditions as follows. DRY mode operation COOL mode operation to 43 , Outdoor temperature should be in range of 18 Outdoor temperature should be in range of 18 to 43 , otherwise it is possible for air conditioner otherwise it is possible for air conditioner to breakdown. -
Page 6: Installation
Please consult with a licenced technician to install the unit and don’t install it by yourself. Hotpoint is not responsible for incorrect installation. Location: The condensation water must be drained away conveniently. -
Page 7: Installation Procedure
Installation procedure: Horizontal line 1) Remove the sticker from the front panel. 2) Put the unit into the installation hole. When installing the unit, it should be slanted down to the back to avoid the enlargement of noise or vibration. (Slant between 6-10mm.) (Shown at right figure.) The installation place should be strong enough to avoid the enlargement of noise or vibration. -
Page 8: Notes For Installation
Note: Drain pan and drain hose must be installed before using reverse cycle models. Drain hose or tubing can be purchased locally to satisfy your particular needs. Notes for installation Remove Before removing air conditioner to another place, you should contact the installer first. -
Page 9: Part Identification
PART IDENTIFICATION Cabinet Air inlet louver Front grille Front intake grille) Power cord Air filter Control panel (behind the front intake grille) Cabinet Air inlet louver Front grille Front intake grille) Remote control panel Power cord Air filter (behind the front intake grille) Air direction adjustment Vertical airflow direction vane (Airflow direction adjustment up and down). -
Page 10: Main Switch Operation Procedure
Main switch operation procedure 1.Only Cooling 1.Main Control Knob Set to Low Cool,Med Cool or High Cool as desired (FAN setting operates the fan only.) CAUTION:If the main control knob is turned off of changed to a fan setting from a cooling operation setting. WAIT at teast 3minutes before resetting to cooling operation. -
Page 11: Operation Of Wireless Remote Control
Operation of wireless remote control Name and function of wireless remote control Note: Besure that there are no obstructions between receiver and remote controller; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. - Page 12 Name and function of wireless remote control Note: This wireless remote control is universal, and it could be used for many units, some buttons of this control which are not available to this unit will not be described below. + button ●...
- Page 13 Name and function of wireless remote control Note: This wireless remote control is universal, and it could be used for many units, some buttons of this control which are not available to this unit will not be described below. TIMER ON TIMER ON BUTTON ●...
- Page 14 Guide for operation- general operation 1. After powered on, press ON/OFF button, the unit will start to run.(Note: When it is powered off, the guide louver of main unit will close automatically.) 2. Press MODE button, select desired running mode, or press COOL or HEAT mode to enter into the corresponding operation directly.
-
Page 15: Changing Batteries And Notices
★ About swing up and down 1. Press swing up and down button continuously more than 2s,the main unit will swing back and forth from up to down, and then loosen the button, the unit will stop swinging and present position of guide louver will be kept immediately. -
Page 16: Ventilation Lever
Remote control panel Note: If wireless remote controller is lost, open the surface panel and operate manually. POWER BUTTON SIGNAL RECEIVER Operation starts when pressing this button, and stops when pressing this button again. MODE BUTTON SWING BUTTON Select the operation mode, AUTO, HEAT, COOL, FAN, Activate the automatic air swing function. -
Page 17: Operation Tips
Operation Tips Operation for comfort and economy Do not overcool the room Keep blind or curtains closed. Keep the room temp. uniform. temperature. This is not good Do not let sunshine enter the Adjust the vertical and horizon- for health and wastes electricity. room directly when the air con- tal airflow direction to ensure a dition is in operation. -
Page 18: Caution
Caution Operations for safety and health 1) The plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry. 3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in void of hazard. Do not pull out the power cord. -
Page 19: Care And Maintenance
Care and maintenance Always turn off the air conditioner and main power supply before cleaning to ensure safety. Cleaning unit Air filter 1. Cut power off before cleaning. The air filter behind the intake grille should be washed at least once every two weeks or as often as it needs cleaning. -
Page 20: Trouble Shooting Guide
Trouble shooting guide Please check the following items before asking for repair,it saves your time and money. Fault phenomenon Trouble-shooting * Is there a power failure? * Is the plug out? Air conditioner dose not * Is power fuse or switch off ? operate at all. -
Page 21: After Service
*Carelessly splash water or something into air conditioner; *Electrical lines are much hot or lines cover breaks; *Other strange situations. After service If your air conditioner has the questions of quality or anything else, please contact the Hotpoint National Service Department on 1300-303-929. - Page 22 Please retain this form and attach your receipt to it. Should you require any warranty service, please check the fault finding chart at the back of this manual first and then contact Hotpoint National Service Department on 1300-303- 929 who will appoint an authorised Service Agent to assist you. You must have your receipt to claim warranty.
- Page 23 PROBLEMS THAT MAY NOT BE COVERED UNDER WARRANTY Hotpoint (Aust) Pty Ltd reserves the right to refuse warranty if reported problems arise from situations outside their control. For example: Systems of inappropriate capacity for area(s) served, e.g. not sized by a method accepted as normal trade practice.
- Page 24 Hotpoint (Aust) Pty Ltd Web Site: www.hotpoint.com.au 66129905991...
