Maytag UXT4030AAB Repair Parts List page 3

Vent hood
Hide thumbs


Advertisement

Section:
BODY/INTERNAL PARTS
No.
Part No.
Description
1
47001055
COVER, OUTLET BOX
2
Y706189
SCREW Note: SCREW, COVER
3
47001056
RECEPTACLE, BULB
4
47001057
LENS, BULB
5
47001080
KIT, NUT & SCREW Note: (INCLD 2 #10-16 SCREWS
6
47001074
BLADE, FAN
7
Y03050041
NUT, HEX(MUST ORDER LOCALLY)
8 N 47001060
BRACKET, MOTOR
9
47001075
MOTOR ASSY. Note: (INCLD ITEM NO'S 6,7, & 8)
10
47001076
FILTER (DUCTFREE)
11
47001063
RETAINER, FILTER
12 N 47001065
LABEL, SWITCH (BLK) Note: PLATE, SWITCH (BLK)
13
47001066
SWITCH, MOTOR (BLK)
14
47001067
SWITCH, LIGHT (BLK)
15 N 47001068
RECEPTACLE, MOTOR
16
71001171
SCREW, GROUND
-
47001201
MANUAL, USE & CARE
*Color Code (-)=Not Shown
2 #10-16 NUTS)
#=Series, Serial Prefix or Run No., N=Not Available
2
Series Qty
1
2
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
