CUSTOM PACKAGED
ELECTRONIC
AIR CLEANER
Model 75 Series Units
WITHOUT
Wash System
INSTALLATION
•
OPERATION
•
SERVICE
•
For Model Numbers
75- ______-01 & -03
Electrostatic Precipitators for
Commercial & Industrial
Applications
101 McNeill Road • Sanford, NC 27330
(919) 775-2201 • Fax: (919) 774-8771 • (800) 884-0002
www.trioninc.com
MANUAL PART NO. 154024-002•
Accepted For Use
City of New York
Department of Buildings
MEA 288-01-E and 88-99-E
July 2002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trion 75
Summary of Contents for Trion 75
-
Page 1: Air Cleaner
CUSTOM PACKAGED ELECTRONIC AIR CLEANER Model 75 Series Units WITHOUT Wash System Accepted For Use INSTALLATION • City of New York OPERATION • Department of Buildings MEA 288-01-E and 88-99-E SERVICE • For Model Numbers 75- ______-01 & -03 Electrostatic Precipitators for Commercial &... -
Page 2: Table Of Contents
General Component Arrangement............12 Figure 2 High Voltage Lead Terminal Connections ......... 13 Figure 3 Typical Outdoor Installation..............14 Figure 4 Model 75 Junction Box… ..............15 Figure 5 Unit Outline ..................16 Figure 6 ATS Control Outline (STANDARD) ............I7 Figure 7 ATS PWM Remote Box (OPTIONAL) .......... -
Page 3: Section I Design
Note: Trion Tridex Detergent is specially formulated controller is located near the air cleaner. Ideal mounting for use with Trion electronic air cleaners. Use of height is at eye level for ease in reading the other cleaners and detergents, not specifically instrumentation, and to facilitate service. -
Page 4: Outdoor Installations
A minimum of 39 inches is Trion Model 75 Cabinet required. (see figure 5) The access doors on the Model 75 cabinet are gasketed (b) Level the cabinet to assure proper drainage from and the unit is basically sealed against air leakage. The the drain pan. -
Page 5: Connect Drain
B. The drain line from the Trion drain basin is clear and from evaporation between cleaning periods will not completely connected to its point of termination. -
Page 6: General Description
A. Inspect the inside of the adjoining ductwork and blades spaced between grounded electrodes. The Trion cabinet to be sure it is clean and free of any collecting section consists of parallel plates arranged so debris or construction materials. Especially note the that each alternate plate is charged while the opening in the drain basin for any restrictions. -
Page 7: Routine Maintenance
Trion, Inc., is formulated EXCESSIVE ARCING. specifically for electronic air cleaners. If substitutes are used, they must be approved by Trion, so as to not void the warranty and should be safe for use in ventilation systems and non-caustic, as 95% of the D. -
Page 8: Troubleshooting
When a cleaning service is used, a certificate power supply and the ionizing-collecting cell(s) they energize. The quantity of power supplies per unit is showing dates of inspection and/or cleaning shall be dependent upon unit size with one or two power maintained on the premises. -
Page 9: Spare Parts
For specific recommendations, consult the Trion factory The trouble can then be isolated to, a single cell, or the or nearest Sales Office. Consideration, however, should ionizing or collector section of a given cell as follows: be given to stocking the following components;... -
Page 10: Troubleshooting Reference Chart
Troubleshooting Reference Chart PROBLEM/ PROBABLE LOCATION REASON - CORRECTION SYMPTOM CAUSE Ionizing Section of Cell Dirty insulator(s) – Clean Defective insulator(s) – Replace Foreign Object Between Ionizing Bar and Ground electrode - Remove Collecting Section of Cell Dirty insulator(s) - Clean Defective insulator(s) –...
