Summary of Contents for Trion Air Boss M-Series
- Page 1 A i r P u r i f i c a t i o n S y s t e m s Air Boss M-Series ® Media & Adsorption Air Cleaner A i r P u r i f i c a t i o n S y s t e m s | w w w. t r i o n i n c . c o m...
-
Page 2: Features And Benefits
Engineered Solutions For Clean Air Trion’s Air Boss media units are industrial air cleaners designed for both general ventilation (removal of airborne pollutants from plant atmospheres) or source capture (ductwork or arms positioned at the origin of pollutants). These units help solve welding smoke,... -
Page 3: Specifications
Air Boss Specifications M2500 Dimensions 47" L x 23.9" W x 23.6" H Installation Weight 180 Lbs./Shipping 250 Lbs. Electrical: .75hp: 120vac/60/1ph Standard 10.5 AMPS Optional Motors: Standard Thermally Protected Blowers: Standard Direct Drive, Forward Curved Optional Air Volume (CFM) 1240-2010 Controls 3-Speed Selector Switch Sound Rating 50-70 dBA @ 5 Ft. 4 Inch 35% Pleated (Standard) Pre Filters: Polyester Pad (Optional) 3-Way Wrap Around (Optional) 95% Bag Filter (Standard) Primary 65% Bag Filter (Optional) Secondary Gauge Kit Silencer (Optional) Specification for Each Unit... - Page 4 Media and Adsorption Air Cleaner Dimensions M2500 Top View Front View Dimensions M3000 Top View Front View w w w. t r i o n i n c . c o m Intake End End Discharge Intake End End Discharge...
-
Page 5: Air Delivery
Dimensions M6000 Top View Front View Air Delivery M3000 PRE-FILTER: 4" PLEATED PRIMARY FILTER: 95% BAG MOTOR TURNS BLOWER BLOWER PULLEY OPEN PULLEY 1151 1218 2 H.P. 1286 1354 1422 1489 1273 1348 3 H.P. 1423 1498 1573 1648 1000 1500 2000 2500... - Page 6 Industrial Applications Guide Industrial Applications Dusts Smoke & Fumes Atmospheric Burn Room Testing Exhaust General Ventilation Metal Forming: Tobacco • Cold Heading Rubber • Warm Fogging Silica Injection Molding Plastic/Epoxy Rubber Curing Fiberglass Drying Ovens Mica Heat Treating Textile Indoor Firing Range Dried Automotive Body Putty Kitchen Exhaust Talcum Powder Plasma Cutting Paper Soldering Spices Tobacco Toner Torch Cutting Wood (light loadings) Welding Fly Ash...
- Page 7 Industrial - Wet Particulate Typical Heating & Air Conditioning Systems Application Oil Mist/Smoke Coolants Arms, Portable Units Oily Welding Fume Ambient Capture Industrial - Dry Particulate Typical Heating & Air Conditioning Systems Application Process Dust Powders Grinding Fumes Arms, Portable Units Welding Fumes Smokes Ambient Capture Industrial Applications Guide Equipment 800-20,000 CFM Medium Central System 2,000-25,000 CFM Heavy 8,250-Infinite CFM Heavy 2,000-10,500 CFM Heavy Equipment...
- Page 8 Our Media Air Cleaners come with a three-year limited warranty. Learn more about other Trion industrial products by contacting your local Trion representative or by visiting us on the web at DC Cartridge Dust Collector ww w. T RI O NI N C. c o m Mini M.E.
