User Manual
User Manual
VS-291/VS-491
Read this guide thoroughly and follow the installation and
operation procedures carefully in order to prevent any damage to
the units and/or any devices that connect to them.
This package contains:
w 1 Video Switch (VS-291; or VS-491)
w 1 DC 9V Power Adapter
w 1 User Manual
If anything is damaged or missing, contact your dealer.
Copyright © 2002 - 2006 ATEN® International Co., Ltd.
Manual Part No. PAPE-1181-100
Printing Date: 03/2006
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.
