- Page 1 8-Port HDMI Switch USER MANUAL VS0801H...
-
Page 2: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. -
Page 3: Online Registration
VS0801H User Manual Online Registration You can register your product at our online support center: International http://support.aten.com North America http://www.aten-usa.com/product_registration Online Support International Email Support support@aten.com Online Technical Support http://support.aten.com Support Troubleshooting http://www.aten.com Documentation Software Updates Telephone Support 886-2-8692-6959 North America... -
Page 4: Package Contents
Copyright © 2009 - 2010 ATEN International Co., Ltd. Manual Part No. PAPE-1333-100G Printing Date: 2010-09-16 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 HDMI A/V sources that are connected to your HDMI display. With eight HDMI A/V input ports, the VS0801H 8-port HDMI Switch allows you to connect eight HDMI devices (such as an HD camcorder or satellite box, HD-DVD player, hi-def Blu-ray player, home theater PC, stand-alone streaming media player, gaming console, etc.) to your HDMI monitor, display, projector or TV at...
- Page 6 Signaling rates up to 2.25 Gbits in support of 1080p display. All-metal casing Power On Detection – if one of the HDMI source devices is powered off, the VS0801H will automatically switch to the next powered on device Easy and affordable way to add eight HDMI inputs to your...
-
Page 7: System Requirements
Contact your dealer to purchase the correct cable sets. 2. If you wish to utilize the VS0801H’s high-end serial controller function, you will also need to purchase an appropriate RS-232 cable. See Installing the RS-232 Controller, page 11. - Page 8 Components VS0801H Front View Component Function Port Selection Pressing a port selection pushbutton Pushbuttons routes the HDMI source from the corresponding input port to the output port for display. Port LEDs There is one port selected LED next to each port selection pushbutton. This lights green to indicate that the corresponding port has been selected.
- Page 9 VS0801H Rear View Component Function HDMI In The cables from the HDMI source devices plug into any of the eight available ports. Power Jack The power adapter cable plugs in here. HDMI Out The cable from the HDMI display device plugs in here.
-
Page 10: Ir Remote Control
IR Remote Control ON / OFF Component Function Port Up / Port Press the Port Up button to cycle forward Down Buttons through the source devices (1 to 2; 2 to 3; ... 8 to 1). Press the Port Down button to cycle backward through the source devices. -
Page 11: Installation
Installing the RS-232 Controller In order to use the RS-232 serial interface to attach a high-end controller (such as a PC) to the VS0801H, use a serial cable such as a modem cable. The end connecting to the VS0801H should have a 9-pin male connector. -
Page 12: Installation Diagram
Installation Diagram HDMI Output Device Hardware / Software Controller HDMI Source Devices - 12 -... -
Page 13: Manual Selection
Source Device Selection The VS0801H 8-port HDMI Switch offers easy and flexible source device selection with either the front panel pushbuttons, with the remote control, or through the RS-232 serial interface. Note: Whenever the VS0801H is powered on, it automatically selects the first port connected to a powered on source device. -
Page 14: Rs-232 Serial Interface
RS-232 Serial Interface The VS0801H’s built-in bi-directional RS-232 serial interface allows system control through a high-end controller, PC, and/or home automation / home theater software package. Configuring the Serial Port The controller’s serial port should be configured as follows: Baud Rate... -
Page 15: Serial Commands
Serial Commands The VS0801H’s serial commands are as follows Packet Format Control Function Start Data Head Function Data Checksum Protocol Code Length Code Switch to 0x5A Port Switch to Last 0x00 0x81 0x81 Last Port 0x7E Code Port 0x00 0xA5... -
Page 16: Powering Off And Restarting
2. Unplug the power adapter cable from the VS0801H. 3. Wait 10 seconds, and then plug the power adapter cable back 4. After the VS0801H is powered on, power on the attached devices. Note: Whenever the VS0801H is powered on, it automatically selects the first port connected to a powered on source device. -
Page 17: Specifications
Specifications Function VS0801H Display Connections Connectors Device HDMI In 8 x HDMI Type A Female (Black) Display HDMI Out 1 x HDMI Type A Female (Black) RS-232 Port 1 x DB-9 Female (Black) Power 1 x DC Jack LEDs Selected... -
Page 18: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
