AIR INTAKE ASSEMBLY . . . . . . . . . . . . . . . . . . 15 . . . . . . . . . . . E10
BATTERY ASSEMBLY . . . . . . . . . . . . . . . . . . . 16 . . . . . . . . . . . E11
BODY PANEL ASSEMBLY . . . . . . . . . . . . . . . . . . 1 . . . . . . . . . . . D10
CAM CHAIN ASSEMBLY . . . . . . . . . . . . . . . . . . 30 . . . . . . . . . . . F11
CAM SHAFT VALVE ASSEMBLY . . . . . . . . . . . . . 29 . . . . . . . . . . . F10
CARBURETOR . . . . . . . . . . . . . . . . . . . . . . . 21 . . . . . . . . . . . . F2
CLUTCH ASSEMBLY . . . . . . . . . . . . . . . . . . . . 34 . . . . . . . . . . . . G1
CONTROL SWITCH HOUSING ASSEMBLY . . . . . . . . 45 . . . . . . . . . . . G12
COOLING ASSEMBLY . . . . . . . . . . . . . . . . . . . 18 . . . . . . . . . . . E13
CRANK BALANCER ASSEMBLY . . . . . . . . . . . . . . 28 . . . . . . . . . . . . F9
CRANKCASE ASSEMBLY . . . . . . . . . . . . . . . . . 24 . . . . . . . . . . . . F5
CRANKCASE COVER ASSEMBLY
CRANKSHAFT ASSEMBLY . . . . . . . . . . . . . . . . 26 . . . . . . . . . . . . F7
CYLINDER ASSEMBLY
CYLINDER HEAD ASSEMBLY . . . . . . . . . . . . . . . 22 . . . . . . . . . . . . F3
DECALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 . . . . . . . . . . . D12
ELECTRICAL COMPONENTS ASSEMBLY . . . . . . . . 44 . . . . . . . . . . . G11
ENGINE AND EXHAUST . . . . . . . . . . . . . . . . . . 17 . . . . . . . . . . . E12
FRAME AND RELATED PARTS . . . . . . . . . . . . . . . 4 . . . . . . . . . . . D13
FRONT SUSPENSION ASSEMBLY . . . . . . . . . . . . . 7 . . . . . . . . . . . . E2
FUEL TANK ASSEMBLY . . . . . . . . . . . . . . . . . . 13 . . . . . . . . . . . . E8
GEAR SHIFTING ASSEMBLY . . . . . . . . . . . . . . . 39 . . . . . . . . . . . . G6
HYDRAULIC BRAKE ASSEMBLY . . . . . . . . . . . . . 12 . . . . . . . . . . . . E7
HYDRAULIC BRAKE CONTROL ASSEMBLY . . . . . . . 11 . . . . . . . . . . . . E6
MAGNETO ASSEMBLY
MECHANICAL BRAKE ASSEMBLY . . . . . . . . . . . . 10 . . . . . . . . . . . . E5
OIL FILTER/PUMP ASSEMBLY . . . . . . . . . . . . . . 32 . . . . . . . . . . . F13
REAR AXLE ASSEMBLY . . . . . . . . . . . . . . . . . . 19 . . . . . . . . . . . E14
REAR BEVEL GEAR ASSEMBLY . . . . . . . . . . . . . 41 . . . . . . . . . . . . G8
REAR SUSPENSION ASSEMBLY . . . . . . . . . . . . . . 8 . . . . . . . . . . . . E3
RECOIL STARTER ASSEMBLY . . . . . . . . . . . . . . 31 . . . . . . . . . . . F12
RELATED ITEMS . . . . . . . . . . . . . . . . . Back Cover . . . . . . . . . . . G14
REVERSE SHIFT LEVER ASSEMBLY . . . . . . . . . . . 14 . . . . . . . . . . . . E9
SEAT ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . 5 . . . . . . . . . . . D14
SECONDARY DRIVE ASSEMBLY . . . . . . . . . . . . . 38 . . . . . . . . . . . . G5
SECONDARY TRANSMISSION ASSEMBLY
SHIFTER ASSEMBLY . . . . . . . . . . . . . . . . . . . 40 . . . . . . . . . . . . G7
SPEEDOMETER DRIVE ASSEMBLY . . . . . . . . . . . 37 . . . . . . . . . . . . G4
STARTER CLUTCH ASSEMBLY . . . . . . . . . . . . . . 27 . . . . . . . . . . . . F8
STARTER MOTOR ASSEMBLY . . . . . . . . . . . . . . 42 . . . . . . . . . . . . G9
STEERING ASSEMBLY . . . . . . . . . . . . . . . . . . . 6 . . . . . . . . . . . . E1
TAILLIGHT ASSEMBLY
THROTTLE CASE ASSEMBLY . . . . . . . . . . . . . . . 46 . . . . . . . . . . . G13
TRANSMISSION ASSEMBLY . . . . . . . . . . . . . . . 35 . . . . . . . . . . . . G2
WATER PUMP ASSEMBLY . . . . . . . . . . . . . . . . 33 . . . . . . . . . . . F14
WHEEL AND TIRE ASSEMBLY . . . . . . . . . . . . . . . 9 . . . . . . . . . . . . E4
WIRING HARNESS ASSEMBLY . . . . . . . . . . . . . . 20 . . . . . . . . . . . . F1
NOTE:
© 2001 Arctic Cat Inc.
®™ Trademarks of Arctic Cat Inc., Thief River Falls, MN 56701
BEARCAT ATV 2X4
(Model No. 97A2A-AP)
Table Of Contents
. . . . . . . . . . . . . . . . . . 23 . . . . . . . . . . . . F4
. . . . . . . . . . . . . . . . . . 43 . . . . . . . . . . . G10
. . . . . . . . . . . . . . . . . . . 2 . . . . . . . . . . . D11
The illustrations used in this Parts Manual are for reference to replacement part
numbers only and are not to be used for assembly. For assembly procedures, use
Arctic Cat Service Manuals.
Underlined part numbers are new for the 1997 model year.
. . . . . . . . . . . . 25 . . . . . . . . . . . . F6
. . . . . . . 36 . . . . . . . . . . . . G3
A2
Printed September 2001
