CANISTER PERFORMANCE
INDICATOR
SOME MODELS
Canister
Performance
Indicator Light
The light comes on
whenever the airflow
becomes blocked.
dust bag needs
changing or canister
safety filter needs
cleaning.
NOTE:The light may also come on when using certain
affachments, due to reduced airflow through
attachment,
PERFORMANCE INDICATOR
SOME MODELS
When the unit is running the
lines in the indicator windows
will be clear if there ore no
clogs. When the lines turn
completely red there is a
need to check the dust bag for being full or the other
areas that may be clogged. See HOW YOUR VACUUM
WORKS.
NOTE: Red lines may appear when using
attachments or when cleaning new carpet, due to
reduced airflow by the attachments themselves or
new carpet fuzz filling the bag quickly.
POWER-MATE
TM
STORAGE
SOME MODELS
The lower wand
has a "U" shaped
flange in the area
where the power
cord attaches.
The base has a
"U" shaped slot
near the front
caster.
The flange allows
the wands and
POWER-MATE
TM
to be sTored
with the canister
to conserve
storage space.
The canister must
be stored on end
for this feature to
be used.
The wand will slip out of the slot as it is Nfted up for use
and wNIslide into the slot as it is lowered for storage.
YOURVACUUMWORKS
The vacuum cleaner creates suction that _ _..Jt[_l_J_ _WIUI_I
picks up dirt. Rapidly moving air carries /i_ ")
the dirt to the dust bag through the ! .._"_._ The hose swivel ailows the /%%.
airflow, passages. The dust bag ,ets L_ .._--_ hose to turn without _it,/_<'.-_c _._ _ ./_'_'_--_ _"_ J-_""_"
..... t ,ll i1.
the air pass through, while it traps _ "_ moving the canister This
K_, ?j3_l_ . F_'_ L ', \_v
the dirt, //'_" is helpful for cleaning in 'k,_l!i _ liY"
. small areas Check hose '\_ " "
For best cleaning results, keep ///_//_" J ..... : " Ilin
?
th al low a S 0 en fortwlsTIngoeforepu g
e rf p sage p . //zi/ / '< r _
Check the starred areas //e_// lj canisTe .
occasionally for clogs. /_e_'/ I1
Unplug fro o let /#/7 I t -
13
