1 . 1 . 7 F r o n t a n
1 . 1 . 7 F r o n t a
LED
ACT (Activity)
ISDN
Phone
(FXS1, FXS2)
WLAN
Printer
WAN
LAN (1, 2, 3, 4)
Interface
Printer
PWR
0/1
FXS 2 - 1
P1 – P4
WAN
Factory Reset
8
d R e a r V i e w f o
n d R e a r V i e w f o
Status
Blinking
On
Blinking
On
Blinking
On
Blinking
On
Orange
Green
Blinking
Orange
Green
Blinking
Description
Connecter for a USB printer.
Connecter for a power adapter.
Power Switch.
Connecter of analog phone for VoIP communication.
Connecter for local networked devices.
Connecter for remote networked devices.
Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and
keep for more than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
r V i g o r 2 9 0 0 V G i
r V i g o r 2 9 0 0 V G i
Explanation
The router is powered on and running properly.
The ISDN network is correctly setup.
A successful remote connection on the ISDN BRI
B1/B2 channel.
The phone is off hook (the handset of phone is
hanging).
A phone call is incoming.
The wireless LAN function is enabled.
Ethernet packets are transmitting over wireless LAN.
The USB interface printer is ready.
A normal 10Mbps WAN link is ready.
A normal 100Mbps WAN link is ready.
Ethernet packets are transmitting.
A normal 10Mbps connection is through its
corresponding port.
A normal 100Mbps connection is through its
corresponding port.
Ethernet packets are transmitting.
