Installation Instructions
INSTALLING OPTIONS
COOKTOP INSTALLATION WITH
A GE OR GE MONOGRAM 30"
DOWNDRAFT VENT
The installation of the downdraft vent with
this cooktop requires careful consideration.
Both the cooktop and the vent must be installed
according to each specific installation instruction.
COOKTOP REQUIREMENTS
The countertopmust have a deep flat surfaceto
accommodate the cooktop and vent.Countertops
with a rolled front edge and backsplash will not
providethe flat surfacearea required.
• Review the illustration to determine the countertop
surface requirements.
- All cutout clearances for this installation must
be observed.
!-3/4" Min. Cooktop Cutout to Rear
Vertical Combustible Surface
B6-1/8" (SS)
36" (B,W)
3/4"
f 2-_/a"
21-3/ "
Cutout
Depth 19-1/8"!
Cooktopi
Cutout
Depth
Cooktop and Vent Cutout
i-i/32" at Center
Front Edge
of Countertop
" 1/4" Overlap
',__t i/8 Gap,
23" (SS)
22-7/8" (B,W)
Total Flat
Surface
Required
2-!/2" Min. 2" M _in.cu
Clearance to Cutout . tout
to Side Walls
BASE CABINET REQUIREMENTS
The combined installation will fit in a standard
24" deep base cabinet. Use a 36" or wider base
cabinet.
- The vent housing, blower and ductwork will
occupg the base cabinet.
2-i/2" to
Cutout
1-7/8"
B/4"
Thick
Support
Rail
_22" to Support Rai_
