GE JP336SDSS Dimensions And Installation Information

JP336SD
GE 30" Built-In Clean Design Electric Cooktop
Dimensions and Installation Information (in inches)
Important: Requires a 5" free area between the
bottom of the cooktop to any combustible material,
i.e., shelving. Free area not required when installing
wall oven underneath cooktop. Refer to installation
instructions. Requires a 15" minimum from cooktop
to adjacent overhead cabinets. Units are furnished
with a 48" flexible armored cable.
Note: 30" Ribbon cooktops are approved for use
over select GE 27"and GE 30" Single Wall Ovens
and Warming Drawers. Refer to cooktop and wall
oven/warming drawer installation instructions
packed with product for current dimensional
data. If installed with a GE Telescopic Downdraft
System, consult both the cooktop and downdraft
installation instructions packed with product before
installing. Cooktop gas/electric supply may need to
be re-routed to install downdraft. The countertop
cutout requires 23-1/2" minimum flat countertop
surface and 25" minimum total countertop depth.
In addition, other clearances to front edge of the
countertop must be considered. Consult cabinet and
countertop manufacturer's specs for flush mount
installation priorto install.
Before installing, consult installation instructions
packed with product for current dimensional data.
Filler Trim Kit: When replacing an old GE 30"
cooktop (with larger opening) use the following one-
piece trim kit to fill in the over-size hole. Available at
additional cost. JXTR32B (Black)

KW Rating

240V 7.4
208V
5.6

Breaker Size

240V 40 Amps
†
Note: Check local codes for
†
208V
30 Amps
†
required breaker size
For answers to your Monogram
®
questions, visit our website at geappliances.com
or call GE Answer Center service, 800.626.2000.
®
or GE appliance
* ADA qualified based
*
on Uniform Federal
Accessibility Standards
Specification Created 10/12
Listed by
Underwriters
Laboratories
321371
