S15i
Multimedia Projector
Operator's Guide
Thank you for purchasing this projector.
WARNING
manuals to ensure correct usage through understanding. After reading, store
them in a safe place for future reference.

About this manual

Various symbols are used in this manual. The meanings of these symbols are
described below.
WARNING This symbol indicates information that, if ignored, could possibly
result in personal injury or even death due to incorrect handling.
CAUTION
This symbol indicates information that, if ignored, could result
possibly in personal injury or physical damage due to incorrect
handling.
Please refer to the pages written following this symbol.
NOTE • The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual.
• The reproduction, transmission or use of this document or contents is not permitted without
express written authority.
Trademark acknowledgment
• VGA and XGA are registered trademarks of the International Business Machines
Corporation.
• Apple and Mac are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of the Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
• Internet Explorer is a trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.
© 3M 2006
3M™ Digital Projector S15i
Before using, read the "Product Safety Guide" and these
1

Advertisement

Table of Contents
loading

Related Manuals for 3M Multimedia Projector S15i

Summary of Contents for 3M Multimedia Projector S15i

  • Page 1: About This Manual

    • VESA and SVGA are trademarks of the Video Electronics Standard Association. • Windows is a registered trademark of Microsoft Corporation. • Internet Explorer is a trademark of Microsoft Corporation. All other trademarks are the property of their respective owners. © 3M 2006 3M™ Digital Projector S15i...

  • Page 2: Table Of Contents

    Temporarily blanking the screen ..21 Technical(English only) Multifunctional settings ..22 (Please see the end of this book, Using the menu function ..22 although in English.) © 3M 2006 3M™ Digital Projector S15i...

  • Page 3: Projector Features

    VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY VOLUME MUTE FREEZE KEYSTONE ZOOM POSITION MENU ENTER RESET S15i VGA cable Power cord Operator's Guide Filter cover (US, UK, EUROPE) Product SafetyGuide Quick Start Guide Warranty © 3M 2006 3M™ Digital Projector S15i...

  • Page 4: Part Names

    Restart switch by using a cocktail stick or similar, and before turning on again, make the projector cool down at least 10 minutes without operating. Only push the Restart switch in these exceptional instances. © 3M 2006 3M™ Digital Projector S15i...

  • Page 5: Controls

    KEYSTONE Zoom ZOOM FREEZE button ( + button ( POSITION MENU POSITION button ( ENTER MENU button ( RESET Menu cursor buttons ESC button ( 18~40) 18~40) ENTER button ( RESET button ( © 3M 2006 3M™ Digital Projector S15i...

  • Page 6: Preparations

    Fix the strap to the strap ring of lens cover. Lens cover Strap Strap Strap ring Strap ring Strap ring Attach the lens cover to the lens of projector, and slowly turn over the projector, so that the top is facing up. © 3M 2006 3M™ Digital Projector S15i...

  • Page 7: Putting Batteries

    When putting in batteries, align and insert the two AA batteries according to their plus and minus terminals as indicated in the remote control. Close the battery cover. Replace the battery cover in the direction of the arrow and snap it back into place. © 3M 2006 3M™ Digital Projector S15i...

  • Page 8: Using The Remote Control

    • Since the remote control uses infrared light to send signals to the projector (Class1 LED), be sure to use the remote control in an area free from obstacles that could block the remote control’s output signal to the projector. © 3M 2006 3M™ Digital Projector S15i...
  • Page 9 Disconnect all the connectors and adapters that were connected to the up. Please be careful for a projector not to fall. While the projector is placed Filter cover’s knob Slowly turn the projector so that the bottom is facing up. Claws Tabs © 3M 2006 3M™ Digital Projector S15i...

  • Page 10: Setting Up

    • Don’t place the projector in a bathroom or the outdoors. • Put nothing containing the liquid near the projector. CAUTION projector. • • Put nothing containing the liquid near the projector. projector's remote sensor. © 3M 2006 3M™ Digital Projector S15i...

  • Page 11: Arrangement

    (131) 97.2 (38) (2.3) (148) 109.4 (43) (2.5) (165) 121.6 (48) (3.0) (198) 145.9 (57) (3.8) (248) 182.3 (72) (5.1) (331) 243.1 (96) (6.4) 10.5 (414) 303.9 (120) (7.6) 12.6 (497) 364.7 (144) © 3M 2006 3M™ Digital Projector S15i...

  • Page 12: Adjusting The Projector's Elevator

    Raise or lower the projector to the desired height and then release the elevator buttons. When you release the elevator buttons, the elevator feet will lock into position. the elevator feet by hand. © 3M 2006 3M™ Digital Projector S15i...

  • Page 13: Connecting Your Devices

    • Please take advantage of this function by connecting the accessory RGB properly if any other type of connection is attempted. • Please use the standard drivers in your computer as this projector is a © 3M 2006 3M™ Digital Projector S15i...
  • Page 14 Audio out Video out CONTROL S-VIDEO VIDEO AUDIO Audio cable (stereo mini) CONTROL S-VIDEO VIDEO Audio out AUDIO Audio cable (stereo mini) Component video cable CONTROL S-VIDEO VIDEO AUDIO Audio out Component video out © 3M 2006 3M™ Digital Projector S15i...

  • Page 15: Connecting Power Supply

    “O”). Power switch AC inlet Connector of the power cord Connect the connector of the power cord to the AC inlet of the projector. Firmly plug the power cord's plug into the outlet. © 3M 2006 3M™ Digital Projector S15i...

  • Page 16: Power On/Off

    When the power is completely on, the indicator will stop blinking and light green. POWER (Blinking green) POWER (Solid green) To display the picture, select an input signal according to the section "Selecting an input signal" © 3M 2006 3M™ Digital Projector S15i...

  • Page 17: Turning Off The Power

    Do not set the power switch to the OFF position while the POWER indicator is green or blinking. POWER (Solid orange) Close the lens cover. For safety purposes, disconnect the power cord if the projector is not to be used for prolonged periods of time. © 3M 2006 3M™ Digital Projector S15i...

  • Page 18: Operating

    ZOOM ASPECT AUTO BLANK POSITION MENU ENTER RESET VIDEO when TURN ON is selected for the AUTO SEARCH item in the OPTION menu If no input is detected at the © 3M 2006 3M™ Digital Projector S15i...

  • Page 19: Searching An Input Signal

    MENU adjusting the zoom. ENTER RESET To close the dialog and complete this operation, don’t perform operation for a few seconds. Adjusting the focus Use the focus ring to focus on the picture. © 3M 2006 3M™ Digital Projector S15i...

  • Page 20: Using The Automatic Adjustment Feature

    POSITION MENU ENTER RESET ZOOM To close the dialog and complete this operation, press the KEYSTONE button again. Even if you don’t do anything, the dialog will automatically disappear after a few seconds. © 3M 2006 3M™ Digital Projector S15i...

  • Page 21: Using The Partial Magnify Feature

    To remove the blank screen and return to the input signal screen, press the BLANK button again. signal changes, or when one of the projector’s buttons or the remote control buttons are pressed. © 3M 2006 3M™ Digital Projector S15i...

  • Page 22: Multifunctional Settings

    NORMAL MY MEMORY SAVE 1 MIRROR NORMAL MIRROR NORMAL RESET RESET Advanced MENU FILTER TIME FILTER TIME LANGUAGE ENGLISH LANGUAGE ENGLISH Go To Advance Menu... Go To Advance Menu... EASY MENU EASY MENU © 3M 2006 3M™ Digital Projector S15i...

  • Page 23: Advanced Menu

    PICTURE ZOOM IMAGE KEYSTONE IMAGE KEYSTONE ENTER INPUT WHISPER NORMAL INPUT WHISPER NORMAL SETUP MIRROR NORMAL SETUP MIRROR NORMAL SCREEN VOLUME SCREEN VOLUME OPTION OPTION EASY MENU EASY MENU KEYSTONE KEYSTONE is chosen © 3M 2006 3M™ Digital Projector S15i...
  • Page 24 (ex. LANGUAGE, H PHASE etc.) aren’t reset. To close the menu Press the MENU button again. Even if you don't do anything, the operation will complete and the menu will disappear automatically after about 10 seconds. © 3M 2006 3M™ Digital Projector S15i...

  • Page 25: Easy Menu

    See the item COLOR of section PICTURE menu. ( • This item can be chosen only at a video signal. TINT See the item TINT of section PICTURE menu. ( • This item can be chosen only at a video signal. © 3M 2006 3M™ Digital Projector S15i...

  • Page 26: Go To Advanced Menu

    See the item LANGUAGE of section SCREEN menu. ( Go To changes the EASY MENU into the Advanced MENU. ( Advanced Menu Performs to use the menu of PICTURE, IMAGE, INPUT, SETUP, SCREEN or OPTION. © 3M 2006 3M™ Digital Projector S15i...

  • Page 27: Picture Menu

    2nd tone from left end on the test pattern, use the equalizing adjustment bar “1”. The darkest tone at the left end of the test pattern cannot be controlled with any of equalizing adjustment bar. © 3M 2006 3M™ Digital Projector S15i...
  • Page 28 Gray scale of 15 steps COLOR Strong Weak • This item can be chosen only at a video signal. TINT Green • This item can be chosen only at a video signal. SHARPNESS Strong Weak © 3M 2006 3M™ Digital Projector S15i...

  • Page 29: My Memory

    Performing the SAVE1, SAVE2, SAVE3 or SAVE4 puts the current adjustment data on the memory whose number corresponds with the command’s number. © 3M 2006 3M™ Digital Projector S15i...

  • Page 30: Image Menu

    , and might not be exact display ratio. V POSITION Down H POSITION Left Right H PHASE Right Left • This item can be chosen only at a RGB signal or a component video signal. © 3M 2006 3M™ Digital Projector S15i...

  • Page 31: Auto Adjust Execute

    VIDEO FORMAT MENU. Refer to Page( For a component video signal, the signal type is automatically • The automatic adjustment operation requires approximately 10 seconds. Also please note that it may not function correctly with some input. © 3M 2006 3M™ Digital Projector S15i...

  • Page 32: Input Menu

    • The AUTO mode automatically selects the optimum mode. • The AUTO operation may not work well at some signals. If the picture becomes unstable (ex. an irregular picture, a color lack), please select the mode depending on the input signal. © 3M 2006 3M™ Digital Projector S15i...

  • Page 33: Information

    TION 1024x768 @60Hz SECAM INFORMATION FRAME LOCK AUTO • The “FRAME LOCK” message on the dialog means the frame lock function is working. ( • This item can't be chosen at no signal. © 3M 2006 3M™ Digital Projector S15i...

  • Page 34: Setup Menu

    MIRROR, if the projector screen is inclined or if the projector is angled downward, this function may not work correctly. NORMAL WHISPER WHISPER • When the WHISPER is selected, acoustic noise and screen brightness are reduced. MIRROR NORMAL H:INVERT V:INVERT H&V:INVERT VOLUME High © 3M 2006 3M™ Digital Projector S15i...

  • Page 35: Screen Menu

    • To avoid remaining as an afterimage, the MyScreen and the ORIGINAL screens will change to the BLACK screen after several minutes. 36). • For the MyScreen, please refer to the item MyScreen ( © 3M 2006 3M™ Digital Projector S15i...
  • Page 36 RESET or ESC button. Registration takes several minutes. When the registration is completed, the registered screen and the message “MyScreen registration failed, the message “A capturing error has occurred. Please try again.” is displayed. © 3M 2006 3M™ Digital Projector S15i...

  • Page 37: Myscreen Lock, Message

    ”SYNC IS OUT OF RANGE” ”Searching ..” while searching for an input signal ”Detecting….” when an input signal is detected The indication of the input signal by changing The indication of the aspect ration by changing © 3M 2006 3M™ Digital Projector S15i...

  • Page 38: Option Menu

    When the time is set to 1 to 99, and when the passed time with projector lamp will go off and the power indicator begins blinking. 17). Please refer to the section “Turning off the power” ( © 3M 2006 3M™ Digital Projector S15i...

  • Page 39: Filter Time, Service

    • Please reset the lamp time only when you have replaced the lamp, for a suitable indication about the lamp. 41, 42). • For the lamp replacement, see the section "Lamp" ( FILTER TIME RESET CANCEL • 43). • © 3M 2006 3M™ Digital Projector S15i...
  • Page 40 FACTORY RESET all the items in all of menus will collectively return to the initial setting. Note that the items LAMP TIME, FILTER TIME and LANGUAGE are not reset. RESET CANCEL © 3M 2006 3M™ Digital Projector S15i...

  • Page 41: Maintenance

    Using the lamp for long periods of time, or past the replacement date, could cause it to burst. Do not use old (used) lamps; this is a cause of breakage. © 3M 2006 3M™ Digital Projector S15i...
  • Page 42 (1) Press the MENU button to display a menu. Only when the EASY MENU has appeared, please perform the next step (2). NOTE • Please reset the lamp time only when you have replaced the lamp, for a suitable indication about the lamp. © 3M 2006 3M™ Digital Projector S15i...
  • Page 43 Turn the projector off, and unplug the power cord. Allow the lamp to cool for at least 45 minutes. Disconnect all the connectors and adapters that were connected to the projector’s projector. Filter cover’s knobs knob Filter cover’s knobs slowly turn the projector bottom up. © 3M 2006 3M™ Digital Projector S15i...
  • Page 44 Slowly turn the projector so that the top is facing up, except for the case of in the OPTION menu (1) Press the MENU button to display a menu. When the EASY MENU has appeared, please skip the next step (2). dialog will appear. © 3M 2006 3M™ Digital Projector S15i...

  • Page 45: Other Care

    If soiling is severe, dip soft cloth in water or a neutral cleaner dilute in water, and wipe lightly after wringing well. Then, wipe lightly with a soft, dry cloth. © 3M 2006 3M™ Digital Projector S15i...

  • Page 46: Troubleshooting

    There is no input signal. NO INPUT IS DETECTED ON *** of the signal source. The horizontal or vertical frequency of the input signal SYNC IS OUT OF RANGE ON *** fH *****kHz fV *****Hz © 3M 2006 3M™ Digital Projector S15i...
  • Page 47 *** HRS PASSED AFTER THE Please immediately turn the power OFF, and clean or LAST FILTER CHECK. FILTER MAINTENANCE IS ESSENTIAL 39). TO REMOVE WARNING MESSAGE, RESET FILTER TIMER. SEE MANUAL FURTHER INFO. © 3M 2006 3M™ Digital Projector S15i...

  • Page 48: Regarding The Indicator Lamps

    After performing any needed maintenance, turn the power on again. If the same indication is displayed after the treatment, please contact your dealer or service company. © 3M 2006 3M™ Digital Projector S15i...
  • Page 49 In such a case, press the “ ” (OFF) side of the power door and then turn the power on again. © 3M 2006 3M™ Digital Projector S15i...

  • Page 50: Phenomena That May Easily Be Mistaken For Machine Defects

    Either there is no lamp and/or lamp door, or either of Please turn the power off, and allow the unit to cool down at 41, 42 the lamp and lamp door, and then turn the power on again. © 3M 2006 3M™ Digital Projector S15i...
  • Page 51 NOTE • Although bright spots or dark spots may appear on the screen, this is a unique characteristic of liquid crystal displays, and such do not constitute or imply a machine defect. © 3M 2006 3M™ Digital Projector S15i...
  • Page 52 285 (W) x 73 (H) x 202 (D) mm Size (Not including protruding parts) Weight (mass) 2.3 kg RGB input: RGB..Communication port: CONTROL ..Ports Video input: VIDEO ...... RCA x 1 ..... Audio input: AUDIO ....Stereo mini x 1 © 3M 2006 3M™ Digital Projector S15i...
  • Page 53 [unit: mm] © 3M 2006 3M™ Digital Projector S15i...

  • Page 54: Example Of Computer Signal

    • Automatically adjustment may not function correctly with some input signals. • The image may not be displayed correctly when the input sync signal is a composite sync or a sync on G. © 3M 2006 3M™ Digital Projector S15i...
  • Page 55 1152 x 864 1152 x 864 10.7 (75Hz) (75Hz) 1280x960 1280x960 11.9 (60Hz) (60Hz) SXGA (60Hz) 11.9 SXGA (60Hz) 1024 SXGA (75Hz) SXGA (75Hz) 1024 SXGA (85Hz) SXGA (85Hz) 1024 UXGA (60Hz) UXGA (60Hz) 1200 © 3M 2006 3M™ Digital Projector S15i...
  • Page 56 Ground Green Ground Ground Blue (No connection) (No connection) Ground 10 Ground 11 (No connection) 12 SDA (DDC data) (No connection) 13 H. sync / Composite sync. 14 V. sync. 15 SCL (DDC clock) © 3M 2006 3M™ Digital Projector S15i...
  • Page 57 3 TD 6 (No connection) 9 (No connection) S-VIDEO Mini DIN 4pin jack Signal Ground Ground VIDEO RCA jack • System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL60 AUDIO Ø3.5 stereo mini jack © 3M 2006 3M™ Digital Projector S15i...

  • Page 58: Communications Setting

    Type Setting code high high high Action (byte_0 - 1) Action Content Change setting to desired value. Read projector internal setup value. INCREMENT Increment setup value by 1. DECREMENT EXECUTE Run a command. © 3M 2006 3M™ Digital Projector S15i...
  • Page 59 • Provide an interval of at least 40ms between the response code and any other code. • The projector outputs test data when the power supply is switched ON, and when the lamp is lit. Ignore this data. • Commands are not accepted during warm-up. © 3M 2006 3M™ Digital Projector S15i...

  • Page 60: Command Table

    9B FB 01 00 80 30 02 00 Ramp BE EF 06 00 0B FA 01 00 80 30 03 00 BE EF 06 00 C8 FA 02 00 80 30 00 00 © 3M 2006 3M™ Digital Projector S15i...
  • Page 61 02 00 B6 30 00 00 OFFSET G Increment BE EF 06 00 26 F5 04 00 B6 30 00 00 Decrement BE EF 06 00 F7 F4 05 00 B6 30 00 00 © 3M 2006 3M™ Digital Projector S15i...
  • Page 62 0E D1 01 00 08 20 01 00 NORMAL BE EF 06 00 5E DD 01 00 08 20 10 00 BE EF 06 00 AD D0 02 00 08 20 00 00 © 3M 2006 3M™ Digital Projector S15i...
  • Page 63 CB D6 01 00 14 30 00 00 TURN ON BE EF 06 00 5B D7 01 00 14 30 01 00 BE EF 06 00 F8 D6 02 00 14 30 00 00 © 3M 2006 3M™ Digital Projector S15i...
  • Page 64 15 30 00 00 Decrement BE EF 06 00 B3 D6 05 00 15 30 00 00 MENU POSITION H Execute BE EF 06 00 DC C6 06 00 43 70 00 00 Reset © 3M 2006 3M™ Digital Projector S15i...
  • Page 65 83 D2 01 00 02 30 00 00 FREEZE BE EF 06 00 13 D3 01 00 02 30 01 00 BE EF 06 00 B0 D2 02 00 02 30 00 00 © 3M 2006 3M™ Digital Projector S15i...
  • Page 66 Intended Use Before operating this machine, please read this entire manual thoroughly. The 3M Multimedia Projectors are designed, built, and tested for use indoors, using 3M lamps, 3M ceiling mount hardware, and nominal local voltages. The use of other replacement lamps, outdoor operation, or different voltages has not been tested and could damage the projector peripheral equip- ment and/or create a potentially unsafe operating condition.
