- Page 4 WIRING SCHEMATIC REAR VIEW OF MODULE RS-232 Port INV-200 Connector Jumpers for second outputs Pager port (Starter, Ignition, Accessories) Bypass/GPS port Bypass/GPS port RS-232 port Accessories 2 Jumper Pager port Ignition 2 Jumper INV-200 CONNECTOR Starter 2 Jumper (Door Lock pulse inverter) Temperature Sensor (Optional) 3.
