3Com NBX Communications System Planning Guide

Preliminary Information

Number of telephones installed on current telephone system:
Number of telephones being installed on the NBX system:
Number of users anticipated in the near future:
Number of chassis: NBX 100
Where will the NBX chassis be located?
How will it be mounted? Wall
Mode:
Key system? Hybrid/PBX?
Will disk mirroring be installed (SuperStack 3 NBX only)? Yes
What range of extensions would you like?
(NBX 100 default: 100-449 / SuperStack 3 default: 1000-4999)
Extension that will be assigned to the attendant's telephone:
Power Failure Telephone (PFT) units to be installed? (North America only) Yes
Number of PFTs:
UPS available for chassis? (UPS is recommended) Yes
Dedicated power outlet available for UPS? Yes
Will Ethernet power be used for the telephones? Yes
Number of 802.3af-compliant Ethernet power supplies:
Number of non-802.3af-compliant Ethernet power supplies (may require the use of a splitter
(3C10223) for each powered device):
Will a redundant power supply be used (SuperStack 3 NBX only)? Yes
Note: One dedicated power outlet is required for each power supply.
Attach a list of frequently dialed telephone numbers for System Speed Dials.

Site Survey

Cable Survey
Plenum PVC
Data cable: cat./level:
Voice-only cable: cat./level:
Total number of locations/drops:
Riser cable: Plenum
Copper Number of pairs:
Fiber Armored
Coax Type:
Demarcation for dial tone:
Feeder: existing new
Plenum PVC Number of pairs:
Termination block? Yes
Modular jack RJ-21x (66)
Location of IDFS:
Drop ceiling height:
