Wireless network setup
Connecting in PIN mode
1 The network configuration report, including PIN, must be printed (see
"Printing a network configuration report" on page 158).
In ready mode, press and hold the
the control panel for about 5 seconds. You can find your machine's PIN.
2 Press and hold the (WPS) button on the control panel for more than
4 seconds until the status LED stays on.
The machine starts connecting to the access point (or wireless router).
3 You need to enter the eight-digit PIN within two minutes on the
computer that is connected to the access point (or wireless router).
The LED blinks slowly for up to two minutes until you enter the eight-
digit PIN.
The WPS LED blinks in the order below:
a The light blinks fast on the WPS LED. The machine is connecting to
the access point (or wireless router).
b When the machine is successfully connected to the wireless
network, the WPS LED light stays on.
Insert the supplied software CD into your CD-ROM drive, and follow the
4
instructions in the window to set up the wireless network.
(Stop or Stop/Clear) button on
Re-connecting to a network
When the wireless function is off, the machine automatically tries to re-connect
to the access point (or wireless router) with the previously used wireless
connection settings and address.
In the following cases, the machine automatically re-connects to the
wireless network:
• The machine is turned off and on again.
• The access point (or wireless router) is turned off and on again.
Canceling the connection process
To cancel the wireless network connection when the machine is connecting to
the wireless network, press and release the
control panel. You need to wait 2 minutes to re-connect to the wireless
network.
(Cancel or Stop/Clear) on the
