Washing Machine Instruction Manual
DWD-M8011/DWD-M8012/DWD-M8013
INSTRUCTION MANUAL
Economic washing system
The washing machine determines the water level and washing time
automatically by sensing the amount of laundry and water temperature
in order to minimize energy and water consumption.
Low noise system
The washing machine minimizes the spinning noise level by sensing
the amount of unbalance of laundry.
Nano-silver sterilization washing(Option)
By applying very fine silver particles on essential parts inside, the
washer sterilizes up to 99.9% as is done by boiling wash.
Air bubble washing(Option)
This is an advanced technology that generates millions of air bubbles inside the drum on washing
sequence, and the bubbles dissolve the detergent particles completely and cleanse all the soil in
clothes gently and neatly.
CONTENTS
PARTS AND FEATURES.................................................................................................................2
WASHER SAFETY...........................................................................................................................3
INSTALLATION INSTRUCTIONS ....................................................................................................4
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHER ........................................................................................................6
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................8
PROGRAMS AND FUNCTIONS ......................................................................................................9
WASHING PROCEDURE AND PROGRAM SELECTION.............................................................10
MAINTENANCE .............................................................................................................................11
HOW TO CLEAN THE FILTER ......................................................................................................12
REMOVING STAINS ......................................................................................................................13
TROUBLE SHOOTING ..................................................................................................................14
SPECIFICATION ............................................................................................................................15
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washers are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your washer properly and safely.
Please read it carefully.
Page
Advertisement
Table of Contents
Related Manuals for Daewoo DWD-M8013
Summary of Contents for Daewoo DWD-M8013
-
Page 1: Table Of Contents
A NOTE TO YOU Thank you for buying a DAEWOO appliance. DAEWOO washers are easy to use, save time, and help you manage your home better. This manual contains valuable information about how to operate and maintain your washer properly and safely. -
Page 2: Parts And Features
PARTS AND FEATURES The parts and features of your washer are illustrated on the page. Become familiar with all parts and features before using your washer. NOTE The drawings in the book may vary from your washer model. They are designed to show the different features of all models coverd by this book. Your model may not include all features. -
Page 3: Washer Safety
WASHER SAFETY Save these instructions Your safety is important to us. To reduce the risk of fire, electrical shock, or injury when using your washer adhere to the following basic precautions. Read all instructions before using your washer • Flammable fluids (dry-cleaning solvents, Please ... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Removing transit bolts 1. Before operating the washer, remove the transit bolts(3ea) along with the rubber. • If the bolts are not removed, it may cause heavy vibration, noise and malfunction. 2. Unscrew the 3 bolts with the 10mm hex wrench or spanner or cross-tip screwdriver. -
Page 5: Drain System
Drain system • Never forget to install drain hose before operating your washer. • Open the packing box, and the drain hose is tied at backside of washer. • If you use the laundry tub, Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS Electrical shock hazard : Failure to follow these instructions could result in WARNING death or serious injury. • Electrical earth is required on this washer • Don’t earth to a gas pipe. • If it does not fit the outlet, have a proper outlet •... - Page 7 Sorting • Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together. • Separate dark colors from light colors, colorfast items from non-colorfast item. Soil (Heavy, Normal, Light) Separate clothes according to amount of soil. Color (White, Lignts, Darks) Separate white clothes from colored clothes.
-
Page 8: The Functions Of The Control Panel
THE FUNCTIONS OF THE CONTROL PANEL Program selector For switching the washing machine on and off and for selecting the program. Can be rotated in both direction. Even if the program selector rotates while the program is running, the program is not changed (except for off (All program is electronically controlled by PCB) Start/Hold button Button for options... -
Page 9: Programs And Functions
PROGRAMS AND FUNCTIONS Programs and functions Program Fabric type Proper Degree Option Max. Remark Temp. of soiling Load Colorfast garments Cold Lightly (shirts, night dresses, 40°C soiled pajamas…) and lightly soiled white cotton Normally (underwear…) 60°C to heavily soiled Intensive wash Rinse+ Rating 60°C/Pre... -
Page 10: Washing Procedure And Program Selection
WASHING PROCEDURE AND PROGRAM SELECTION Washing Procedure • Turn the program selector to the desired program The indicator light of Start/Hold button is on. • If required, press the button(s) for option(s). The indicator light of the selected option button is on. •... -
Page 11: Maintenance
MAINTENANCE Proper care of your washer can extend its life. This section explains how to care for your washer properly and safely. Cleaning your washer Exterior Interior Wipe up detergent, bleach, and other spills with Clean interior with 250ml of chlorine bleach a soft, damp cloth or sponge as they occur. -
Page 12: How To Clean The Filter
HOW TO CLEAN THE FILTER Cleaning the water inlet filter • Clean the filter when water leaks from the water inlet. 1 Turn off the water 2 Separate the inlet 3 Pull out the inlet filter. 4 Connect the inlet tap. -
Page 13: Removing Stains
REMOVING STAINS Stained, heavily-soiled, or greasy items may need to be prewashed or soaked for best results. Soaking helps remove protein-type stains like blood, milk or grass. Prewashing helps loosen soil before washing. Stain removal rules • Use warm water for soaking or prewashing stained laundry. Hot water can set stains. •... -
Page 14: Trouble Shooting
TROUBLE SHOOTING Most problems are easily solved if you understand the cause. Check the following list for problem before calling for service. Problem Cause Solution Program dose not start. Plug is loose or not plugged in. Insert plug tightly. Power failure. An interrupted program will be resumed when the power return. -
Page 15: Specification
SPECIFICATION MODEL DWD-M8011/DWD-M8012/DWD-M8013 Dimension (mm) 595x440x850 (WxDxH) Maximum mass of textile (kg) Unit Weight (kg) 43(Net)/46(Gross) Standard Water Consumption Spin Speed (RPM) Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm ~ 8kgf/cm... - Page 16 ABOUT THIS MANUAL ABOUT THIS MANUAL VISION CREATIVE, INC.
