Service Manual
Washing Machine
Model:
DWD-M8041/M8042/M8043
DWD-M1041
DWD-M1241/M1242/M1243
Caution
: In this Manual, some parts can be changed for improving, their per-
formance without notice in the parts list. So, if you need the latest
parts information, please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. :
Jan. 2010
Advertisement
Table of Contents
Related Manuals for Daewoo DWD-M1041
Summary of Contents for Daewoo DWD-M1041
-
Page 1: Service Manual
: In this Manual, some parts can be changed for improving, their per- formance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CORP. http : //svc.dwe.co.kr Jan. 2010... -
Page 2: Direction For Disassembly
4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1 Open the door and remove the clamp door as. 2 Separate the gasket from the cabinet front and remove two screws. 3 Remove the door lock switch from the cabinet front . DRAIN PUMP 1 Separate the cover pump from the cabinet front and 2 Lay the right-side of the washer on the floor. - Page 3 HEATER AND THERMISTOR 1 Separate the plate t as from the washer. 2 Separate the case detergent as and remove two (Remove two screws at rear) screws from panel f. 3 Separate the panel f as from the washer. 4 Separate the cabinet front from the washer. (Remove the clamp door as and 4 screws) 5 Separate connectors from the heater and remove the 6 Remove the earth terminal and loosen the nut by using...
-
Page 4: Universal Motor
UNIVERSAL MOTOR Firstly, you have to do from 1 to 5 of HEATER AND THERMISTOR DISASSEMBLY. 1 Separate the box inlet as from the washer. 2 Remove the screw of the motor connector. (Remove screws and hose inlet) And separate the connector from the tub. 3 Separate the hose air from the sensor pressure. -
Page 5: Explode View And Parts List
5. EXPLODE VIEW AND PARTS LIST BOX INLET AS PART NAME PART CODE SPECIFICATION Q'TY REMARK A01 CASE HANDLE 36111T1U00 ABS D-MU1041 A02 CASE DETERGENT 3611145800 A03 CAP SOFTENER 3610907800 A04 BOX INLET 3610527500 A05 NOZZLE AS 3618105700 D-MU80 SINGLE VALVE COLD ONLY 3618105710 D-MU80 COLD+HOT... - Page 6 PANEL FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK B01 PANEL F 36142T2400 DWD-M104'S B02 BUTTON RES 3616645400 DWD-M104'S B03 BUTTON SELECT 3616645500 DWD-M104'S B04 WINDOW DISPLAY 3615509800 TR-ABS DWD-M104'S B05 WINDOW LED 3615509700 TR-ABS DWD-M104'S PRPSSWC063 B06 PCB AS PRPSSWC050 D-MU804 PCB DEFAULT AS(DUAL+BB) M804'S(DUAL+BB) PRPSSWC051 D-MU804 PCB OPTION AS (COLD &...
- Page 7 3615114600 SUS D1.4 C10 PIN HANDLE 3618200200 SUS304, D3, L48 C11 DOOR GLASS 361A110700 GLASS PI300 C12 FRAME DOOR O 3612208602 DWD-M1041 3612208600 HIPS DWD-M1041(OPTION) 3612208601 ABS CR-GILDING D-F1032 DWD-M1042(3) C13 SCREW TAPPING 7115401629 NO DISPONBLE T1 FLT 4X16 SUS...
- Page 8 TUB AS EXPLODE VIEW AND PARTS LIST...
- Page 9 PART NAME PART CODE SPECIFICATION Q'TY REMARK D01 TUB REAR AS 3618829900 D-MU103 TUB REAR+BEARING HOUSING D02 BEARING INNER 3616304700 6205ZZ SHENS D03 BEARING OUTER 3616304800 6204ZZ SHENS D04 WATER SEAL 361A600300 D05 GASKET TUB 3612324100 PI=4.5, L=1650, EPDM D06 FIXTURE HEATER 3612009400 SUS, PI=2 D07 TUB FRONT...
- Page 10 CABINET AS EXPLODE VIEW AND PARTS LIST...
- Page 11 NYLON, DA-16N, ID21.9 D-MU80 NO DISPONIBLE NO DISPONIBLE E10 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN E11 PLATE T AS 3614540700 D-MU1031(2), WHITE DWD-M1041(2) 3614540701 SILVER PATTERN D-MU1033 DWD-M1043 NO DISPONIBLE E12 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN E13 REACTOR AS...
-
Page 12: Function Of The Convenient Service
8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the load movement You can check the PCB ASS'Y and the condition of each load movement simply. • The method to test the load movement 1 Plug the power cord. 2 Turn the program selector to arbitrary program (except for OFF position). - Page 13 DISPLAY ERROR MESSAGE MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke Change the valve inlet.
- Page 14 MESSAGE CAUSE ERROR SOLUTION The water is supplied continuously due to an OVERFLOW Change the valve inlet. inferior valve inlet. ERROR The valve inlet is normal, but the water level Change the water level sensor (sensor sensor (sensor pressure) is inferior. pressure).
-
Page 15: Wiring Diagram
10. WIRING DIAGRAM WIRING DIAGRAM... - Page 16 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Jan. 2010...
