Service Manual
Washing Machine
Model:
DWD-M801X/M802X/M803X
DWD-M101X/M102X/M103X
DWD-M121X/M122X/M123X
Caution
: In this Manual, some parts can be changed for improving, their per-
formance without notice in the parts list. So, if you need the latest
parts information, please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. :
Jan. 2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo DWD-M801X
Summary of Contents for Daewoo DWD-M801X
- Page 1 : In this Manual, some parts can be changed for improving, their per- formance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CORP. http : //svc.dwe.co.kr Jan. 2010...
-
Page 2: Table Of Contents
AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER... -
Page 3: Specifications
1. SPECIFICATIONS DWD-M801X/101X/121X SERIES INLET HOSE (HOT) (OPTION) INLET HOSE (COLD) DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN COVER PUMP ADJUSTABLE LEG MODEL DWD-M801X/101X/121X SERIES POWER SOURCE 220~240V / 50, 60Hz DIMENSION (WXDXH) 595mm x 440mm x 850mm... - Page 4 DWD-M802X/102X/122X SERIES INLET HOSE (HOT) (OPTION) INLET HOSE (COLD) DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN COVER PUMP ADJUSTABLE LEG MODEL DWD-M802X/102X/122X SERIES POWER SOURCE 220~240V / 50, 60Hz DIMENSION (WXDXH) 595mm x 440mm x 850mm WEIGHT 43 Kg WATER CONSUMPTION 42ℓ...
- Page 5 D-MU803'S, D-MU103'S, D-MU123'S INLET HOSE (HOT) (OPTION) INLET HOSE (COLD) DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN COVER PUMP ADJUSTABLE LEG MODEL D-MU803'S, D-MU103'S, D-MU123'S POWER SOURCE 220~240V / 50, 60Hz DIMENSION (WXDXH) 595mm x 440mm x 850mm WEIGHT 54 Kg WATER CONSUMPTION...
-
Page 6: Installation
2. INSTALLATION Removing transit bolts 1. Before operating the washer, remove the transit bolts(3ea) along with the rubber. • If the bolts are not removed, it may cause heavy vibration, noise and malfunction. 2. Unscrew the 3 bolts with the 10mm hex wrench or spanner or cross-tip screwdriver. -
Page 7: Bs Plug Safety Details (For U.k. User)
BS Plug Safety Details (For U.K. User) IMPORTANT THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE: GREEN AND YELLOW : EARTH BLUE : NEUTRAL BROWN : LIVE This appliance must be earthed As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol... -
Page 8: Installation Of Drain Hose
Installation of drain hose • Never forget to install drain hose before operating your washer. • Open the packing box, and the drain hose is tied at backside of washer. • If you use the laundry tub, Top of laundry tub must be at least 60cm high and no higher than 100cm from bottom of washer. •... -
Page 9: Maintenance
3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock hazards. Proper care of your washer can extend its life. This section explains how to care for your washer proper- ly and safely. Cleaning your washer Exterior Interior •... -
Page 10: Cleaning The Water Inlet Filter
Cleaning the water inlet filter. • “IE” error message (refer to troubleshooting guide) will display when the water does not enter the detergent case. • If your water is very hard or contains traces of lime deposit, the water inlet filter may become clogged. And the water leaks from the water inlet. -
Page 11: Cleaning The Detergent Case
Cleaning the detergent case. • In case of residual detergents or fabric softeners have accumulated ; - it should be cleaned with a jet of running water. - If necessary, it can be removed completely from the washing machine. Push point 1 Pull-out 2 Push and pull again •... -
Page 12: Direction For Disassembly
4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1 Open the door and remove the clamp door as. 2 Separate the gasket from the cabinet front and remove two screws. 3 Remove the door lock switch from the cabinet front . DRAIN PUMP 1 Separate the cover pump from the cabinet front and 2 Lay the right-side of the washer on the floor. - Page 13 HEATER AND THERMISTOR 1 Separate the plate t as from the washer. 2 Separate the case detergent as and remove two (Remove two screws at rear) screws from panel f. 3 Separate the panel f as from the washer. 4 Separate the cabinet front from the washer. (Remove the clamp door as and 4 screws) 5 Separate connectors from the heater and remove the 6 Remove the earth terminal and loosen the nut by using...
- Page 14 UNIVERSAL MOTOR Firstly, you have to do from 1 to 5 of HEATER AND THERMISTOR DISASSEMBLY. 1 Separate the box inlet as from the washer. 2 Remove the screw of the motor connector. (remove screws and hose inlet) And separate the connector from the tub. 3 Separate the hose air from the sensor pressure.
-
Page 15: Explode View And Parts List
5. EXPLODE VIEW AND PARTS LIST BOX INLET AS PART NAME PART CODE SPECIFICATION Q'TY REMARK HANDLE CASE 36111TE00 HIPS D-MU1031 CASE DETERGENT 3611145800 PP CAP SOFTENER 3610907800 PP BOX INLET 3610527500 PP 3618105700 COLD ONLY NOZZLE AS NOZZLE TOP + NOZZLE UNDER 3618105710 COLD+HOT SCREW TAPPING... - Page 16 PANEL FRONT AS (DWD-M801X/101X/121X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL F 3614287400 HIPS DWD-M801X's WINDOW LED 3615505200 ABS TRANSPARENT DWD-M801X's BUTTON SELECT 3616636400 DWD-M801X's KNOB DIAL AS 3613406300 KNOB+DECO DWD-M801X's SHAFT KNOB 3614905600 MU801's PRPSSWC000 OPTION(COLD+HOT, BB) CASE PCB(HIPS)
- Page 17 PANEL FRONT AS (DWD-M802X/102X/122X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL F 3614287500 HIPS DWD-M802X's WINDOW LED 3615505300 ABS TRANSPARENT DWD-M802X's BUTTON SELECT 3616636500 DWD-M802X's KNOB DIAL AS 3613406200 KNOB+DECO DWD-M802X's SHAFT KNOB 3614905700 MU802's PRPSSWC010 OPTION(COLD+HOT, BB) CASE PCB(HIPS) PRPSSWC011 OPTION(COLD, NB) CASE PCB(HIPS) DWD-M802X's...
- Page 18 PANEL FRONT AS (DWD-M803X/103X/123X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL F 36142T1D00 HIPS D-MU1031 BUTTON SELECT 3616640100 HIPS D-MU1031 BUTTON RES 3616640000 HIPS D-MU1031 WINDOW LED 3615507800 D-MU1031 WINDOW DISPLAY 3615507900 D-MU1031 KNOB DIAL AS 3613408000 KNOB OUT,IN+DECO D-MU1031 SHAFT KNOB 3614905700...
- Page 19 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET F AS 3610812810 PAINTING T=0.7 3618829901 TUB REAR(FRPP) + BEARING HOUSING(ALDC) FRPP D-MU103' s change core NUT HEX 7S627W50X1 NUT FLANGE M5X0.8P MFZN SCREW TAPPING 3616051229 STS430 F/L BOLT(SE) 5*12 CAP HINGE DOOR 3610916500 POM HINGE DOOR...
- Page 20 TUB AS EXPLODE VIEW AND PARTS LIST...
- Page 21 PART NAME PART CODE SPECIFICATION Q'TY REMARK 3618829900 TUB REAR(FRPP) + BEARING HOUSING(ALDC) TUB REAR AS 3618829901 TUB REAR(FRPP) + BEARING HOUSING(ALDC) FRPP D-MU103' s change core BEARING INNER 3616304700 6205ZZ SHENS BEARING OUTER 3616304800 6204ZZ SHENS WATER SEAL 361A600300 GASKET TUB 3612324100 PI=4.5, L=1650, EPDM...
- Page 22 CABINET AS EXPLODE VIEW AND PARTS LIST...
- Page 23 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610812700 SGCC(GI) T=0.7 PCM 3610812710 SGCC(GI) T=0.7 PAINTING FRAME LOWER 3612208400 SGCC T=0.8 BASE U L 3610393100 SGCC T=1.4 3610393400 SGCC T=1.6 BASE U R 3610393110 SGCC T=1.4 3610393500 SGCC T=1.6 FOOT(BUTYL)+SPECIAL NUT(SCP1) 3617703800 +SPECIAL BOLT(10x1.25, 51MM) LEG ADJUST AS...
-
Page 24: Functions Of The Control Panel
6. FUNCTIONS OF THE CONTROL PANEL DWD-M801X/101X/121X SERIES Program selector For switching the washing machine on and off and for selecting the program. Can be rotated in both direction. Even if the program selector rotates while the program is running,... - Page 25 DWD-M802X/102X/122X SERIES Program selector Indicator light For switching the washing machine on and off The respective indicator lights up, and for selecting the program. when the required program segment runs or “Time delay” is Can be rotated in both direction. selected.
- Page 26 DWD-M803X/103X/123X SERIES Program selector Indicator light The respective indicator lights up, For switching the washing machine on and off When the required program and for selecting the program. segment runs or “Time delay” is selected. Can be rotated in both direction. Even if the program selector rotates while the Time delay program is running, the program is not changed...
-
Page 27: Functions Of The Controller
7. FUNCTIONS OF THE CONTROLLER SEQUENCE CHART Cotton Division Progress Time PREWASH COLD 30°C 40°C 60°C 95°C QUICK30 MIXED 60°C Sensing 20sec. Water Supply 2min. 13min. Pre Wash 8min. Drain 1min. B-Spin 1min. Middle Spin 5min. Sensing 20sec. Water Supply 2min. - Page 28 Synthetic Division Progress Time PREWASH COLD 30°C 40°C 60°C 60°C Sensing 20sec. Water Supply 2min. Pre Wash 13min. 8min. Drain 1min. B-Spin 1min. Middle Spin 5min. Sensing 20sec. Water Supply 2min. 60min. Wash 1 35min. (Heating) 30min. 15min. 10min. 73min. Wash 2 23min.
- Page 29 Wool Delicate Division Progress Time HAND COLD 30°C 40°C COLD 30°C 40°C WASH Sensing 20sec. Water Supply 2min. 13min. Pre Wash 8min. Drain 1min. B-Spin 1min. Middle Spin 5min. Sensing 20sec. Water Supply 2min. 60min. Wash 1 35min. (Heating) 30min. 15min.
-
Page 30: Function Of The Convenient Service
8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the load movement You can check the PCB ASS'Y and the condition of each load movement simply. • The method to test the load movement 1 Plug the power cord. 2 Turn the program selector to the program 1. -
Page 31: Troubleshooting Guide
9. TROUBLESHOOTING GUIDE This washer is equipped with automatic safety function which detects and diagnoses faults at an early stage and copes properly. When the washer does not operate properly, check the following points. Simply Check Guide Problem Cause Solution Program dose not start. - Page 32 DISPLAY ERROR MESSAGE When mechanical or electrical troubles of the washer are occurred, indicator lights of buttons twinkle simultaneously as follows; ERROR Indicator Light twinkling MESSAGE Start/Hold Intensive wash Rinse+ Rinse Hold PFE, OE, E4 E7, E8 E2, E9 H2, H4, H5, H6, H8 MESSAGE ERROR CAUSE...
- Page 33 MESSAGE CAUSE ERROR SOLUTION The water is supplied continuously due to an OVERFLOW Change the valve inlet. inferior valve inlet. ERROR The valve inlet is normal, but the water level Change the water level sensor (sensor sensor (sensor pressure) is inferior. pressure).
-
Page 34: Wiring Diagram
10. WIRING DIAGRAM WIRING DIAGRAM... - Page 35 DAEWOO ELECTRONICS CORP. 1-2, Jeo-dong 1(il)-ga, Jung-gu, Seoul, Korea C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : PRINTED DATE: Jan. 2010...
- Page 36 V V I I S S I I O O N N C C R R E E A A T T I I V V E E , , I I N N C C . . 서울 종로구 통의동 6번지 이룸빌딩 4층 담 당 정건기 님 DWD-M801X/M802X/M803X M O D E L DWD-M101X/M102X/M103X DWD-M121X/M122X/M123X (S/M) 접 수...
