SERVICE CALL CHECK

PLEASE CHECK THE FOLLOWING BEFORE CALLING FOR SERVICE:
1. Power Supply:
Check the power plug is properly connected to a suitable wall outlet.
Check the line fuse/circuit breaker is functioning properly.
2. When the door is opened, does the oven lamp light?
3. Place a cup of water (approx. 150 ml) in the oven and close the door securely.
Set the cooking mode to microwave cooking mode.
Programme the oven for one minute on full power (900 W) and start the oven.
Does the oven lamp light?
Does the turntable rotate?
NOTE: The turntable turns in either direction.
Does the ventilation work?
(Place your hand over the ventilation openings and check for air flow.)
After 1 minute does the signal sound?
Does the cooking in progress indicator go off?
Is the cup of water warm after the above operation?
4. Set the GRILL cooking mode using the top grill and bottom grill for 3 minutes.
After 3 minutes do both GRILL heating elements become red?
If you answer "NO" to any of the above questions, call a Service Technician appointed by SHARP and report the
results of your check. See inside back cover for details of address.
IMPORTANT: If the display shows nothing even if the power plug is properly connected, the energy save mode
should carry on. To release it, open and then close the oven door. See page 8.
NOTES:
1. If you cook the food over the standard time with only the same cooking mode, the power of the oven will
lower automatically to avoid overheating. (The microwave power level will be reduced and the grill heating
elements will begin to light on and off.)
TOP GRILL
BOTTOM GRILL
TOP and BOTTOM GRILL
Dual 2
Dual 3
2. After the GRILL (using both heating elements), DUAL, CONVECTION and AUTOMATIC (except
Automatic Defrost), the cooling fan will run until the oven has cooled down. Also, when you press the STOP
key and open the door during the GRILL, DUAL, CONVECTION and AUTOMATIC (except Automatic
Defrost), the cooling fan will run; you may, therefore, feel air blowing from the ventilation openings.
16:32 Page 24
Cooking mode
Microwave 100 % cooking
Grill cooking
24
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
YES NO
Standard time
20 min.
30 min.
45 min.
Top grill - 15 min.
Bottom grill - 15 min.
Micro - 20 min.
Top grill - 15 min.
Micro - 20 min.
Bottom grill - 15 min.
