Sharp R-85STM-A Quick Start Manual

R-85STM-A
QUICK START GUIDE
1
2
15 3
4
14
5
6
7
13 8
12 9
11 10
1 DIGITAL DISPLAY 9 INFO key
2 TIME keys 10 START/AUTO MINUTE key
3 CONV. (˚C) key 11 STOP/CLEAR key
4 COMBI key 12 KITCHEN TIMER/CLOCK SET
key
5 INSTANT COOK keys
13 WEIGHT UP/DOWN keys
6 EXPRESS COOK keys
14 MICRO POWER key
7 EXPRESS DEFROST keys
15 GRILL key
8 LESS/MORE keys
TINS-A716WRRZ-K61
1
INSTALLATION
INSTALLATION
1. Remove all packaging and
accessories from the oven, including the
feature sticker fixed to the outside of the
door and the wrapping shown in the diagram.
DO NOT REMOVE THE WAVEGUIDE COVER,
this can be found on the right hand side wall
inside your microwave. Please see page 4 in the
operation manual.
2. Ensure there is at least 19cm of free space
above the oven.
3. Ensure the turntable parts
are assembled as shown in
the diagram opposite.
Other Accessories
The racks can be used for
"Grilling" ,"Dual Cooking" or
"Convection Cooking" of food.
MICROWAVING MICROWAVING
To cook for 2 minutes 30 seconds on 70%
microwave power.
1. Enter the cooking time by
x2
pressing the 1 MIN. key
twice and the 10 SEC. key
x3
three times.
2. Select the power by pressing
x2
the MICRO POWER key twice.
3. Press the START/AUTO MINUTE
key once to start cooking.
4
4. The display will count down through cooking time.
the message shown opposite (1).
Close the door. The display will show (2).
The oven is now ready for use.
If you want to set the clock, press the
KITCHEN TIMER/CLOCK SET key twice and follow
the instructions in Step 3 below.
IMPORTANT
The oven has an Energy Save mode, for details refer to page 8 of your
If you
require any
advice or assistance
regarding your Sharp
product, please visit our Website
or call our Help Line.
Website:
www.sharp.co.uk/customersupport
Help Line:
08705 274277 (U.K.)
(01) 676 0648 (Ireland)
(office hours)
2. Enter the hours by pressing the TIME keys.
3. Press the KITCHEN TIMER/CLOCK SET key
again and enter the minutes by pressing the
TIME keys.
x1
GETTING STARTED
GETTING STARTED
Plug in the oven. Nothing will appear
in the display at this time. 1.
Open the door, the display will flash
2.
Operation Manual.
• The oven will default to Energy Save Mode after 3 minutes if not
used. Whilst in Energy Save Mode the display is blank and the
oven cannot be used.
• To remove Energy Save Mode, open and then close the
door, ".0" will be displayed and the oven
is ready for use.
• To remove Energy Save Mode
permanently, set the clock.
SETTING
SETTING
THE CLOCK
THE CLOCK
Your oven is fitted with a 12 hour clock.
To set the time of day, ensure the door is closed and follow
the guidelines given below:
1.Press the KITCHEN TIMER/CLOCK
SET key twice.
4. Press the KITCHEN
TIMER/CLOCK SET key
again to start the clock.
2
x2
x1
3
x1
