ENERGY SAVE MODE
GB
Dear Customer,
Your oven comes set for the energy save mode. When you plug the oven in, nothing will appear on
the display at this time.
To operate the oven with Energy Save Mode
1. Open the door. The oven display will show "ENERGY SAVE MODE". You can place the food in the oven
for cooking.
2. Close the door and press the STOP key. The display will show " .0". Set the cooking time, cooking mode
and power level and start the cooking progress (please refer to the operation manual.).
3. Remove the food from the oven after the audible signal sounds
4. If you do nothing for 2 minutes after the preceeding operation, i.e. plugging in, closing the door
or pressing the STOP key, or at the end of cooking the power will go off automatically.
5. To restore the power on, open and then close the door.
If you set the clock, energy save mode does not work. (How to set the clock you
will find in the operation manual.)
Example: To change from clock set mode (stand-by operation) to Energy Save Mode.
Make sure the correct time appears on the display.
1. Press the CLOCK 2. Press the 1 MIN key once. 3.Press the +1 min
SETTING key.
x1
x1
CONTROL PANEL
GB
Following you will find the Control Panel of model R-852. For R-84ST the Digital Display, Indicators
and Operating Keys are the same.
Digital display and indicators:
1. TOP GRILL indicator
8.
2. BOTTOM GRILL indicator
1.
3. CONVECTION indicator
7.
2.
4. MICROWAVE indicator
6.
3.
5. WEIGHT (kg) indicator
5.
4.
6. COOKING IN PROGRESS indicator
7. LESS/MORE indicators
9.
23.
8. CLOCK SET indicator
10.
22.
Operating keys:
9. FRESH PIZZA/FRESH QUICHE key
10. BOILED/JACKET POTATOES key
11. INSTANT ACTION keys
11.
12. LESS/MORE keys
13. TIME keys
14. CONVECTION key
12. Press to change the convection setting
21.
15. DUAL MODE key:
13.
1 PRESS
2 PRESSES = MICROWAVE & TOP GRILL
3 PRESSES = MICROWAVE & BOTTOM GRILL
16. +1 min
20. 14.
17. DOOR OPEN button
18. STOP key
19. 15.
19. GRILL MODE key:
1 PRESS
2 PRESSES = BOTTOM GRILL
18. 16.
3 PRESSES = TOP & BOTTOM GRILL
20. MICROWAVE POWER LEVEL key
Press to change the microwave power setting
21. CLOCK SETTING key
17.
22. FRENCH FRIED POTATO key
23. FROZEN PIZZA/FROZEN QUICHE key
ENGLISH
TINS-A272URR0
GB
GB
/ START key.
The power will be off and the display
will show nothing.
x1
GB
= MICROWAVE & CONVECTION
/START key
= TOP GRILL
Read SAFETY WARNINGS in the manual
R-852 / R-84ST
MICROWAVE OVEN WITH TOP &
BOTTOM GRILLS AND CONVECTION
QUICK START GUIDE
before operating
R-852
